Summary of Contents for Genaray SSL-36
- Page 1 SSL-36 36 IN. SOFT STRIP LED USER MANUAL...
- Page 2 The SSL-36 runs on AC or battery power. It has a color temperature of 5600 K and a 95 CRI rating, which delivers excellent color accuracy. Its power output is controlled by a stepless dimmer knob that ranges from 100% to 10% brightness.
- Page 3 · Do not attempt to disassemble or there are no missing parts. repair the equipment—doing so will · All images are for illustrative void the warranty, and Genaray will purposes only. not be responsible for any damage. SSL-36 USER MANUAL...
-
Page 4: Product Overview
Ratchet handle 5/8 in. mounting AC adapter receiver Lollipop Locking knob Release AC power PRODUCT lever cable OVERVIEW 3-pin XLR cable Mounting studs Carrying case FRONT BACK Diffuser Mounting plate Barndoors SSL-36 USER MANUAL... - Page 5 Hanger loop Dimmer control box Battery Mounting-shoe release button slot Battery contacts D-tap power socket 3-pin XLR Brightness input control Power output 3-way power cable V-mount switch battery slot V-mount adapter with touch-connect strap SSL-36 USER MANUAL...
- Page 6 MOUNTING THE SSL-36 Attaching the Lollipop Mount Mounting the SSL-36 to a Light Stand 1. Close the barndoors, and place the light 1. Make sure the ratchet handle is tightened facedown on a flat surface. before mounting the SSL-36. 2. Align the lollipop mount with the mounting 2.
- Page 7 2. To connect the power output cable to the Using the SSL-36 with AC power SSL-36’s 4-pin connector, align the two Important! The SSL-36 is a multivoltage fixture connectors, and press them together. capable of running on 100 to 240 V, 50/60 Hz.
- Page 8 POWERING THE SSL-36 (CONTINUED) To move the AC adapter safely out of Using the SSL-36 with Battery Power the way: 1. When attaching a V-mount battery, make sure the power switch is in the off position, 1. Wrap the touch-connect strap securely and disconnect the AC adapter so the around the AC adapter.
- Page 9 ADJUSTING POWERING THE SSL-36 THE LIGHT (CONTINUED) 3. Place the battery down into the mount, The brightness control on the control box can and push the battery toward the contacts adjust the output from 100% to 10%. until it clicks into place.
-
Page 10: Product Specifications
Control box: 2.7 × 3.5 × 5.6 in. (6.8 × 9 × 14.2 cm) Bulb Life: 50,000 hr. AC adapter: 1.5 × 2.9 × 5.9 in. (3.8 × 7.4 × 15 cm) Carry bag: 39.4 × 5.1 × 4.7 in. (100 × 13 × 12 cm) Battery: V-mount SSL-36 USER MANUAL... - Page 11 ONE-YEAR LIMITED WARRANTY This GENARAY product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of...
