  • Page 1 DSP M850 Solo/Duo UHF Microphones DSP B210 Solo/Duo UHF Voice and Instrument Systems User Manuel: M850 DSP Solo / M850 DSP Duo / B210 DSP Solo / B210 DSP Duo / B210 DSP Headset / B210 Lavalier tie-clip microphone M850 DSP...
  • Page 2 Safety Information Thank you for purchasing this digital appliance. To ensure perfect operation and security, please read the manual carefully and retain it for future reference. This manual can be downloaded from our site. CAUTION Risk of electric shock Do not open! Precautions The lightning flash with the arrowhead symbol in an equilateral triangle is intended to alert the user to the presence of non- insulated “dangerous voltage”...

  • Page 3: Table Of Contents

    Contents Contents ....................1 1 – Introduction ..................2 2 – Declarations of conformity ..............2 3 – DSP (Digital Signal Processor) Module ..........2 4 – Receiver functions and features ............3 5 – Transmitter functions and features ............4 6 –...

  • Page 4: Introduction

    The electronic system of this DSP module is designed to resist any interference which may occur while it is in use, guaranteeing the integrity of the signal at all times. Voice and instrument sound using Prodipe DSP UHF will be as close as possible to wire transmission quality.

  • Page 5: Receiver Functions And Features

    Balanced mono audio output XLR (main track on Solo versions). 4. Power supply connection ( 12-18V DC). 5. BNC antenna input (Solo versions). 6. BNC second antenna input (Duo versions). Actual product(s) may differ from illustrations/photographs used Copyright © 2017 IPE Music / Prodipe...

  • Page 6: Transmitter Functions And Features

    4. Power supply and synchronisation tell-tale light. 5. LCD display. 6. Receiver [IR] for automatic channel selection. 7. Battery compartment LR6 / AA (x2). 8. Battery cover. Actual product(s) may differ from illustrations/photographs used Copyright © 2017 IPE Music / Prodipe...

  • Page 7: Configuration Of Transmission Channels

    2- M850 Microphone (M850 DSP Solo et M850 DSP Duo): 1. Microphone unit and wire mesh cover. 2. LCD display. 3. ON | MUTE | OFF Switch: ON | MUTE | OFF. 4. Power supply and synchronisation tell-tale light. 5. Battery compartment LR6 / AA (x2).
  • Page 8 CAUTION, once you have synchronisd one microphone or bodypack you MUST switch it off before synchronising the other. Actual product(s) may differ from illustrations/photographs used Copyright © 2017 IPE Music / Prodipe...

  • Page 9: Use

    If you are using a Prodipe Lavalier tie-clip microphone, refer to the accompanying user manual for the best position. If you are using microphones from the Prodipe 21 Series, refer to the accompanying user manuals for the best position. 8 – General characteristics of DSP UHF ...

  • Page 10: Connections

    Connect the mains adapter to the socket provided in the back of the receiver and plug into a 230V/50 Hz power source. Audio connection: Connect the receiver audio output cable (jack or XLR) to your mixer or broadcasting system. Actual product(s) may differ from illustrations/photographs used Copyright © 2017 IPE Music / Prodipe...

  • Page 11: Precautions During Use And Guarantee

    To preserve the sensitivity and sound reproduction quality of your microphone, it should never be exposed to humidity or extreme temperatures (e.g. direct sunlight). Prodipe and its distributors disclaim all liability for damage to this device resulting from use other than as described above.

  • Page 12: Technical Specifications

    AC: 100~240V (45-60Hz) Voltage S/N ratio > 96dB RX sensitivity < -94dBm Unbalanced audio output 1 mix out 1 mix out (6.35mm jack) Balanced audio output (XLR) Actual product(s) may differ from illustrations/photographs used Copyright © 2017 IPE Music / Prodipe...

  • Page 13: Table Of Frequencies

    64185 65435 65350 67850 65350 67850 64210 65460 64210 65460 64210 65460 65400 67900 65400 67900 64235 65485 64235 65485 64235 65485 65450 67950 65450 67950 Actual product(s) may differ from illustrations/photographs used Copyright © 2017 IPE Music / Prodipe...
  • Page 14 _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________...
  • Page 15 _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________ _____________________________________________________________...
  • Page 16 IPE Music 20, rue Clément ADER Z.A. Les Gloriets 85340 OLONNE-SUR-MER FRANCE www.prodipe.com...
