Summary of Contents for Electric Fireplaces Direct CS-28MM1030-GRY
- Page 1 CS-28MM1030-GRY ASSEMBLY, CARE & USE INSTRUCTIONS Questions, problems, missing parts? Before returning to your retailer, call our customers service department at 1-855-571-1044 8 a.m. - 8 p.m., EST, Monday-Friday. Please Keep This Manual For Future Reference...
- Page 2 PACKAGE CONTENTS PART DESCRIPTION QUANTITY Front Bar Left Wall Right Wall Left Middle Wall Shelf Base Back Panel Insert Remote Control Battery White Rocks Acrylic Shards...
- Page 3 HARDWARE CONTENTS (NOT SHOWN ACTUAL SIZE) PART DESCRIPTION QUANTITY Bolt Wooden dowel Back Panel Screw Touch-up pen...
-
Page 4: Assembly Instructions
PREPARATION Estimated Assembly Time: 45 minutes Before beginning assembly of product, make sure all parts are present. Compare parts with Tools Required for Assembly (not included): package contents list and hardware contents list. If any part is missing or damaged, do not attempt Phillips screwdriver to assemble the product. - Page 5 ASSEMBLY INSTRUCTIONS (CONT’D) 3. Insert five wooden dowels (BB) into the holes on the assembly from step 2, Place front bar (B) onto the assembly. Hardware Used Wooden dowel 4. Attach top (A), secure from underneath with nine bolts (AA). Hardware Used Bolt 5.
- Page 6 ASSEMBLY INSTRUCTIONS (CONT’D) 6. From behind the assembly, remove the preassembled insert brackets from the opening area. Save brackets and screws for future use. Note: Before proceeding to the next step, with the help of another person, move the mantel close to the fi...
- Page 7 ONE-YEAR LIMITED WARRANTY The manufacturer warrants that your new Electric Fireplace is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. Install and operate this Electric Fireplace in accordance with the installation and operating instructions furnished with the product at all times.
- Page 8 REPLACEMENT PARTS For replacement parts, call our customer service department at 1-855-571-1044, 8 a.m. - 8 p.m., EST, Monday - Friday. PART DESCRIPTION PART # Big Corner Block PF-1030FM-28-207-001 Small Corner PF-1030FM-28-207-002 Block (15) Bolt (17) PH-1030FM-28-001 Screw (16) PU16-3.5x15-BS Insert Mounting PU16-232628-MB Bracket (with...
