  • Page 1 Owner’s Manual...
  • Page 2 NTENDED The intended use of the Pride Mobility Products device is that of a device with motorized positioning control that is intended for medical purposes and that can be adjusted to various positions. The de- vice is used to provide stability for patients and to alter postural positions.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS I. INTRODUCTION ....................4 II. SAFETY ......................5 III. YOUR CHAIR ..................... 8 IV. ASSEMBLY/DISASSEMBLY ................11 V. OPERATION ...................... 14 VI. BASIC TROUBLESHOOTING ................16 VII. CARE AND MAINTENANCE ................18...

  • Page 4: Introduction

    I. INTRODUCTION SAFETY The product you have purchased combines state-of-the-art components with safety, comfort, and styling in mind. Read and follow all instructions, warnings, and notes in this manual and all other accompanying litera- ture before attempting to operate this product for the fi rst time. If there is any information in this manual which you do not understand, or if you require additional assistance for setup or operation, please contact your authorized provider.

  • Page 5: Ii. Safety

    II. SAFETY PRODUCT SAFETY SYMBOLS The symbols below represent labels used on the product to identify warnings, mandatory actions, and prohibited actions. It is very important for you to read and understand these symbols completely. Do not remove these labels from your product. Please note that not all of the symbols may be used on your chair model.
  • Page 6 II. SAFETY Battery Door Location Degree of protection against electric shock Properly dispose of all electronic components, including the external transformer, hand control, batteries, actuator motors, and wiring. Contact your authorized retailer for more information. Green LED indicates power to the unit is on. Not applicable to all models. Your chair is a state-of-the-art life-enhancement device designed to increase comfort.
  • Page 7 II. SAFETY The scissor and lift mechanisms are labeled as pinch/crush point hazards on your chair. Keep clear of these areas and make sure the path of motion is unobstructed. See fi gure 3.1 for pinch/crush point locations. WARNING! Do not place objects or appendages in the path of moving parts. Degree of Protection/Mode of Operation •...

  • Page 8: Iii. Your Chair

    III. YOUR CHAIR BODY COMPONENTS Chairs are equipped with several frame and electrical components. Typically, frame (or body) components include a removable back pad*, removable chaise pad*, footrest, leg levelers, a lift mechanism, and scissor mechanisms. The electrical components include the external transformer, hand control, and batteries‡ (not included).
  • Page 9 III. YOUR CHAIR Removable Back Pad: Attaches to the chair with reusable fasteners to enable the use of the bed option on some models and to make servicing the chair more convenient. Removable Chaise Pad: Attaches to the chair with reusable fasteners to make servicing the chair more convenient.
  • Page 10 III. YOUR CHAIR Figure 3.2 Footrest Figure 3.3 Footrest extension  Chairs are designed so that your feet hang over  However, when your heels hang over the edge of the end. If your heels were on the footrest, it the footrest, it puts the weight of your legs on the would put pressure on your heels and leg mus- backs of your calves.

  • Page 11: Assembly/Disassembly

    IV. ASSEMBLY/DISASSEMBLY Your chair may require some assembly before initial use. It may also require disassembly to make servicing the chair more convenient. If your chair is a Knock-Down (KD) model, follow the instructions in “Chair Back Assembly” CHAIR BACK ASSEMBLY NOTE: If your chair is an Infi...
  • Page 12 IV. ASSEMBLY/DISASSEMBLY NOTE: Pull up on the chair-back to ensure that it is locked in place. NOTE: See fi gure 4.2 for additional instructions regarding LC770 models. 4. Connect the hand control harness to the chair and heat/massage harnesses (if equipped) to the chair (fi...
  • Page 13 IV. ASSEMBLY/DISASSEMBLY CHAIR PLACEMENT Your chair should be placed near a standard electrical outlet on dry, level ground where there is ample room to allow for proper operation. We recommend that you have the assistance of an attendant when positioning the chair to avoid the possibility of injury when lifting.

  • Page 14: Operation

    V. OPERATION OPERATION PRECAUTIONS There are certain precautions that should be taken during the operation of your chair. Read and follow these precautions carefully in order to ensure safe chair operation and to prevent injury and/or product damage.  Plug the power cord directly into the electrical outlet. Do not use an extension cord! ...
  • Page 15 V. OPERATION Follow these steps to properly sit in your chair: 1. Make sure that the chair is in the standing position. 2. Back into the chair and sit in the center of the seat. 3. Activate the DOWN button (switch) to lower the chair to a comfortable seated position. Follow these basic steps to operate your chair from the seated position: 1.

  • Page 16: Basic Troubleshooting

    VI. BASIC TROUBLESHOOTING Your chair may require occasional troubleshooting. The following troubleshooting tips and FAQs should sum- marize what you need to know about your chair. If at any time you do not feel comfortable performing the troubleshooting steps listed in this manual, contact your authorized provider for service. Please have the model number, serial number, and nature of the problem when calling.
  • Page 17 VI. BASIC TROUBLESHOOTING FREQUENTLY ASKED QUESTIONS What if my chair does not operate at all?  Ensure the external transformer is plugged into a properly wired electrical outlet.  Check the circuit breaker box connected to the electrical outlet to ensure the outlet is receiving power. ...

  • Page 18: Care And Maintenance

    VII. CARE AND MAINTENANCE Your chair will require routine maintenance checks. You can perform some of these checks, but others may require assistance from an authorized retailer. By following the maintenance checks in this section as sched- uled, you can help ensure your chair gives you years of trouble-free operation. If you have any questions regarding your chair’s care, contact your authorized retailer.
