R
PIM-485-16-TD-NXT
EAD FIRST WHEN INSTALLING A
Addendum
INSTALLING , CONFIGURING & OPERATING
PANEL INTERFACE
MODULE
RS485
NexSentry Star I/II Version
(PIM-485-16-TD-NXT)
The most current version of this document is available for download at:
http://www.irsupport.net
IR Security & Safety
575 Birch St.
(866) 322-1237
(866) 322-1233 fax
P/N: M053-016-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Panel Interface Module RS485 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Schlage Panel Interface Module RS485

Summary of Contents for Schlage Panel Interface Module RS485

  • Page 1 PIM-485-16-TD-NXT EAD FIRST WHEN INSTALLING A Addendum INSTALLING , CONFIGURING & OPERATING PANEL INTERFACE MODULE RS485 NexSentry Star I/II Version (PIM-485-16-TD-NXT) The most current version of this document is available for download at: http://www.irsupport.net IR Security & Safety 575 Birch St. (866) 322-1237 (866) 322-1233 fax P/N: M053-016-A...
  • Page 2 575 Birch St. Forestville, Ct 06010 (866) 322-1237 (866) 322-1233 Fax World Wide Web http://www.irsupport.net Copyright © 2003-2004 Ingersoll-Rand, all rights reserved. No part of this document can be reproduced, transmitted, or transcribed in any form by electrical, mechanical, optical, manual, or otherwise without the prior written consent of Ingersoll-Rand.

  • Page 3: Table Of Contents

    Linking the PIM-485-16-TD-NXT to WAPMs ...11 PIM-485-16-TD-NXT Card Formats...12 PIM-485-16-TD-NXT Alarms...12 What Happens if the PIM-485-16-TD-NXT Loses DC Power...12 Using the PIM-485-16-TD-NXT Reset Switch ...12 Contacting Schlage ...13 FCC Compliance & Warnings...14 FCC Compliance ...14 Warnings...14 Revision History...15 575 Birch St., Forestville, Connecticut 06010 / (860) 584-9158 / (860) 584-2136 fax P/N: M053-016-A IR Security &...

  • Page 4: Wyreless Access™ System (Was)

    1. Wyreless Access™ System (WAS) 1.1 Overview Every access control system that uses Wyreless Access 1-1): • at least one Wyreless Panel Interface Module (WPIM), and • at least one Wyreless Access Point Module (WAPM) Figure 1-1 – Wyreless Access System Block Diagram The WPIM is wired to the access control panel and ideally is installed very close to the access control panel.

  • Page 5: Panel Interface Module-Rs485-Nexsentry (Pim-485-16-Td-Nxt)

    Each PIM-485-16-TD-NXT can emulate up to 16 DR42xx DigiReaders, therefore a PIM-485-xx-NEX can control from 1 to 16 WAPM’s (1 to 8 for a Star I). The Schlage Configuration & Demonstration Tool (CDT) is used to determine what RS-485 polling addresses each PIM-485-16-TD-NXT will emulate.
  • Page 6 The PIM-485-16-TD-NXT can be ordered with one of three possible enclosures. The xx in the PIM-485- 16-TD-NXT sales model number indicates the maximum number of WAPM’s that can be controlled by that sales model. Table 1-1 & Table 1-2 shows the PIM-485-16-TD-NXT sales model and its major specifications.
  • Page 7 MODEL ENCLOSURE PIM-485-16-TD-NXT ANT-REMOTE ANT-6DB-FLAT Table 1-2- PIM-485-16-TD-NXT Sales Model Table 575 Birch St., Forestville, Connecticut 06010 / (860) 584-9158 / (860) 584-2136 fax P/N: M053-016-A MAXIMUM NUMBER LOCATION OF WAPMs plastic indoor indoor plastic outdoor indoor plastic outdoor IR Security & Safety http://www.irsupport.net ACCESS CONTROL PANEL INTERFACE/DESCRIPTION...

  • Page 8: Installing The Pim-485-16-Td-Nxt

    2. Installing the PIM-485-16-TD-NXT 2.1 Configuring the PIM-485-16-TD-NXT to Emulate DR42xx DigiReaders The Schlage Configuration & Demonstration Tool (CDT, version 1.4 or higher) must be used to configure each PIM-485-16-TD-NXT to emulate the desired number and address of DR42xx DigiReaders.
  • Page 9 ADDR/READER MIRO Table 2-2 - PIM, MIRO, Reader, Point Number Association for one PIM 575 Birch St., Forestville, Connecticut 06010 / (860) 584-9158 / (860) 584-2136 fax P/N: M053-016-A Point Numbers Door Position Switch Request to Exit IR Security & Safety http://www.irsupport.net Strike Relay Page 9 of 15...

  • Page 10: Connecting The Pim-485-16-Td-Nxt To A Star I/Ii Access Control Unit

    2.2 Connecting the PIM-485-16-TD-NXT to a Star I/II Access Control Unit Note: Make certain that that Star I/II Terminal Block TB1 is configured for the S-NET communication protocol. 2.2.1 PIM-485-16-TD-NXT using an Original PIM PCB Star I/II – TB1 Table 2-3 – RS485 Connection: Original PIM PCB & RAMM 2.2.2 PIM-485-16-TD-NXT using a RS485 PIM PCB Star I/II –...

  • Page 11: Linking The Pim-485-16-Td-Nxt To Wapms

    2.3.2 Linking WAPM’s using the Configuration & Demonstration Tool (CDT) The Schlage CDT can be used to link WAPM’s to a PIM-485-16-TD-NXT. Refer to the CDT The PIM-485-16-TD-NXT must be connected to the PC running the CDT using a serial connection (either RS485 or RS232).

  • Page 12: Pim-485-16-Td-Nxt Card Formats

    2.4 PIM-485-16-TD-NXT Card Formats The PIM-485-16-TD-NXT accepts a 26 bit Wiegand format, strips off the two parity bits and the eight bit facility code field, the resulting 16 bit card number field is sent to the STAR I/II controller for further processing.

  • Page 13: Contacting Schlage

    3. Contacting Schlage For questions regarding Wyreless Access™: customerservice@recognition-source.com sales@recognition-source.com techsupport@recognition-source.com www.recognition-source.com (630) 762-4450 (630) 762-4444 fax IR Security & Safety 575 Birch St., Forestville, Connecticut 06010 / (860) 584-9158 / (860) 584-2136 fax P/N: M053-016-A http://www.irsupport.net Page 13 of 15...

  • Page 14: Fcc Compliance & Warnings

    - the product emits a strange smell, heat, or smoke. • Changes or modifications not expressly approved by Schlage, could void the users authority to operate the equipment. 575 Birch St., Forestville, Connecticut 06010 / (860) 584-9158 / (860) 584-2136 fax P/N: M053-016-A IR Security &...

  • Page 15: Revision History

    5. Revision History Version Date Changes X001 07/03/02 preliminary in house release for comments X001.1 09/06/02 updated Configuring and Linking sections for new CDT version 09/12/02 released for publication 01/13/04 added Star II/PIM/CDT addressing information/rules, removed obsolete sales models, added new sales model PIM-485-16-TD-NXT, added card format section 575 Birch St., Forestville, Connecticut 06010 / (860) 584-9158 / (860) 584-2136 fax P/N: M053-016-A IR Security &...
