3 Overview

3.1 Function
The RWM MC is used to read out smoke
alarm devices and record the chamber value
(see chapter 5.4 "Kammerwert (Chamber
value)" on page 38). The chamber value
provides information on the level of pollu-
tion of the smoke alarm device.
3.2 Layout
Fig. 4 Layout, front side
Operating Manual: RWM MC - Diagnostic device for smoke alarm devices
30
1 Connection socket for RJ plug
2 Display
3 Adapter cable
4 Start button
5 Triangular plug with protective cap
1
2
3
4
Fig. 5 Layout, rear side
5
6 Battery compartment
6
