- Page 1 USER’S MANUAL TP1043 02 series HMI – Operator panel ME7056_11 07/21...
-
Page 3: Table Of Contents
HMI - Operator panel: TP1043 02 Mect srl INDEX 1. Introduction ......................1 1.1. Staff skill ......................1 1.2. Simbols ....................... 1 1.3. Terms ......................... 1 1.4. Security ......................2 1.5. Reference Manual ....................2 2. System description ....................3 2.1. -
Page 4: Introduction
Products described in this manual are devoted to PLC programmers or automation experts only. MECT S.r.l. declines any responsibility about malfunctioning or damage caused by incorrect use of MECT devices, due to noncompliance to this manual information. MECT S.r.l has an help desk. -
Page 5: Security
HMI - Operator panel: TP1043 02 Mect srl 1.4. Security Attention Switch off devices before connecting them. ESD (Electrostatic discharge) Modules have electronic components that can be damaged by. electrostatic discharge. Be sure to be connected to ground when handle the devices. -
Page 6: System Description
A Micro-USB host port allows, with a special adapter, the use of an USB-pen drive for software updates and data log. Through a GPRS/UMTS or Wi-Fi key (optionally sold by Mect) is possible to connect the operator panel to a Wi-Fi or Mobile network. Settings under MENU OPTIONS NETWORK_CFG tab “Wi-Fi”... -
Page 7: Specification
HMI - Operator panel: TP1043 02 Mect srl 2.1. Specification TP1043 02 is based on a multiprocessor system. PLC and HMI are based on a 454MHz ARM9. Table 1 Hardware characteristics PLC Processor ARM926JE 454MHz 128MB FLASH 128MB Non volatile variables... -
Page 8: Mechanical Dimensions
HMI - Operator panel: TP1043 02 Mect srl 2.2 Mechanical dimensions In the following figures see the TP1043 dimensions. Panel with frame mounting and hooks fastening: Encumbrance Front view Side view Mounting plate ME7056_11 07/21... - Page 9 HMI - Operator panel: TP1043 02 Mect srl Panel with frame mounting and screws fastening: Encumbrance Front view Side view Mounting plate ME7056_11 07/21...
- Page 10 HMI - Operator panel: TP1043 02 Mect srl Panel without frame mounting: In this case, the display has to be exactly at the same height of the panel, so for metal panels below 2,5mm it needs to insert a spacer to reach the exact height.
-
Page 11: Panel Mount
HMI - Operator panel: TP1043 02 Mect srl 2.3 Panel mount 2.3.1 Distance The device must be installed with some space between other devices to allow the right dissipation and cabling. In order to avoid EMC issues, you should not overlap cables. -
Page 12: Tp1043 02 Wiring
HMI - Operator panel: TP1043 02 Mect srl 2.4 TP1043 02 wiring 2.5 Connections In the following figure see the wiring diagram. Figure 7 Table 3 TP1043 02 Power Supply 12÷36Vdc - 150mA (24Vdc) or 24Vac ±20% - 150mA 24Vdc/Vac... -
Page 13: Power Supply
HMI - Operator panel: TP1043 02 Mect srl 2.6 Power supply 2.6.1 System power supply TP1043 02 has a 12÷36Vdc or 24Vac (see the model purchased) according to the scheme in the figure. System is protected against reverse power supply. -
Page 14: Modbus Wiring
HMI - Operator panel: TP1043 02 Mect srl 2.7 ModBus wiring ModBus on TP1043 02 is a 2 wire RS485 serial line, at the following pins of the terminal board: Table 4 Signal Description GNDiso / GND Linea + Linea - Example of wiring for a system composed by: ... -
Page 15: Canopen Wiring
HMI - Operator panel: TP1043 02 Mect srl 2.8 CANOpen wiring The CANopen interface on TP1043 02 must be connected to the terminal block on the pins shown in the table. Table 5 Signal Description GNDiso CAN H Line +... -
Page 16: Peripherals
data storage: datalogger USB peripherals as printers, mouse, etc Wi-Fi or Mobile key interface (optionally supplied by Mect) to connect to a different network from LAN Specific connection of external peripherals are implemented on request. 3.2 Ethernet TP1043 02 has a 10/100Mbit/s ethernet port with auto-configuration, the connection cable between TP1043 02 and a personal computer can be either straight either cross. -
Page 17: Uart Debug
HMI - Operator panel: TP1043 02 Mect srl Switches configuration is shown in the following table Table 6 Boot mode Note Internal Flash (default) Default configuration Factory firmware upgrade do not use SD card SD card 3.5 UART debug In the bottom side of the rear panel there is a six pole header used for debug purpose. -
Page 18: Hmi / Plc
The use of this port is recommended for advanced users only. 4 HMI / PLC The device is programmed by a development suite (Mect Suite - QT based), tailored to MECT products. A tutorial specifically made for the device is available. -
Page 19: How To Order
HMI - Operator panel: TP1043 02 Mect srl 5 How to order ME7056_11 07/21...
