2.3 Linking the PIM-485-16-TD-NXT to WAPMs

2.3.1 How to Set an RF Channel
One of fifteen RF channels can be set using DIP switch SW7 on the PIM. Table 2-5 shows how to set
SW7 to select the desired RF channel:
Channel
NOTE: The first two switch settings select Channel 1.
2.3.2 Linking WAPM's using the Configuration & Demonstration Tool (CDT)
The Schlage CDT can be used to link WAPM's to a PIM-485-16-TD-NXT. Refer to the CDT
The PIM-485-16-TD-NXT must be connected to the PC running the CDT using a serial connection
(either RS485 or RS232).
Once the PIM-485-16-TD-NXT is connected to the PC and the CDT is running the Link tab on the
CDT's PIM panel is used to control the PIM-485-16-TD-NXT's Link Mode. The Panel field needs to
be set to indicate which WAPM is to be linked. Table 2-6 shows the allowable range of values for the
Panel field on the CDT Link tab.
575 Birch St., Forestville, Connecticut 06010 / (860) 584-9158 / (860) 584-2136 fax
P/N: M053-016-A
Switch 1 Switch 2
1
up
1
up
2
up
3
up
4
up down
5
up down
6
up down
7
up down
8
down
9
down
10
down
11
down
12
down down
13
down down
14
down down
15
down down
Table 2-5 – DIP Switch Setting to Select the RF Channel
PIM Model
PIMx-485-16-NEX
Table 2-6 – CDT Panel Field Range of Values
IR Security & Safety
http://www.irsupport.net
Switch 3 Switch 4
up up Up
up up down
up down Up
up down down
up Up
up down
down Up
down down
up up Up
up up down
up down Up
up down down
up Up
up down
down Up
down down
Panel Field
0-15
Page 11 of 15
