Installing and removing batteries
To open the battery vault, slide the grip to the left. This will unlock it and the battery
can be placed inside with the positive end of it pointing towards the vault flap.
To close the battery vault, simply push gently down on the
flap until you hear a clicking sound. The receiver is now
locked and ready to use.
Switching the receiver On and Off
To turn the receiver on, simply slide the switch to the left. To turn it off, slide the
switch to the right.
Viewing the Main Menu
On the top edge of the receiver, press and hold the navigation switch for 2 seconds.
The main menu will be displayed and will read from left to right:
EXIT> FREQUENCY>AF OUTPUT> OPTIONS> SCAN> INFO>LOCK.
Accessing the Frequency option
After accessing the main menu, use the wheel to scroll to the Frequency option. Once
the frequency option is highlighted press the middle part of the wheel to view a range
of frequencies.
A range of frequencies will then be displayed. The desired frequency can be accessed
by using the wheel to scroll to it. Then press the middle part of the wheel to select it.
Once a frequency has been selected, the receiver instantly goes back to the main menu.
AF output option
User Guide for En2 MX receiver
Slide grip to the right to
open the battery
compartment.
Switch.
Advertisement
Table of Contents
Related Manuals for Envoy En2
Summary of Contents for Envoy En2
- Page 1 User Guide for En2 MX receiver Installing and removing batteries To open the battery vault, slide the grip to the left. This will unlock it and the battery can be placed inside with the positive end of it pointing towards the vault flap.
- Page 2 After accessing the main menu, use the wheel to scroll to the AF output option. Once the AF output option is highlighted press the middle part of the wheel to view a range of AF outputs. A range of the AF outputs will then be displayed. The desired AF output option can be accessed by using the wheel to scroll to it.
- Page 3 Brightness On selection of the Brightness mode, scroll the wheel to scroll to select on of five brightness options. Once a brightness option has been selected, the receiver will instantly go back to the options menu. Screen Saver On selection of the Screen Saver mode, move the wheel to scroll between 4 screen brightness options: X (NONE)>...
- Page 4 Information option After accessing the main menu, use the wheel to scroll to the Info option. Once the Information option is highlighted press the middle part of the wheel to view the options : S/N> Rev > Table. To view the information for any of these, there is no need to press down the middle button.
