AUTOMATIC WATER TREATMENT SYSTEM
Instruction Manual
Chlorine Pool-Care System
for Pools up to 30,000 Gallons
Ver la versión en español de este manual en kingtechnology.com/knowledge-center/manuals-diagrams
SPARCO
Customer Service 800-222-0169
kingtechnology.com
WARNING
To minimize the risk of serious injury, death or
damage, before installing or first using this
equipment, read Instruction Manual and all safety
labels and follow all safety instructions and
precautions. Save manual for future reference.
1
Advertisement
Table of Contents
Related Manuals for King Technology 01-02-5510
Summary of Contents for King Technology 01-02-5510
- Page 1 SPARCO AUTOMATIC WATER TREATMENT SYSTEM Instruction Manual Chlorine Pool-Care System for Pools up to 30,000 Gallons Customer Service 800-222-0169 kingtechnology.com WARNING To minimize the risk of serious injury, death or damage, before installing or first using this equipment, read Instruction Manual and all safety labels and follow all safety instructions and precautions.
-
Page 2: Table Of Contents
Step 3: Setting the Control Dial Step 4: Routine Pool Care Winterizing Troubleshooting Parts List Maintenance - Replacing Control Dial O-Rings Maintenance - Replacing Cap O-Rings and Knobs Warranty For information on King Technology’s entire product line, visit our website at kingtechnology.com... -
Page 3: Sparco Introduction
The water treatment center that controls the flow of Pre-filled with chlorine tablets and fits inside the Sparco Water water through the Sparco Water Treatment Chamber. Treatment System. For Pools up to Product # 01-04-5003 30,000 gallons. Product # 01-02-5510... -
Page 4: Notes And Safety Information
• Keep the instructions nearby and available for reference covered sufficiently in this manual, contact King Technology at throughout the service life of this Sparco System. 800-222-0169. -
Page 5: Safety Labels On Sparco System
Safety Label on Sparco System Review this label before installing or operating this System. Contact King Technology at 800-222-0169 if this label is missing from your Sparco System. Fire, explosion and high pressure hazards To minimize the risk of serious injury, death or property damage while using the Sparco System: a Read, understand and follow all instructions and safety precautions in the manual, and on this Sparco System and on any label for chemicals used with this Sparco System including Sparco Chamber. -
Page 6: Installation Tips To Ensure Proper Performance
Change the eyeball IN-FLOOR CLEANER fittings in the return jets to a smaller Line 2 VALVE size to increase back pressure. Contact King Technology at 800-222-0169 for a FILTER FLOW PUMP specially designed pressure gauge to determine back pressure at PN #01-22-4000 pool start-up. -
Page 7: Base Flex-Hose Installation
Phillips pan head screws, one in front and one in back. If you Apply sealant to threaded ends of both hose have questions about stability, please contact adapters and inside of both male adapters. your dealer or King Technology. -
Page 8: Hard-Plumbed Installation
C emen t return jets to a smaller or larger dealer about installing a size to adjust back pressure. For corrosion resistant check best results use King Technology’s Following Primer directions, Insert PVC pipe into male valve which will reduce the pressure... -
Page 9: Step 1: Preparing The Pool
Step 1: Preparing the Pool Make sure the pool has adequate Check for metals in the pool such circulation. The total volume of pool as iron or copper. Before attempting water must completely circulate water balance, these should be Metal through the pump and filter at least removed. - Page 10 Continue... Step 1: Preparing the Pool Initially shock the pool with For best results in achieving water balance, follow a chlorine shock only to rid steps 5a through 5e in order. the water of contaminants and establish a chlorine residual. Always follow the manufacturer’s directions Take a water sample carefully.
-
Page 11: Step 2: Putting The System To Work
Step 2: Putting the System to Work Avoid a If openings are pinched DANGER pinched together, open with fingers or opening. Never use fast dissolving chlorine tablets, liquid bleach, re-cut closer to the colored or calcium hypochlorite in the Sparco System. A correct screens inside Sparco oval... -
Page 12: Step 3: Setting The Control Dial
Step 3: Setting the Control Dial This system is designed to work effectively with a variety of pool equipment as long as the following procedures are followed. Set control dial on Sparco System by matching up the parameters of your pool on the chart below. THIS IS A STARTING POINT ONLY and may need to be adjusted to fit your individual pool needs. -
Page 13: Step 4: Routine Pool Care
Step 4: Routine Pool Care Run filtration system enough Shock the pool every week or as needed with a non-chlorine or hours to circulate all water 1 to 2 times per day. More than that chlorine shock. could result in over chlorination. WARNING DANGER To prevent the build up of gas pressure in the Sparco System,... -
Page 14: Winterizing
Winterizing Turn pump off and turn dial Remove Sparco Chamber. to Minimum. Remove cap. If the Sparco Chamber still contains chlorine, wrap in plastic bag and store in shed or cool, dry, well-ventilated location away from children, pets, cars, motorcycles or anything metal that can rust, pit, etc. -
Page 15: Troubleshooting
Troubleshooting For help troubleshooting call King Technology at 800-222-0169. Problem Remedy 1. Make sure your filtration 3. Make sure the pool is free chlorine reading of What do I do system is working properly (i.e. properly balanced 1.0 to 3.0 ppm. -
Page 16: Parts List
Parts List SILICONE LUBRIC ANT INCLUDED WITH SPARCO SYSTEM Model 5510 REPLACEMENT PARTS FOR SPARCO SYSTEM Model 5510 REF. # DESCRIPTION QTY. INCLUDED REF. # PART NUMBER DESCRIPTION 1 & 2 Cap w/O-Ring 1 & 2 01-22-9418 Cap w/O-Ring Body 01-22-9926 Cap O-Ring Pressure Relief Valve... -
Page 17: Maintenance - Replacing Control Dial O-Rings
System Maintenance Replacing the Control Dial O-Rings Using a needle nose pliers, find Push control dial completely the snap ring tail located at into the housing and turn the approximately the five o’clock dial to setting 2. position under the control dial. Insert the non-lipped end Pull down and out of the groove. -
Page 18: Maintenance - Replacing Cap O-Rings And Knobs
System Maintenance continued... Replacing Knobs Replacing the Cap O-Ring Remove old O-ring. To replace, simply unscrew old knob and replace with the new one. Top half of groove Place new O-ring in bottom half of groove. Place your thumbs on each side of the cap over the O-ring in the groove. -
Page 19: Warranty
Limited One-Year Warranty King Technology, Inc. will warrant this unit with a complete replace- 3. Any express warranty not provided for herein, and any remedy for ment for the original purchaser, should it prove defective by reason breach of warranty or breach of contract which, but for this provision,... - Page 20 MANUFACTURED BY 530 11th AVENUE SOUTH HOPKINS, MINNESOTA 55343 U.S.A. 952-933-6118 • 800-222-0169 kingtechnology.com 20-48-0150 553111843R5N...
