Falcon RM70 Installation Instructions

Installation Instructions
1. Prepare frame header for filler or adapter plate.
Install filler or adapter plate and top bracket.
For RM70 and RM170, see Figures 1 and 2.
(Filler, filler mounting screws, and bracket
mounting screws by others.)
For RM70A and RM170A, see Figures 3 and 4.
2. Prepare floor and threshold for bottom bracket.
Install bottom bracket (Figures 5 and 6, other
side).
3. Cut mullion to length from top (Figures 7 and 8,
other side).
4. Slide mullion over top fitting and swing into
position on bottom fitting (Figure 9, other side).
5. Slide mullion clamp over top fitting and secure
with three screws (Figure 10, other side).
6. Install security clips on door (Figure 11, other
side).
Customer Service
1-877-671-7011
Filler (by
others)
Top bracket
location
1-5/8"
View
looking up
Figure 1. Header and filler preparation for top
bracket (RM70 and RM170).
Filler (by others) flush
with stop, centered on
center line of doors
Figure 2. Filler and top bracket installation (RM70
RM70, RM70A, RM170, and RM170A
© Allegion 2016
Printed in U.S.A.
www.allegion.com/us
4270108237 Rev. 12/16-f
Door
Drill and tap header and filler
for 10-32 screws, 3 places
Door
doors
Door
9/16"
1-11/16"
2-3/4"
doors
10-32 x 1/2" FPHMS
(by others)
and RM170).
Removable Mullions
PAGE NO.
1 of 2
Adapter plate
Prepare header for #10 x 1"
FPHSMS, 4 places
1-1/2"
2-1/4"
1-1/8"
Adapter
plate location
View looking up
Figure 3. Header preparation for adapter plate
(RM70A and RM 170A).
Adapter plate
#10 x 1" FPHMS
4 places
Install top bracket to
adapter plate with three
10-32 x 1/2" FPHMS
Figure 4. Adapter plate and top bracket
installation (RM70A and RM170A).
REVISION
4270108237
F
Door
Door
doors
Door
11/32"
1-27/32"
