Part List - Master Bilt MBGFP-HG Installation & Operation Manual

PART LIST

The table below gives componet part numbers. Use this chart when ordering replacement parts for your MBGFP
cabinets. Always Advise Cabinet Serial Number When Ordering Parts
Ballast
Bulb
Lamp Holder
LED Light Bar (Single)
LED Light Bar (Double)
Female Door Plug (if required)
Light Switch
Expansion Valve
Evaporator Coil
Evaporator Fan Blade
Evaporator Fan Motor
Evaporator Fan Guard
Defrost Heater
Drain Line Heater
Defrost Heater Safety
Compressor
Condenser Coil
Condenser Fan Motor
Condenser Fan Blade
Drier
Thermometer
LAE Controller
LAE Sensor T1
LAE Sensor T2
Door - LH
Door - RH
Pilaster
Pilaster Clip
Wall Guard
Shelf (Sides)
Shelf (Middle)
Shelf (Bottom Sides)
Shelf (Bottom Center)
6/17 Rev. D 57-02400
MBGFP23-HG MBGFP27-HG
23-01709 23-01709
23-01576 23-01576
23-50562 23-50562
23-01924 (R) 23-01924(R)
NA
21-00568 21-00568
23-50793 23-50793
09-10407 09-10407
07-14098 07-14098
15-13106 15-13106
13-13279 13-13279
25-01324 25-01324
17-09568 17-09568
17-00404 17-00404
19-01164 19-01164
03-15192 03-15192
07-14088 07-14088
13-13101 13-13101
15-13093 15-13093
09-09171 09-09171
44-00963 44-00963
19-14243 19-14243
19-14244 19-14244
19-14245 19-14245
31-03925 31-03926
31-03929 31-03930
33-01408 33-01408
33-01011 33-01011
25-01376 25-01376
33-01812 (W) 33-01807 (W)
33-01813 (B) 33-01808 (B)
NA
33-01402 (W)
NA
33-01590 (B)
NA
MBGFP48-HG
23-01709
23-01575
23-50562
NA
NA 23-01925 (C)
21-00568
23-50793
09-10408
07-14099
15-13106
13-13279
25-01324
17-09569
17-00404
19-01164
03-14902
07-14089
13-13101
15-13093
09-09171
44-00963
19-14243
19-14244
19-14245
31-03927
31-03928
33-01408
33-01011
25-01376
33-01805 (W)
33-01806 (B
NA NA
33-01453 (W)
33-01606 (B)
NA NA
MBGFP74-HG
23-01709
23-01577
23-50562
23-01924(R)
23-01925 (C)
21-00568
23-50793
09-10408
07-14100
15-13106
13-13279
25-01324
17-09570
17-00404
19-01164
03-14898
07-14089
13-01283
15-13093
09-09171
44-00963
19-14243
19-14244
19-14245
31-03927
31-03928
33-01408
33-01011
25-01376
33-01805 (W)
33-01806 (B)
33-01807(W)
33-01808 (B)
33-01453 (W)
33-01606 (B)
33-01453 (W)
33-01606 (B)
14
