Field Controls EvenAir H32 Installation Manual

The EvenAir H32 wiring hub is installed at the equipment. It is connected to the T32 or T32WF
thermostat using the existing or new 4-wire thermostat cable that normally connects the thermostat
to the equipment. The equipment is wired directly to the Wiring Hub, The upstairs sensor can be
either a wired or wireless sensor. Wireless sensors require the ER1 radio module that plugs into the
wiring hub. An outdoor temperature sensor can also be used to control fossil fuel heating in a dual
fuel heat pump or to control a whole house fan or economizer.
The EvenAir wiring hub can be used to control humidification and de-humidification, fresh air
intake per ASHRAE 62.2, ERVs or HRVs, whole house fans and economizers.
COMPONENTS: H32 Wiring Hub
T32 or T32WF Thermostat
AMJ type Modulating Dampers
1 TS51 or 2 TS52 Wired Temp Sensors
READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY BEFORE PROCEEDING WITH THE INSTALLATION.
This device MUST be installed by a qualified agency in accordance with the manufacturer's installation instructions.The definition of
a qualified agency is: any individual, firm, corporation or company which either in person or through a representative is engaged in,
and is responsible for, the installation and operation of HVAC appliances, who is experienced in such work, familiar with all the
precautions required, and has complied with all the requirements of the authority having jurisdiction.
Installed By:_______________________________________
INSTALLATION MANUAL
WIRING HUB
R
F I E L D C O N T R O L S
Model H32
PN 580011201
Wiring Hub
24VAC, 10VA
Made in USA
Please retain these instructions after installation.
Phone: _____________________
www.fieldcontrols.com
H32
R
For Wireless Temperature Sensors
1 or 2 TSER Wireless Sensors
1 ER1 Plugin Radio Module
Installation Date: _____________
P/N 780101720 3/18 Rev A
