- Page 1 Installation and Maintenance Manual MRPW-03 Performa Winch 70.2 STP ™...
-
Page 2: Table Of Contents
Outline Installation Installation procedure Positioning the self-tailing arm Maintenance Washing Maintenance table Disassembly procedure Exploded view with maintenance products Assembly Harken limited worldwide warranty ® Ordering spare parts Exploded view Parts list 70.2 STP Installation and Maintenance Manual Performa Winch... -
Page 3: Introduction
® In case of doubt the Harken Tech Service is at your disposal at techservice@harken.it This Manual is available only in English. If you do not fully understand the English language, do not carry out the operations described in this Manual. -
Page 4: Installation
It is the installer's responsibility to carry out all structural tests needed to ensure that the deck can bear the load. ® Harken does not supply the screws needed to install the winch since these may vary depending on the deck on which it is to be installed. - Page 5 Procedure To install the winch you must remove the drum and use Socket Head (SH) bolts or Hexagonal Head (HH) bolts. Tools needed One medium flat-bladed screwdriver To identify the various parts, refer to the exploded view at the end of this Manual. Torque to apply when assembling Follow steps below only to install the winch using Socket Head (SH) bolts 2.
- Page 6 Follow steps below only to install the winch using hexagonal headed bolts 6. Completely unscrew the three screws n° 26 7 . Remove the stripper arm housing n°21 8. Slide out the central shaft n°19 9. Unscrew the 6 hex screws n°17 ( 20Nm/177 in-lb) Install the winch on the deck in the position you have chosen, keeping in...
-
Page 7: Installation Procedure
B. Remove the winch and drill the six 8.5 mm diameter holes. ® C. Bolt the base of the winch to the deck using five M8 bolts (not supplied by Harken ), correctly chosen for the thickness and type of the boat deck. Consult the yard that built the boat in case of doubt. -
Page 8: Positioning The Self-Tailing Arm
Installation and maintenance of winches must be carried out exclusively by specialized personnel. In the case of doubt contact Harken ® Tech Service at techservice@harken.it... - Page 9 To identify the various parts refer to the exploded view at the end of this Manual. Carry out procedure as shown in the paragraph on winch installation and then do the following: 6. Completely unscrew the three screws n° 26 7.
- Page 10 12. Remove gear n°2. 13. Remove the idler and pinion n°14. 14. Remove roller bearings n°15 15. Remove pawls n°11. 16. Remove gear n°10 17. Remove roller bearings n°12. 70.2 STP Installation and Maintenance Manual Performa Winch ™...
- Page 11 If it is necessary to replace any jaws of the winch, proceed as follows: II. Remove the jaws n°22 I. Unscrew the 4 screws n°24 ( 4Nm/35 in-lb) Inspect balls inside the drum and carefully check the correct position; if it is necessary to put back any balls, push balls in the race (as shown below): Once the winch is completely disassembled, clean the parts: use a basin of diesel oil to soak metal components and rinse plastic parts in fresh water.
-
Page 12: Exploded View With Maintenance Products
Exploded view with maintenance products Anti-seize Harken ® Grease Harken ® Pawl Oil Apply Harken grease on assy socket screw ® 70.2 STP Installation and Maintenance Manual Performa Winch ™... -
Page 13: Assembly
Hold the spring closed and slide the pawl into its housing. Once in position, check that the pawls can be easily opened and closed with a finger. In case of doubt concerning the assembly procedure contact Harken ® Tech Service: techservice@harken.it 70.2 STP... -
Page 14: Harken ® Limited Worldwide Warranty
Limited Worldwide Warranty in the Harken ® Catalogue and on the website www.harken.com Ordering spare parts ® Spare parts can be requested from Harken ® described in the Harken Limited Worldwide W XXXXX Warranty, indicating the part number in the... -
Page 15: Exploded View
Exploded view 1/2 70.2 STP Installation and Maintenance Manual Performa Winch ™... - Page 16 Exploded view 2/2 70.2 STP Installation and Maintenance Manual Performa Winch ™...
-
Page 17: Parts List
Assy Housing WInch 70 M0614303 Screw M8x20 UNI 6109 Housing W70 Heli-coil M6x9 Support Bushing W70 S415580085 Bushing Ø12xØ35x9 S4130900A7 Bushing Ø22xØ25x8.5 *Available with service kit; see website www.harken.com **Winch product sticker 70.2 STP Installation and Maintenance Manual Performa Winch ™...
