Center High-Mounted
Stoplamp (CHMSL)
1. Remove the center high mount stoplamp (CHMSL)
fasteners.
2. Pull the CHMSL out of the liftgate.
3. Disconnect the rear washer hose from the rear
washer nozzle.
5-58
4. Disconnect the electrical connector from the
CHMSL assembly.
5. Press the tabs on the CHMSL lens to separate the
CHMSL bulb from the CHMSL lens.
6. Pull the CHMSL bulb out of the assembly.
7. Push the new bulb into the assembly until the bulb
is installed.
8. Align the tabs on the CHMSL lens with the CHMSL
bulb assembly, and push to installed.
9. Connect the electrical connector to the CHMSL
assembly.
10. Connect the rear washer hose to the rear
washer nozzle.
11. Align the CHMSL assembly with the liftgate.
12. Install the CHMSL fasteners.
