CleanFreak TPL-PH12 Owner's And Operator's Manual page 6

ITEM PART NUMBER
NO.
1 UNAVAILABLE
2 UNAVAILABLE. SEE #5
3 UNAVAILABLE
4 H00564-2 WARNING LABEL
5 G11603-1 PRESSURE VALVE
6 UNAVAILABLE
8 J00651 HOSE CLAMP
9 02494-1A CORD HOOK ASSY.
10 02382A HANDLE RETROFIT KIT
11 00580-36IN-A HP HOSE ASSY
12 C00311 8-32 X 3/8 RH
13 B00216 POWER CORD
14 UNAVAILABLE
15 B02211-1 ROCKER SWITCH
16 G02531-1 WHEEL 4"
17 82331-2A AXLE ASSEMPLY
18 C00312-1 10-32 X 1 1/8" BLK ZINC
19 B02212 STRAIN RELIEF W/ NUT
20 82490A-GREY MOTOR HOUSING
21 82491A SUCTION HEAD LENS
22 F02492-GREY BOTTOM COVER
23 F02493-GREY BELT ACCESS COV.
24 82363A MOTOR STRAP ASSY
25 82424A BEARING SHAFT ASSY.
26 G00528-3 BRUSH BEARING
27 80508-1A BRUSH ASSY
28 E02445 BELT
QTY. ITEM
NO.
0 29 D00356-4 WEIGHT BLOCK
0 30 A00091-2 SPRAY TIP
0 31 00185-6A WIRING ASSY.
1 32 B00190 4" ZIP TIE
1 33 E03428 MOTOR SEAL GASKET
0 34 G00539 BRUSH MOTOR
1 35 A00102 Q.D. 1/4F X 1/4FP
1 36 A00053 45 ELBOW 1/4MP X 1/4FP
1
1
25
1
1
2
1
2
1
1
1
1
1
2
1
2
1
1
6
PART NUMBER QTY.
1
1
1
1
1
1
1
1
