Techome TVL3 Quick Installation And Instruction Manual

DELETING THE MAX/MIN HEIGHT LIMITS
1. Adjust the TV Lift height to the
desired max or min height you wish
to delete. Using 'UP' or 'DOWN'.
OR
3. Hold 'UP' (For Max) or 'DOWN'
(For Min) on the Switch Box for 3 seconds
until you hear a continuous beep.
3 sec
SETTING A MEMORIZED HEIGHT
1. Adjust the TV Lift height to the
desired height. Using any remote.
OR
3. Pressing the 'M' button will now set
the TV Lift to the memorized height.
3
2. Flick the 'SET' switch to the right
on the Switch Box.
4. Return the 'SET' button back to
the left again to regain control of
the TV Lift.
2. Press and hold the 'M' button
on the RF Remote until you hear
three (3) beeps.
TECHOME TV LIFT (TVL3)
QUICK INSTALLATION AND
INSTRUCTION
MANUAL
www.techome.com.au
info@techome.com.au | +61 (0)7 3297 9797
