Mect TPAC1008 Series User Manual

Operator panel

Advertisement

Quick Links

USER'S MANUAL for
TPAC1008 series
Operator panel
ME7030_05
04/16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPAC1008 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Mect TPAC1008 Series

  • Page 1 USER’S MANUAL for TPAC1008 series Operator panel ME7030_05 04/16...
  • Page 2 TPAC1008 Operator panel Mect srl ME7030_05 04/16...
  • Page 3: Table Of Contents

    TPAC1008 Operator panel Mect srl INDEX 1. Introduction ......................1 1.1. Staff skill ......................1 1.2. Simbols ....................... 1 1.3. Terms ......................... 1 1.4. Security ......................2 1.5. Reference manuals ..................... 2 2. System description ....................2 2.1. Specification....................... 4 3.
  • Page 4: Introduction

    Products described in this manual are devoted to PLC programmers or automation experts only. MECT S.r.l. declines any responsibility about malfunctioning or damage caused by incorrect use of MECT devices, due to noncompliance to this manual information. MECT S.r.l has an help desk.
  • Page 5: Security

    TPAC1008 Operator panel Mect srl 1.4. Security Attention Switch off devices before connecting them. ESD (Electrostatic discharge) Modules have electronic components that can be damaged by. electrostatic discharge. Be sure to be connected to ground when handle the devices. The instrument has no power switch and no internal fuse, but it powers on immediately after connecting a correct power supply input (check the power supply value on the instrument label).
  • Page 6 TPAC1008 Operator panel Mect srl Figure 1: Front view TPAC1008 (horizontal version) Figure 2: Front view TPAC1008 (vertical version) ME7030_05 04/16...
  • Page 7: Specification

    TPAC1008 Operator panel Mect srl 2.1. Specification TPAC1008 is based on a multiprocessor system. PLC and HMI are based on a 454MHz ARM9, I/O interface and I/O acquisition is based on a Cortex M3 processor. The 2 systems on different boards communicate over a CAN channel.
  • Page 8: Hardware Installation

    TPAC1008 Operator panel Mect srl 3. Hardware Installation In the following figures see the TPAC1008 dimensions. 3.1. Mechanical dimensions Side view Rear view Figure 3 Figure 4 Side view Figure 5 ME7030_05 04/16...
  • Page 9 TPAC1008 Operator panel Mect srl Technical specification Table 2 Mechanical Material Polycarbonate, Polyamide 6.6 Dimensions W x L x H 195 mm x 145 mm x 60.5 mm Mounting plate 139mm x 189mm Installation Panel installation Environmental conditions Operative temperature 0 °C ...
  • Page 10 TPAC1008 Operator panel Mect srl EN 55011 (AC supply, 73 dB (µV) 500 kHz ... 30 conducted) EN 55011 (radiated) 40 dB (µV/m) 30 MHz ... 230 10 m 47 dB (µV/m) 230 MHz ... 1 10 m Emissions according to EN 61000-6-3 (2001)
  • Page 11: Panel Mount

    TPAC1008 Operator panel Mect srl 3.2. Panel mount 3.2.1. Distance System must be installed with a space for heat dissipation and cabling. Avoid cabling superimposing to avoid EMC problems. Figure 6A: Horizontal mounting Figure 6B Vertical mounting ME7030_05 04/16...
  • Page 12: Tpac1008 Wiring

    TPAC1008 Operator panel Mect srl 4. TPAC1008 wiring 4.1. Connections In the following figure see the wiring diagram with the available I/O. Figure 7: Pinout PLC M4 connection terminal is the expansion board terminal, and can be different according to different available models.
  • Page 13 TPAC1008 Operator panel Mect srl Table 3 TPAC1008 01 Input type Resolution Note 0.01mA 420 mA Input impedance 9 0.005V 0V Input impedance 1M thermocouples 1°C Cold junction J(0°C – 600°C), compensation T(0°C – 400°C), Analogue input N° 4 K(0°C – 1200°C) PT100 r -40.0°C...
  • Page 14: Power Supply

    TPAC1008 Operator panel Mect srl 4.2. Power supply 4.2.1. Isolation Device has no galvanic isolation between input, output and power supply. 4.2.2. System power supply TPAC1008 has a 24VDC (-15% +20 %) according to the scheme in the figure. System is protected against reverse power supply.
  • Page 15: Digital Input/Output Wiring

    TPAC1008 Operator panel Mect srl 4.3. Digital input/output wiring The digital I/Os are PNP type, the wiring must follow the scheme below. Figure 9 Each digital output can source a 500mA max, and the total current can be lower than 4.4.
  • Page 16 TPAC1008 Operator panel Mect srl thermocouple Figure 10 TPAC1008 can be connected to PT100. 2 different scales are possible:  –40.0 °C to 200.0°C  –40 °C to 800°C The scale –40.0°C to 200.0°C has a resolution of 0.1°C. The scale –40°C to 800°C has a resolution of 1°C.
  • Page 17: Analogue Output Wiring

    TPAC1008 Operator panel Mect srl Configuring input as 0V or 4m is possible to connect up to 4: Figure 12 4.5. Analogue output wiring 2 analogue output channels are available. See in the figure the current analogue output wiring. Figure 13...
  • Page 18: Canopen Wiring

    TPAC1008 Operator panel Mect srl See in the figure the voltage analogue output wiring. Figure 14 4.6. CanOpen wiring Can interface on TPAC1008 is on M1 terminal board on pins: Table 4 Segnale CAN H CAN L Example of a wiring of a system composed by: ...
  • Page 19 TPAC1008 Operator panel Mect srl Figure 15 Cable type Cable between TPAC1008 and CANopen slave must be a shielded twisted pair, and to avoid external disturbances the shield must be connected to both 0V of the communicating systems. The cable length is a function of the baud rate as follows.
  • Page 20: Modbus Wiring

    TPAC1008 Operator panel Mect srl 4.7. ModBus wiring ModBus on TPAC1008 is a 4 wire RS485 serial line, on the M2 terminal board on pins: Table 6 Segnale Description TX + Line + Tx TX - Line - Tx RX +...
  • Page 21: Peripherals

    TPAC1008 Operator panel Mect srl 5. Peripherals 5.1. TPAC1008 has an USB 2.0 host for:  software update.  data storage: datalogger.  Connect USB peripherals as printers, mouse, etc. Specific connection of external peripherals are implemented on request. 5.2.
  • Page 22: System Variables

    TPAC1008 Operator panel Mect srl 6.1. System variables Here some system variables available for PLC program. Table 8 Variable name Number Type Description UINT Firmware revision PLC_StatusReg UINT Analogue input configuration: PLC_AnInConf_1  0 not configured PLC_AnInConf_2  1 current PLC_AnInConf_3 ...
  • Page 23 After that the variables are available in read / write mode as described in the program tutorial. The system can use 5472 interchange variables between HMI and automation (at maximum) which include: internal variables, interchange variables on Modbus network, retentive variables. The variables are defined by a software “Mect Suite”. ME7030_05 04/16...
