AV Link SBB3 User Manual

Universal l-shaped soundbar brackets

These universal brackets are VESA compatible allowing you to neatly mount a soundbar onto an existing TV wall bracket.

Once the soundbar has been mounted, the brackets are completely invisible giving a perfect stylish look while in the ideal

position for the best sound distribution.

• Universal compatibility with most makes of TV and any soundbar that can be wall mounted

• Easy to install and completely invisible when mounted

• Adjustable angle for perfect mounting

• Installation hardware included

Caution

Please read this manual thoroughly to

avoid damage to property or

personnel. If unsure of any part of this

manual please refer to professional

installer for help:

• This product contains small

components that could pose a

choking hazard if swallowed, please

keep out of reach of children.

• This product is design for indoor

use only. The bracket must be

inspected at least every two

months for loose joints or aged

parts.

Contents

Please check all contents listed are

included inside the box. If anything is

missing please return to the retailer or dealer. For this installation you will also require a Philips (cross) screw driver.

STEP 1 – Assemble the brackets and work out which mounting option is best for your screen and soundbar.

UNIVERSAL L-SHAPED SOUNDBAR BRACKETS

SBB3

Item ref: 129.596UK

User Manual

Table of Contents

Need help?

Do you have a question about the SBB3 and is the answer not in the manual?

Page 1 SBB3 UNIVERSAL L-SHAPED SOUNDBAR BRACKETS Item ref: 129.596UK User Manual These universal brackets are VESA compatible allowing you to neatly mount a soundbar onto an existing TV wall bracket. Once the soundbar has been mounted, the brackets are completely invisible giving a perfect stylish look while in the ideal position for the best sound distribution.
Page 2 STEP 2 – Install the brackets to the soundbar If the soundbar has threaded screw inputs then install the brackets with either A, B, C or D screws as pictured below. If the soundbar has keyhole inserts then install the brackets either way as pictured below. STEP 3 –...
