ULTRASUITE ARRAY
INSTALLATION INSTRUCTIONS
Step 8: Raise the first module assembly, temporarily supporting it using hanger wire. Do not twist the wires at this stage; bend in
loose, 180° loops allowing leveling of the system once all modules are in place (fig. 11).
FIGURE 11: TEMPORARY HANGER SUPPORT
Step 9: Raise adjacent module assemblies, temporarily supporting the modules with hanger wire. Fasten modules together using
bolts, metal washers, and lock nuts supplied by Price (fig. 12, 14). Module sections will have slotted holes for fastening (fig. 13).
Bottom of modules should be flush and level prior to fastening together.
FIGURE 12: HARDWARE
6 ULTRASUITE ARRAY - Manual | priceindustries.com
FIGURE 13: MODULE SECTION CLOSE-UP
