- Page 1 USER’S MANUAL TP1043 02 series HMI – Operator panel ME7056_07 10/18...
-
Page 3: Table Of Contents
HMI - Operator panel: TP1043 02 Mect srl INDEX 1. Introduction ......................1 1.1. Staff skill ......................1 1.2. Simbols ....................... 1 1.3. Terms ......................... 2 1.4. Security ......................2 1.5. REFERENCE MANUAL .................. 2 2. System description ....................3 2.1. -
Page 4: Introduction
Products described in this manual are devoted to PLC programmers or automation experts only. MECT S.r.l. declines any responsibility about malfunctioning or damage caused by incorrect use of MECT devices, due to noncompliance to this manual information. MECT S.r.l has an help desk. -
Page 5: Terms
HMI - Operator panel: TP1043 02 Mect srl 1.3. Terms PLC: TP1043 02 Terminals: MPNC005, MPNC010, MPNC020, MPNC030, MPNC035 System: PLC (TP1043 02) with terminals 1.4. Security Attention Switch off devices before connecting them. ESD (Electrostatic discharge) Modules have electronic components that can be damaged by. -
Page 6: System Description
HMI - Operator panel: TP1043 02 Mect srl 2. System description TP1043 02 is a device composed by a PLC and a HMI with touch-screen monitor 4.3” width and 480 x 272 pixel resolution with 262.000 colors. TP1043 02 allows the supervision of networked devices Modbus RTU and Modbus TCP. -
Page 7: Specification
HMI - Operator panel: TP1043 02 Mect srl 2.1. Specification TP1043 02 is based on a multiprocessor system. PLC and HMI are based on a 454MHz ARM9. Table 1 Hardware characteristics PLC Processor ARM926JE 454MHz 128MB FLASH 128MB Non volatile variables... -
Page 8: Mechanical Dimensions
HMI - Operator panel: TP1043 02 Mect srl 3. Mechanical dimensions In the following figures see the TP1043 dimensions. Panel with frame mounting and hooks fastening: Encumbrance Front view Side view Mounting plate ME7056_07 10/18... - Page 9 HMI - Operator panel: TP1043 02 Mect srl Panel with frame mounting and screws fastening: Encumbrance Front view Side view Mounting plate ME7056_07 10/18...
- Page 10 HMI - Operator panel: TP1043 02 Mect srl Panel without frame mounting: To mount it is necessary that the display is at the same panel height, so for metal panels below 2,5mm it is necessary to insert a shim to reach the exact quote.
-
Page 11: Panel Mount
HMI - Operator panel: TP1043 02 Mect srl 3.1. Panel mount 3.1.1. Distance System must be installed with a space for heat dissipation and cabling. Avoid cabling superimposing to avoid EMC problems. Figure 6A: Horizontal mounting Figure 6B: Vertical mounting... -
Page 12: Tp1043 02 Wiring
HMI - Operator panel: TP1043 02 Mect srl 4. TP1043 02 wiring 4.1. Connections In the following figure see the wiring diagram. Figure 7 Table 3 TP1043 02 Power Supply 24VDC 12÷36Vdc - 150mA (24Vdc) Power Supply 24VAC 24Vac ±20% - 150mA... -
Page 13: Fuse
HMI - Operator panel: TP1043 02 Mect srl 4.2.3. Fuse System has no internal fuse, so the use of an external 500mA fuse for the panel power supply is recommended. Figure 8 Attention A wrong value for the power supply can cause a damage to the device 4.3. -
Page 14: Canopen Wiring
HMI - Operator panel: TP1043 02 Mect srl Figure 9 4.4. CANOpen wiring The CANopen interface on TP1043 02 must be connected to the terminal block on the pins shown in the table. Table 5 Signal Description GNDiso CAN L... -
Page 15: Peripherals
HMI - Operator panel: TP1043 02 Mect srl 24Vdc CANOpen 24Vdc/Vac MPNC010 MPNC030 Figure 10 5. Peripherals 5.1. TP1043 02 has a Micro-USB 2.0 host for: software update data storage: datalogger connect USB peripherals as printers, mouse, etc. -
Page 16: Hmi
System variables The system can use 5472 interchange variables between HMI and automation (at maximum) which include: internal variables, interchange variables on Modbus network, retentive variables. The variables are defined by a software “Mect Suite”. 7. How to order ME7056_07 10/18...
