1200 V4 Installation & User Manual
WARNING
Please read the manual carefully before installation and use. The installation of your
new door opener should be carried out by a technically qualified or licensed person.
Attempting to install or repair the door opener without suitable technical qualification
may result in severe personal injury, death and / or property damage.

Advertisement

Table of Contents
loading

Related Manuals for Jaytech 1200 V4

Summary of Contents for Jaytech 1200 V4

  • Page 1 1200 V4 Installation & User Manual WARNING Please read the manual carefully before installation and use. The installation of your new door opener should be carried out by a technically qualified or licensed person. Attempting to install or repair the door opener without suitable technical qualification...

  • Page 2: Table Of Contents

    CONTENTS Important safety recommendations ···························································· - 1 - Basic function introduction ······································································· - 5 - Special function introduction····································································· - 5 - Installation recommendations ··································································· - 6 - Installation ··························································································· - 7 - Installation (steel track) ··········································································· - 7 - Assemble the Track(optional) ··································································· - 9 - Battery backup Assembly (optional) ···························································...

  • Page 3: Important Safety Recommendations

    Important safety recommendations FAILURE TO COMPLY WITH THE FOLLOWING SAFETY RECOMMENDATIONS MAY RESULT IN SERIOUS PERSONAL INJURY, DEATH AND / OR PROPERTY DAMAGE. 1. PLEASE READ CAREFULLY AND ADHERE TO ALL SAFETY AND INSTALLATION RECOMMENDATIONS. 2. The opener is designed and manufactured to meet Australian Standards AS/NZS 60335-2-95 when installed correctly.
  • Page 4 or property damage may occur if the garage door comes into contact with a moving object 10. Do not allow children to play with the appliance or its controls, including remotes. Waste electrical products should not be disposed of with household waste.
  • Page 5 protection system depending on contact with the bottom edge of the door. 19. Drives, shall be supplied with a label suitable for permanent fixing with a warning sign to keep children away when the door is moving, having a height of at least 60 mm. Drives shall be supplied with a label suitable for permanent fixing that describes how to use the manual release.
  • Page 6 31. Necessary information for the safe handling of a drive weighing more than 20 kg. This information shall describe how to use the handling means, such as hooks and ropes; 32. The drive must not be used with a door incorporating a wicket door (unless the drive cannot be operated with the wicket door put in the safe position);...

  • Page 7: Basic Function Introduction

    Basic function introduction 1. PTC Fuse inside the transformer, to protect the overload of the transformer. 2. O/S/C button on the display board. Make adjustment, maintenance and emergent opening or closing easier. 3. Copper worm gear inside the motor. With higher impact-resistance strength. 4.

  • Page 8: Installation Recommendations

    Installation recommendations there are specific standards that have to be strictly followed regarding the safety rules of electrical Remember installations and automatic gates and doors. As for the legal requirements and standards that must be adhered to, please take notice of the following points to ensure maximum safety and reliability of your installation.

  • Page 9: Installation

    Installation 1) Read the instruction carefully. 2) Make sure the door structure is solid and suitable to be motor driven. 3) Make sure when the door is moving, there are no friction point. 4) The door must be properly balanced and must be easily lowered and raised by hand. Referring to Fig.

  • Page 10: Assemble The Track(Optional)

    Fig.6 Fig.5 1. Fixing the wall bracket(B) to the wall 2cm-15cm over the shaft or intermediate bracket ,and should be center horizontally. (depending on the actual installation space). 2. Fixing the steel track to the wall bracket using axis pin Φ8x80 (C) and cotter pin. (Fig. 5) 3.

  • Page 11: Battery Backup Assembly (Optional)

    Confirm the type of the rail you have bought according to Fig7. 4 IN 1 3 IN 1 2 IN 1 Fig.7 Install the rails according the stepsog Fig8: A. Connect the rails by the sleeve; B. Follow the steps in the picture to connect the rails C.

  • Page 12: Basic Function Setting And Applying

    Basic function setting and applying 1. Matching the receiver and transmitter Coding Transmitters: Press and hold on “Code” button for 1 second until the led dot is on (Fig A). Press button on transmitter once, the dot will go off, press the same transmitter button again and the dot will flash fast for 8 times, and then return to standby mode.
  • Page 13 3. Safety reverse force adjustment Press and hold on “SET” button for 3 seconds until the LED flashes “1”. Press “UP” or “DOWN” button until LED flashes “2”, then press “SET” button. It’s now under force adjustment mode. The LED displays the current set force.
  • Page 14 6. Lock door setting Press and hold on “SET” button for 3 seconds until the LED flashes “1”. Press “UP” or “DOWN” button to (Only when the lock door function is increase or decrease. Adjust the LED to flash “5”, press available, the setting will proceed.

  • Page 15: Special Function, Optional Parts Introduction And Application

    Special function, optional parts introduction and application 1. External Fuse (optional) Protect the overload of the opener. 2. Burglar alarm (optional) Track in real time the close condition of the door. If the door is pried under the abnormal situation, it will alarm loudly. 3.

  • Page 16: Manual Disengagement

    Fig. 13 Fig. 14 Manual disengagement The opener is equipped with a manual release cord to disengage shuttle and move door by hand while holding the handle down (Fig 15). Pull on the handle to disengage the shuttle. To re-engage the door simply run opener in automatic mode or move door by hand until the trolley engages in the chain shuttle.

  • Page 17: Final Notes

    No particular maintenance is required for the logic circuit board. Check the door at least twice a year if it is properly balanced, and all working parts are in good working condition. Check the reversing sensitivity and adjust if it is necessary. Make sure that the safety devices are working effectively (photo beams, etc.) Notice: An inadequately maintained door can affect the life of the automatic opener due to incorrect loads, and will void the warranty.

  • Page 18: Packing List

    Packing list Item Quantity Door opener Track Shuttle components kit Transmitter Transmitter bracket Certificate of approval Warning label Release cord(with caution paper and cord pendant) Door bracket Wall bracket “U” bracket Hanging bracket Bent arm Straight arm Fastener kit Technical Specifications Model 600N 800N...
  • Page 19 Fault Fault cause Solutions appearance Opener without any 1. Power supply 1. Check the power supply to openers. action 2. Plug wire is loose 2. Carefully open the motor cover, check all plug wire on control boards. Faulty learning of “UP” or “DOWN” Learn “UP”...
  • Page 20 PRODUCT WARRANTY For 7 years from the date of installation, this product will be repaired, or replaced free of charge, if defective in material or workmanship. ADDITIONAL WARRANTY ON PARTS Replacement parts for any defective parts on this product will be furnished, free of charge.
  • Page 21 Installation completed by ________________________________________________________________________________ Date______/______/_______ Contact Details __________________________________________________________________________________ Notes____________________________________________________________________________ __________________________________________________________________________________ - 19 -...
