Resistance thermometer
for measuring surface temperature, Type series GA265x
Operating Instructions
1 General Information....................................................................................................... 2
1.1 General Safety Notes .............................................................................................. 2
1.2 Intended Use ........................................................................................................... 2
1.3 Conformity with EU Regulations .............................................................................. 2
1.4 ATEX Approval ........................................................................................................ 2
2 Transportation and Storage .......................................................................................... 2
3 Installation and Commissioning .................................................................................. 2
3.1 Electrical Connection .............................................................................................. 3
4 Operation ........................................................................................................................ 3
4.1 Maintenance / Service ............................................................................................. 3
5 Disassembly ................................................................................................................... 3
Questions about this device? Hotline +49 (0) 4408 804 - 444
LABOM Mess- und Regeltechnik GmbH Im Gewerbepark 13 27798 Hude Deutschland
Tel.: +49 (0) 4408 804-0 Fax: +49 (0) 4408 804-100 e-mail: info@labom.com www.labom.com
BA_054
Rev 1K7
Page 1/3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Labom GA2651
Summary of Contents for Labom GA2651
- Page 1 BA_054 Questions about this device? Hotline +49 (0) 4408 804 - 444 Rev 1K7 LABOM Mess- und Regeltechnik GmbH Im Gewerbepark 13 27798 Hude Deutschland Page 1/3 Tel.: +49 (0) 4408 804-0 Fax: +49 (0) 4408 804-100 e-mail: info@labom.com www.labom.com...
- Page 2 You find the complete EU Declaration of Conformity (document no. KE_011) at www.labom.com. ATEX Approval Devices of the type GA2651 are certified for use in explosive environments. If you purchased a device with ATEX approval, please refer to the accompanying docu- ment XA_001 for ATEX-relevant information.
- Page 3 Electrical Connection Complete the mechanical installation before you connect the device electrically. Set up all electrical connections while the voltage supply is switched off. M12 circular connector cable gland 3-wire circuitry transmitter 3-wire circuitry n.c. n.c. ϑ ϑ Figure 1: Variants of electrical connection Route the cable so that it does not apply force or torque to the measuring insert.
