IMPACT WRENCH
Butterfly
Stock Number M562DB
OWNER'S MANUAL
FOR YOUR SAFETY,
please read these instructions carefully and retain them for future use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M562DB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Performance Tool M562DB

  • Page 1 IMPACT WRENCH Butterfly Stock Number M562DB OWNER'S MANUAL FOR YOUR SAFETY, please read these instructions carefully and retain them for future use.
  • Page 2 SPECIFICATIONS Square Drive (IN.) ......3/8 Working Torque (FT. /LBS) ..20-75 Air Pressure (PSI) ......90 Average Air Consumption (CFM) ..3 Specifications are Free Speed (RPM) ......11000 subject to change without notice Bolt Capacity (IN.) ......3/8 Air Inlet (NPT) ......1/4 in. Hose Size (ID)......
  • Page 3 Failure to do so can lead to accidents for the operator. Use of any other parts will void the warranty. Only use accessories intended for use with this tool. Approved accessories are available from Performance Tool®. Use only accessories that are recommended by the manufacturer for your model.
  • Page 4 OPERATION 1. To set the tool to desired torque, select a nut or screw of known tight- ness of the same size, thread pitch and thread condition as those on the job. 2. Turn air regulator to low position, apply wrench to nut and gradually increase power (turn regulator to admit more air) until nut moves slightly in the direction it was originally set.
  • Page 5 LUBRICATION & MAINTENANCE Warning! Oil tool before each use. 4 to 5 drops of a good grade Air Tool Oil placed in the air inlet is sufficient. Use proper air pressure and CFM rating listed for this tool. Drain water from hoses and compressor tank. Water in the air supply line will cause gumming and loss of power.
  • Page 6 REPLACEMENT PARTS LIST Part # Description Quantity – Housing – Anvil Bushing M562K-01 Anvil Collet M562K-01 O-Ring M562K-01 Anvil – Hammer Pin M562K-01 Hammer Dog M562K-01 Drive Cam – Hammer Cage – Screw – Trigger Pin – Trigger Pin M562K-01 Front Bearing –...
  • Page 7 REPLACEMENT PARTS LIST...
  • Page 8 90 days from the date of purchase, provided that product is returned to place of purchase immediately after discovery of defect. After 90 days and up to one year from date of purchase, PERFORMANCE TOOL®...
