Ultra Champ I & II Adjustable Basketball System
Installation, Operation and Maintenance Instructions
Please read all instructions before attempting installation or operation of these units
SAVE THESE INSTRUCTIONS FOR FUTURE USE
P
N
.
UBLICATION
O
4 5 1 7 5 4 5 9 4
Models: GP8A60 & GP8G60
Advertisement
Related Manuals for Gared Sports Ultra Champ I
Summary of Contents for Gared Sports Ultra Champ I
- Page 1 Ultra Champ I & II Adjustable Basketball System Models: GP8A60 & GP8G60 Installation, Operation and Maintenance Instructions Please read all instructions before attempting installation or operation of these units SAVE THESE INSTRUCTIONS FOR FUTURE USE UBLICATION 4 5 1 7 5 4 5 9 4...
- Page 2 Ultra Champ Adjustable Basketball System Table of Contents Section Page No. Introduction Cautions and Warnings Parts Checklist Assembly and Setup 5-17 Unit Operation Note: The padding options shown below are purchased separately.
- Page 3 Ultra Champ Adjustable Basketball System Introduction Thank you for your purchase of a Gared Sports model Ultra Champ Adjustable backstop. To ensure that our equipment will provide years of use to you, we are including this installation, operation, and maintenance guide. This guide will provide information on the proper assembly and installation methods, operating procedures, and preventative maintenance of your portable backstop.
-
Page 4: Parts Checklist
Ultra Champ Adjustable Basketball System Parts Checklist Verify all parts listed on packing list are present prior to installation. The following parts have been packed separately Please refer to your packing slip to verify the correct board and goal has been received. Item Basic Items 5”... - Page 5 Ultra Champ Adjustable Basketball System Flat Washer (12mm) Lock Washer (12mm) Actuator Hardware 18mm dia. x 310mm long Hex Bolt 18mm dia. Nylon Locking Nut Flat Washer (18mm) Steel Bushing 1.0” o.d. x 5.0” long Plastic Bushing Spacers 16mm dia. x 128mm long Hex Bolt 16mm dia.
-
Page 6: Installation Instructions
Ultra Champ Adjustable Basketball System INSTALLATION INSTRUCTIONS Use the illustration below to assemble the template plate and J-bolts. - Page 7 Ultra Champ Adjustable Basketball System Dig and prepare the hole for anchoring the template plate and J-bolt assembly.
- Page 8 Ultra Champ Adjustable Basketball System Set the J-bolt assembly in concrete with the nut coupler towards the playing area.
- Page 9 Ultra Champ Adjustable Basketball System Use the following illustration to raise the main post (column) into position. Two strong people should be able to complete this process. The rest of the parts can then be added to complete the unit. NOTE: As an alternative, the whole unit could be assembled with the post lying down and then raised as the final process.
- Page 10 Ultra Champ Adjustable Basketball System Use the following steps to level and secure the main post.
- Page 11 Ultra Champ Adjustable Basketball System Unpack the backboard and mounting hardware. Attach the (4) mounting brackets with the nuts and bolts provided. NOTE: Vertical spacing will be 20” as shown.
- Page 12 Ultra Champ Adjustable Basketball System Unpack the goal and attachment hardware. Included should be the rim, the net, (4) bushings, bolts, nuts, washers, the cover plate and screws. Follow the steps below to mount the goal to the backboard. The net can be added at any time.
- Page 13 Ultra Champ Adjustable Basketball System The following illustration shows how to attach the LSCE60 Pro Mold Padding. Padding may be attached before or after backboard is mounted in final position.
- Page 14 Ultra Champ Adjustable Basketball System Assemble the (2) actuator brackets as shown in the illustration below. Attach the lower extension arm as shown below.
- Page 15 Ultra Champ Adjustable Basketball System This is the primary lifting and support arm for the backboard. Attach the height adjustment actuator to the brackets (bottom) and the extension arm (top) with the hardware shown in the detail views.
- Page 16 Ultra Champ Adjustable Basketball System Assemble the upper extension arms and attach to the top of the main post using the hardware shown in the detail views below.
- Page 17 Ultra Champ Adjustable Basketball System Attach the backboard to the extension arms using the hardware indicated in the detailed views below. This will require at least three strong persons with ladders. *Helpful hint* You could also accomplish this task by working...
- Page 18 Ultra Champ Adjustable Basketball System out of the bed of a truck which may provide a more stable base than ladders. Make sure you have enough help to complete this operation safely! Note: Height adjustment is continuously variable from 7’-6” to 10’-0”...
- Page 19 Ultra Champ Adjustable Basketball System...
- Page 20 Gared Holdings, LLC Performance Sports Systems Gared Sports 9200 E. 146 Street 707 North 2 Street Noblesville, IN 46060 St. Louis, MO 63102 800-848-8034 800-325-2682 www.perfsports.com www.garedsports.com...
