Summary of Contents for Genaray OLED-55
- Page 1 OLED-55 OCTALUX LED USER MANUAL OctaLux LED - USER MANUAL...
-
Page 2: Introduction
Thank you for choosing Genaray. The OctaLux LED Light Softbox produces bright, soft, and OctaLux LED consistent light that’s designed for use in the studio or on INTRODUCTION location when shooting portraits, beauty/fashion, tabletop products, and interviews. 240 individual LEDs generate a 5500 K daylight-balanced light that creates warmth and glow on your subject. -
Page 3: Table Of Contents
The housing is sturdy, and the LEDs are not prone to Overview ........6-9 breakage like fluorescent fixtures, making the Genaray OLED-55 ideal for everyday usage. The OctaLux LED Light Assembling the Softbox ..10-11 Softbox is 31.5˝ (80 cm) in diameter, and it attaches with Attaching the Diffusers ..12-13... -
Page 4: Precautions
PRECAUTIONS · Please read and follow these · Always remove the power cord by instructions, and keep this holding the plug; do not pull the cord. manual in a safe place. · Disconnect the power cord from · Keep this product away from water the power supply when not in use. - Page 5 · Do not stare at the light · If necessary, clean the LEDs when it is powered on. with only a lint-free, cotton cloth. Do not smudge. · Do not point directly towards the naked eye (especially those of · Keep this product away from children. infants and small children)—it ·...
-
Page 6: Overview
OctaLux light head Reflector dish PRODUCT OVERVIEW LEDs Diffuser cap Locking knob Tilt-adjustment knob 120 V AC/DC power adapter AC power cable OctaLux LED - USER MANUAL... - Page 7 Integrated Handle socket speed ring On/off Front dimmer knob DC power input diffuser socket Mounting socket OctaLux LED - USER MANUAL...
- Page 8 Inner diffuser Side A PRODUCT OVERVIEW Softbox tension-rod pockets 8 × tension rods Internal diffuser ringlets Side B OctaLux LED - USER MANUAL...
- Page 9 Touch-fastener strips 31.5˝ (80 cm) OctaLux softbox Spacer Access flaps OctaLux light-head handle OctaLux LED - USER MANUAL...
-
Page 10: Assembling The Softbox
ASSEMBLING THE SOFTBOX 1. Place the OctaLux light head faceup on a flat surface 2. Open the access flaps on the back of the OctaLux softbox, place the softbox around the light head. It will take shape with the following steps. 3. - Page 11 6. Insert the next two rods at a 90° angle from the first two rods that were inserted. This time insert each additional rod into a socket on the speed ring, and then into a pocket on the softbox. 7. Insert the remaining rods, one opposite the next.
-
Page 12: Attaching The Diffusers
ATTACHING THE DIFFUSERS The diffusers soften the light output and can be used separately or in combination for varying results. 1. Stretch the diffuser cap over the LED light head’s built-in reflector dish. 2. Attach the inner diffuser to the ringlets hanging on the inside of the softbox. - Page 13 3. Stretch the front diffuser over the outside edge of the softbox, aligning the touch-fastener strips. 4. Press the touch-fastener strips together, and make certain that the diffuser fits tightly on all sides. OctaLux LED - USER MANUAL...
-
Page 14: Mounting The Octalux
MOUNTING THE OCTALUX The OctaLux mounts to most light stands that have a standard 5/8˝ stud. 1. Make sure the tilt adjustment knob is fully tightened. Tilt Adjustment Locking Knob Knob 2. Loosen the locking knob on the mounting socket, and mount the OctaLux LED Light on your light stand. -
Page 15: Powering The Octalux
POWERING THE OCTALUX Make sure the unit is turned off. Connect the AC power cable to the AC/DC adapter and a wall outlet. Connect the adapter’s DC connector to the OctaLux light. To turn on the OctaLux light, turn the On/off dimmer control clockwise until you hear a click. -
Page 16: Disassembling The Softbox
DISASSEMBLING THE SOFTBOX 1. Ensure that the power control on 6. Remove the diffuser cap if attached. the back of the light head is turned 7. Remove the OctaLux light-head handle to the Off position. Unplug the by rotating it counterclockwise until you power cord from the wall outlet. -
Page 17: Specifications
PRODUCT SPECIFICATIONS OctaLux LED Light source: CRI: 240 LEDs Lamp life: Dimming: 50,000 hr. 10%–100% Luminance @ 3´ 1 m: Softbox diameter: 2000 lx – no diffusers 31.5˝ (80 cm) 1500 lx – with front diffuser only AC operating voltage: 100–240 V, 50/60 Hz 1800 lx –... -
Page 19: Warranty
ONE-YEAR LIMITED WARRANTY This Genaray product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. Genaray’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at Genaray’s discretion, of... - Page 20 OctaLux LED - USER MANUAL...
