1/2 in. dr. air impact wrench

Advertisement

Quick Links

1/2 in. Dr. Air Impact Wrench
Stock Number M558DB
OWNER'S MANUAL

SPECIFICATIONS:

Drive Size (IN.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/2
Max Torque (FT/LBS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230
Working Torque (FT/LBS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50-200
Air Pressure (P.S.I.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Average Air Consumption (C.F.M.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Free Speed (R.P.M.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7,500
Air inlet (N.P.T.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/4
Hose size (I.D.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/8 in.
Weight (LBS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4.4
Specifications are subject to change without notice.
WARNING!
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND WARNINGS BEFORE
OPERATING THIS TOOL. FAILURE TO DO SO MAY RESULT IN PERSONAL INJURY
AND/OR PROPERTY DAMAGE AND WILL VOID WARRANTY.
Some dust created by power sanding contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. An example of
this type of chemical is lead from lead based paints. Your risk from these exposures varies, depending on how often you do this type of work. To reduce your expo-
sure: work in a well ventilated area and work with approved safety equipment, such as dusk masks that are specially designed to filter out microscopic particles.
P.O. Box 88259 Tukwila, WA 98138 • 1-800-497-0552 • www.wilmarcorp.com • Made in China • © Copyright 2010

Advertisement

loading
Need help?

Need help?

Do you have a question about the m558db and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Performance Tool m558db

  • Page 1: Specifications

    1/2 in. Dr. Air Impact Wrench Stock Number M558DB OWNER’S MANUAL SPECIFICATIONS: Drive Size (IN.) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1/2 Max Torque (FT/LBS) .
  • Page 2 IMPORTANT SAFETY INFORMATION WARNING! READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND WARNINGS BEFORE OPERATING THIS TOOL. FAILURE TO DO SO MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE AND WILL VOID WARRANTY. 1. Keep work area clean. Cluttered areas invite injuries. 2.
  • Page 3 5. If fastener bogs, slows or binds the tool, or if the fastener fails to move after 5 seconds, accessories are available from Performance Tool®. Use only accessories that are use a larger size impact wrench with a higher torque rating. Overloading this tool will recommended by the manufacturer for your model.
  • Page 4 After 90 days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which our examination shall disclose to be defective and under warranty. These warranties shall be valid only when a sales receipt showing the date of purchase accompanies the defective product or defective part (s) being returned.
