StoneAge AUTOBOX ABX-PRO-100 User Manual

Hose feed device engineered to quickly and safely clean a broad range of pipes with or without a flange.
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AUTOBOX
(ABX-PRO-100)
®
CONTROL BOX (CB-ABX-PRO-100-X)
AUTOBOX
ABX-PRO ACCESSORIES:
®
LIGHTWEIGHT POSITIONER (LWP-500-V2)
FIN FAN KIT (FF-XX)
PRODRAIN (PRO-700-V2)
NAVIGATOR & CONTROL BOX (NAV-170)
USER MANUAL
PL 612 REV J
(08/2018)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUTOBOX ABX-PRO-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for StoneAge AUTOBOX ABX-PRO-100

Summary of Contents for StoneAge AUTOBOX ABX-PRO-100

  • Page 1 AUTOBOX (ABX-PRO-100) ® CONTROL BOX (CB-ABX-PRO-100-X) AUTOBOX ABX-PRO ACCESSORIES: ® LIGHTWEIGHT POSITIONER (LWP-500-V2) FIN FAN KIT (FF-XX) PRODRAIN (PRO-700-V2) NAVIGATOR & CONTROL BOX (NAV-170) USER MANUAL PL 612 REV J (08/2018)

  • Page 2: Table Of Contents

    TABLE OF CONTENTS CE DECLARATION OF INCORPORATION ............MANUFACTURER’S INFORMATION .
  • Page 3 OPTIONAL ACCESSORIES ................ABX-PRO TRACTOR ON LWP-500-V2 LIGHTWEIGHT POSITIONER .

  • Page 4: Ce Declaration Of Incorporation

    _ 06/15/2016______ StoneAge Europe Unit 2, Britannia Business Centre Britannia Way Malvern WR14 1GZ United Kingdom ® The Technical File for the AUTOBOX (ABX-PRO-100) is maintained at: StoneAge, Inc. 466 South Skylane Drive, Durango, CO 81303, USA 866-795-1586 • WWW.STONEAGETOOLS.COM...

  • Page 5: Manufacturer's Information

    MANUFACTURER’S INFORMATION StoneAge Inc. StoneAge Europe 466 S. Skylane Drive Unit 2, Britannia Business Centre Durango, CO 81303, USA Britannia Way Phone: 970-259-2869 Malvern WR14 1GZ Toll Free: 866-795-1586 United Kingdom www.stoneagetools.com Phone: +44 (0) 1684 892065 This manual must be used in accordance with all applicable national laws. The manual shall be regarded as a part of the machine and shall be kept for reference until the final dismantling of the machine, as defined by applicable national law(s).

  • Page 6: Warning And Safety Instructions

    Aerosols • StoneAge WILL NOT accept responsibility for the results of misuse. Biological and microbiological (viral or bacterial) agents • IT IS THE RESPONSIBILITY OF THE INSTALLER/OPERATOR Combustible materials •...

  • Page 7: Pre-Run Safety Check

    WARNING AND SAFETY INSTRUCTIONS WARNING PRE-RUN SAFETY CHECK Refer to WJTA-IMCA’s, Recommended Practices For The Use Of Operations with this equipment can be potentially hazardous. Caution High-pressure Waterjetting Equipment and/or The Water Jetting MUST be exercised prior to and during machine and water jet tool Association’s, WJA Code of Practice for additional safety information.

  • Page 8: System Assembly - Overview

    SYSTEM ASSEMBLY - OVERVIEW ® AUTOBOX ABX-PRO-100 ASSEMBLY WITH STRAIGHT MOUNTING OPTIONS *THE MOUNTING OPTION BELOW IS USED ON FLANGELESS PIPES* BOP 050 STRAP MOUNT ASSEMBLY BOP 081-6 SNOUT TUBE Flangeless Pipe shown for graphic BOP 012 SPLASH GUARD representation only. Not included in FF 121-XX assembly.

  • Page 9: Tight Pipe Flange Mounting Options

    THE MOUNTING OPTIONS BELOW ARE FOR USE WHEN THE PIPE JOINT WILL NOT SEPARATE ENOUGH TO ALLOW A STRAIGHT ENTRY CONNECTION. The BOP 082-9-45 is available through STONEAGE for 45o BENDS. A standard 1.75” electrical conduit can also be used for connections ®...

  • Page 10: Cb-Abx-Pro-100-X, Pedestal And Side Mount

    SYSTEM ASSEMBLY - OVERVIEW PEDESTAL MOUNT OPTION CONTROL BOX (CB-PRO-100-P) FRONT VIEW CONTROL PANEL VIEW BACK VIEW REMOTE CONTROL BOX WITH 8’ TETHER ADJUSTABLE HEIGHT STAND COLOR CODED JIC FITTINGS WITH DUST CAPS PUSH-TO- CONNECT FOR VALVE INLET AIR 1/4” DUMP LINE HOSE FEED PNEUMATIC FITTING...

  • Page 11: Quarter Plate Flange Mount Set-Up

    QUARTER PLATE FLANGE MOUNT ASSEMBLY SET-UP QUARTER PLATE FLANGE MOUNT (BOP 010-2-4 QTR) TO PIPE AND ABX-PRO Attach the Quarter Plate Flange Mount to the pipe flange using the fasteners that were removed from the flange joint. The nuts shown between the pipe flange and the Quarter Plate Flange Mount are to allow for drainage.
  • Page 12 QUARTER PLATE FLANGE MOUNT ASSEMBLY SET-UP 4. Loosen the adjustable handle on the Hinge Clamp. Slide the Snout Tube into the Quarter Plate Flange Mount. Tighten the adjustable handle to secure. (Figure 4) ADJUSTABLE HANDLE BOP 081-6 SNOUT TUBE FIGURE 4 5.

  • Page 13: 4"-8" Plate Mount Assembly Set-Up

    4”-8” PLATE MOUNT ASSEMBLY SET-UP 4”-8” FLANGE MOUNT PLATE (BOP 010-4-8) Attach the 4”-8” Flange Mount Plate to the pipe flange using the fasteners that were removed from the flange joint. The nuts shown between the flange and the Flange Mount Plate are to allow for drainage. Other spacer options are acceptable. (Figure 1) Align the appropriate slots or pre-drilled holes to the hole pattern on the flange.

  • Page 14: Strap Mount Assembly Set-Up

    STRAP MOUNT ASSEMBLY SET-UP STRAP MOUNT ASSEMBLY (BOP 050) - MALE POSITIONER SIDE The Strap Mount Assembly (BOP 050) is designed for pipes that do not have flanges. Attach the strap end to the strap capture bar and wrap the strap around the pipe towards the Winch Assembly. (Figure 1) Pull excess strap through the Winch Assembly and tighten down with the Ball End Handle.
  • Page 15 STRAP MOUNT ASSEMBLY SET-UP Release the Adjustable Handle on the BOP 070 Hinge Clamp to access the 4 socket head cap screws. Locate the side of the BOP 030 Collet Block Assembly with 4 threaded holes. Orient the Hinge Clamp so that the hinge is on the right. Fasten the Hinge Clamp Assembly to the Collet Block Assembly using the 4 supplied socket head cap screws.
  • Page 16 STRAP MOUNT ASSEMBLY SET-UP FEMALE POSITIONER ARM TO MALE POSITIONER ARM CONNECTION WARNING Prior to use, always tighten and test the Backout Preventer to ensure the tool does not pass backward toward the Collet Block Assembly. Failure to do so can result in severe injury and/or death. Slide the Female Positioner Arm onto the Male Positioner Arm.

  • Page 17: Hose And Collet Installation

    HOSE AND COLLET INSTALLATION LOADING THE HIGH-PRESSURE HOSE NOTICE Only high quality hoses intended for waterblast applications should be used as high-pressure hoses. Pressure rating of high-pressure hoses MUST NEVER be exceeded. Do not use a shrouded hose or hose with a steel protective cover. This will cause severe damage to the Rollers. To load a hose, release the Adjustable Handle and rotate the Cam Lever until the Indicator Pin is in the “Disengaged”...
  • Page 18 QUICK RELEASE PINS ADJUSTABLE HANDLE FIGURE 3 FIGURE 4 ® ® Attach the desired tool onto the male hose end (Stoneage BT25 Beetle shown for reference). SEE THE APPLICABLE TOOL MANUAL FOR SPECIFIC INSTALLATION INSTRUCTIONS. TOOL FIGURE 5 866-795-1586 • WWW.STONEAGETOOLS.COM...

  • Page 19: Control Box Set-Up

    CONTROL BOX SET-UP PNEUMATIC AIR LINE CONNECTIONS Pull the Dust Caps off the Pneumatic Air Fittings. Connect the Pneumatic Supply Lines from the CB-ABX-PRO-100-X Control Box to ® the AUTOBOX ABX-PRO-100. Pay close attention to the color coded tabs on the air fittings of the Air Motor and the Control Box. Connect the red hose to the red banded air fittings and the black hose to the black banded air fittings.
  • Page 20 CONTROL BOX SET-UP AIR SUPPLY AND LUBRICATOR SETTING The Control Box is supplied with a twist claw style inlet coupling (Chicago style) located on the side of the FRL Assembly. Connect a compatible compressed air line (not included) according to the Manufacturer’s instructions. If another pneumatic connection is preferred, this fitting can be removed and any male 1/2 in NPT fitting may be used.

  • Page 21: Operation

    CONTROL BOX SET-UP PNEUMATIC DUMP CONTROL FITTING AND LINE A DUMP CONTROL is located on the Control Box panel and can be set up to control an air actuated dump valve. To utilize the toggle, the end user will need to install 1/4 in. (6.35 mm) O.D. nylon tubing (not included) between the DUMP CONTROL FITTING and the pneumatic dump valve.

  • Page 22: Maintenance And Troubleshooting

    -Check that the proper Rollers are installed (see roller and collet reference plate) -Tighten eccentric lever to retain clamp force on hose. Contact StoneAge for Safety Data Sheets for material usage, a complete list of spare part numbers, and service instructions for and CB-ABX-PRO-100-X Control Box.

  • Page 23: Roller And Collet Selection

    TRACTOR. It also comes with a pair of the PRO 174-34 and PRO 174-58 rollers in the package. The PRO 174-89 rollers are available ® for 3/8” hoses but not included. The sizing chart below is also located on a plaque near the air motor on the AUTOBOX ABX-PRO TRACTOR. POLY ROLLERS STONEAGE HOSE OD SPIRSTAR PARKER COLLET SIZE ABX-PRO...

  • Page 24: Abx-Pro Roller Replacement

    ROLLER REMOVAL INSTRUCTIONS ROLLER REMOVAL NOTICE This process will be typical for Poly Roller replacements on the ABX-PRO Tractor Assembly. Installation of the appropriate Roller should be ® completed prior to installing the hose and tool into the AUTOBOX ABX-PRO-100 Assembly. WARNING Always de-energize the system before servicing or replacing any parts.

  • Page 25: Roller Installation Instructions

    ROLLER INSTALLATION INSTRUCTIONS ROLLER INSTALLATION NOTICE This process will be typical for Poly Roller replacements on the ABX-PRO Tractor Assembly. Installation of the appropriate Roller should be ® completed prior to installing the hose and tool into the AUTOBOX ABX-PRO-100 Assembly. WARNING Always de-energize the system before servicing or replacing any parts.

  • Page 26: Part Diagrams

    PARTS DIAGRAM AUTOBOX (ABX-PRO-100) ® FULL ASSEMBLY NOTICE ASSEMBLY MUST NOT BE OPERATED WITHOUT THE USE OF A COLLET (FF 121-XXX) OR COLLET SET (PRO 621 OR PRO 622) *OPTIONAL BOP 010-4-8, PLATE FOR LARGE FLANGE PIPES 4”-8” PART NUMBER QTY.
  • Page 27 PARTS DIAGRAM AUTOBOX (ABX-PRO) ® TRACTOR ASSEMBLY NOTE: 1. ADD 5.0 OUNCES OF MOBIL SYNTHETIC OIL SCH 634 (SA# GP 146.1) 2. THIS WORM CAP WILL BOTTOM ON BEARING, WILL NOT BOTTOM ON HOUSING WHEN TIGHTENED 3. ADD PRELUBE TO ALL SHAFTS, GEARS, BEARINGS, AND SEALS. 4.
  • Page 28 PARTS DIAGRAM AUTOBOX (PRO 101) ® HOUSING ASSEMBLY NOTE: 1. ADD BLUE LOCTITE: PN: 242 OR EQUIVALENT. PART NUMBER QTY. PRO 102 BACK PLATE ABX 566-001 SPRING PLUNGER ASSY PRO 103 SIDE PLATE, MOTOR GN 337-HJ HEX JAM NUT SS PRO 104 SIDE PLATE, FRONT GSB 313-0075 BHCS 6-32 X .188 LG SS PRO 105 COVER, FRONT PANEL...
  • Page 29 PARTS DIAGRAM AUTOBOX (ABX 566-001) ® SPRING PLUNGER ASSEMBLY PART NUMBER QTY. ABX 566.1-001 BODY ABX 566.2-001 PIN ABX 566.3-001 SPRING ABX 566.4-001 RING AUTOBOX (PRO 116) ® ADJUSTABLE HANDLE ASSEMBLY PART NUMBER QTY. SRT 556 ADJUSTABLE HANDLE .38-16 X 1.56 SS PRO 116.2 SHOULDER SLEEVE 866-795-1586 •...
  • Page 30 PARTS DIAGRAM PRO 170 IDLER ROLLER ASSEMBLY ALIGN SIGHT HOLE WITH IMPRINTED ROLLER SIZE ON PRO 174-XX ROLLER NOTE: PART NUMBER QTY. PRO 171 IDLER HUB 1. 5x BLUE LOCTITE: PN: 242 PRO 176 IDLER SHAFT PRO 172 ROLLER GEAR 15T OR EQUIVALENT 2.
  • Page 31 PARTS DIAGRAM PRO174-46 FIN FAN (FF 622) HOSE DRIVE ROLLERS *OPTIONAL COLLET SET INCLUDES ONE OF EACH SIZE FF 121-XX SINGLE COLLET STOP ROLLER INSIDE HOSE OD SPIRSTAR PARKER COLLET SIZE COLLET ABX-PRO-100 2240D-02 0.297 in. / 7.5 mm FF 121-297 PRO 174-34 0.26–0.38 IN.
  • Page 32 PARTS DIAGRAM BOP-010-2-4 QTR QUARTER PLATE BOP NOTE: 1. 4x BLUE LOCTITE: PN: 242 OR EQUIVALENT 2. 4x RED LOCTITE: PN: 262 OR EQUIVALENT PART NUMBER QTY. BOP 001-2-4-QTR DECAL PLATE BOP 002-2-4-QTR QUARTER FLANGE PLATE 2-4IN BOP 007 TUBE CLAMP ASSY BOP 013 SCREW 6-32X.25 SELF TAP GSB 331-03 BHCS .31-18 X .75 LG BOP 012...
  • Page 33 PARTS DIAGRAM BOP 050 STRAP MOUNT ASSEMBLY PART NUMBER QTY. BOP 049 RIVET SS BOP 051 RATCHET STRAP ASSEMBLY BOP 057 POSITIONER TUBE, MALE BOP 058 POSITIONER TUBE, FEMALE WELDMENT BOP 059 QUICK PIN BOP 070 HINGE CLAMP ASSEMBLY GS 325-025 SHCS .25-20 X .62 SS *OPTIONAL BOP 082-9-45 1.75 X R9 X 45 DEG SNOUT TUBE...
  • Page 34 PARTS DIAGRAM AUTOBOX (CB-PRO-100-P) ® CONTROL BOX ASSEMBLY, PEDESTAL MOUNT NOTE: NOTE: 2. APPLY BLUE GOOP (A SWAGELOK BRAND) ANTI-SEIZE. TO ALL THREADED HARDWARE. SEE THE CB-ABX-PRO-S PART DIAGRAM ON THE NEXT 3. BLUE LOCTITE: PN: 242 OR EQUIVALENT PAGE FOR NOTES AND UMBILICAL LINE TABLE. 4.
  • Page 35 PARTS DIAGRAM AUTOBOX (CB-ABX-PRO-100-S) ® CONTROL BOX ASSEMBLY, SIDE MOUNT UMBILICAL TUBE ROUTING REMOTE BOX TERMINATION FRL TERMINATION UMBILICAL LINE (SHORT SIDE) (LONG SIDE) 1/4” BLACK TEE FOR SUPPLY DRY AIR TAP 1/4” GREEN DUMP BULKHEAD DUMP NOTE: 2. APPLY BLUE GOOP (A SWAGELOK BRAND) ANTI-SEIZE. TO ALL THREADED HARDWARE. 1/8”...
  • Page 36 PARTS DIAGRAM CB 750-P ABX-PRO REMOTE BOX ASSEMBLY, PEDESTAL PART NUMBER QTY. CB 751 ENCLOSURE, ABX-PRO CB 714 CORD GRIP, .51-.79 CB 751.1 TUBE, REMOTE BOX CONTROLS CB 716 ANODIZED PULL HANDLE CB 752 GRAPHIC ABX-PRO CB 721 PNEUM 3WAY ASSY, DUMP CB 753 HEX STANDOFF CB 722 PNEUM 3WAY ASSY, FWD-REV CB 791 FITTING, TEE, PL4...
  • Page 37 PARTS DIAGRAM CB 750-S ABX-PRO REMOTE BOX ASSEMBLY, SIDE MOUNT PART NUMBER QTY. CB 775 HANDLE, SIDE LATCH CB 714 CORD GRIP, .51-.79 CB 776 HANDLE SPACER, SIDE LATCH CB 721 PNEUM 3WAY ASSY, DUMP CB 777 HOLE PLUG CB 722 PNEUM 3WAY ASSY, FWD-REV CB 791 FITTING, TEE, PL4 CB 751 ENCLOSURE, ABX-PRO GN 319-L-32 NYLOK NUT SS...
  • Page 38 PARTS DIAGRAM CB 763 ABX-PRO FILTER, REGULATOR, LUBRICATOR ASSEMBLY PART NUMBER QTY. CB 312.1 FILTER REGULATOR ASSEMBLY CB 312.1.1 FILTER REGULATOR BOWL CB 312.1.6 FILTER CB 312.1.7 GAUGE WITH LENS CB 312.1.8 ORING CB 312.2 LUBRICATOR ASSEMBLY CB 312.2.2 LUBRICATOR BOWL CB 312.4 SPACER ATTACHMENT CB 312.5 SPACER W-O BRACKET CB 763.1 MODIFIED SPACER W-O BRACKET...

  • Page 39: Optional Accessories

    OPTIONAL ACCESSORY OVERVIEW- ABX-PRO TRACTOR ON LWP-500-V2 POSITIONER ABX-PRO TRACTOR ON THE LWP-500-V2 LIGHTWEIGHT POSITIONER FULL PART DIAGRAMS ARE LOCATED IN THE “OPTIONAL ACCESSORY PART DIAGRAM” SECTION OF THIS MANUAL BOP 035-8 BOP 048 HOSE GUIDE WITH HOSE STOP ADAPTER COLLET BLOCK LWP-500-V2 SHOWN ON HEAT...
  • Page 40 ABX-PRO TRACTOR ON LWP-500-V2 POSITIONER SET-UP ATTACH ABX-PRO TRACTOR TO GUIDE ASSEMBLY AND LIGHTWEIGHT POSITIONER Select an appropriate size Guide Tube from the chart located in the “Part Diagram” section of this manual. Install Guide Tube into the Collet Block on the Guide Assembly by loosening the 4 screws with a 1/4” Allen Wrench. Insert the Guide tube and tighten the 4 screws on the Collet Block Cap.
  • Page 41 CONTROL BOX TO ABX-PRO TRACTOR ASSEMBLY PNEUMATIC SUPPLY LINE CONNECTIONS Connect the vertical positioner drive air motor to the CB-ABX- PRO Control Box with two 1/4 in. (6 mm) JIC hoses. Use the Remove the dust caps from the Joint Industry Council (JIC) diagram below for proper connections Verify the CB-ABX-PRO fittings of the Control Box and the ABX-PRO Tractor.
  • Page 42 ABX-PRO TRACTOR ON LWP-500-V2 POSITIONER SET-UP COLLET INSERTION, HOSE, AND HOSE STOP INSTALLATION Remove Quick Release Pin and pull the Collet out of the Block. Insert waterblast tool on high pressure hose, through the ABX-PRO Tractor and Collet Block Assembly. Be sure the waterblast tool and hose end pass the location of the Collet.

  • Page 43: Abx-Pro Tractor On Ff-Xx Fin Fan Kit

    OPTIONAL ACCESSORY OVERVIEW- ABX-PRO TRACTOR ON FF-100 FIN FAN KIT ABX-PRO TRACTOR ON THE FIN FAN FULL PART DIAGRAMS ARE LOCATED IN THE “OPTIONAL ACCESSORY PART DIAGRAM” SECTION OF THIS MANUAL **THESE PARTS ARE INCLUDED IN THE **BU 152 LIGHTWEIGHT POSITIONER LWP-500-V2 RAIL STOP (x 4) FIN FAN CLAMPS...
  • Page 44 ABX-PRO TRACTOR ON FF-100 FIN FAN KIT SET-UP ATTACH ABX-PRO TRACTOR TO GUIDE ASSEMBLY AND FIN FAN Select an appropriate size Guide Tube from the chart located in the “Part Diagram” section of this manual. Install Guide Tube into the Collet Block on the Guide Assembly by loosening the 4 screws with a 1/4” Allen Wrench. Insert the Guide tube and tighten the 4 screws on the Collet Block Cap.
  • Page 45 CONTROL BOX TO ABX-PRO TRACTOR ASSEMBLY PNEUMATIC SUPPLY LINE CONNECTIONS Connect the vertical positioner drive air motor to the CB-ABX- PRO Control Box with two 1/4 in. (6 mm) JIC hoses. Use the Remove the dust caps from the Joint Industry Council (JIC) diagram below for proper connections Verify the CB-ABX-PRO fittings of the Control Box and the ABX-PRO Tractor.
  • Page 46 ABX-PRO TRACTOR ON FF-100 FIN FAN KIT SET-UP COLLET INSERTION, HOSE, AND HOSE STOP INSTALLATION Remove Quick Release Pin and pull the Collet out of the Block. Insert waterblast tool on high pressure hose, through the ABX-PRO Tractor and Collet Block Assembly. Be sure the waterblast tool and hose end pass the location of the Collet.

  • Page 47: Abx-Pro Tractor On Pro-700-V2 Prodrain

    OPTIONAL ACCESSORY OVERVIEW- PRO-700-V2 PRODRAIN PRO-700 PRODRAIN PRODRAIN FULL ASSEMBLY SNOUT FULL PART DIAGRAMS ARE LOCATED IN THE “OPTIONAL ACCESSORY PART DIAGRAM” SECTION OF THIS MANUAL TRIPOD STAND COLLET BLOCK SPRING LOADED SPLASH DUMP FEET PLATE PRO-700 PRODRAIN ACCESSORY SHOWN FULLY ASSEMBLED WITH ABX-PRO TRACTOR, HIGH PRESSURE HOSE AND TOOL (NOT INCLUDED) ABX-PRO TRACTOR...
  • Page 48 PRO-700-V2 PRODRAIN SET-UP PRO-700 PRODRAIN SET-UP PROCEDURE Attach the BOP 030 Collet Block to the Tripod Stand. Loosen two screws on one Collet Cap with a 1/4” Allen wrench. Slide the BOP 030 Collet Block onto the Tube Adapter located on the bottom end of the Tripod Stand. Tighten the two screws on the Collet Cap until secure.
  • Page 49 PRO-700-V2 PRODRAIN SET-UP Slide the hose guide on the ABX-PRO Tractor into the Camlock on the Tripod Stand, with air fittings pointed down. Make sure to engage the Camlock lever lock pins. (Figure 3) Feed the HP Hose through BOP 09-7 Snout. (Figure 4) Rotate the Cam Tension Lever counterclockwise on the ABX-PRO Tractor to the “Disengaged”...
  • Page 50 PRO-700-V2 PRODRAIN SET-UP The image below shows how the Prodrain should look once the HP Hose and Snout have been properly installed. (Figure 7) 10. Lay the assembly down to attach the waterblast tool to the Male Hose End. Coat the threads of the hose end with Blue Goop by SWAGELOK or and equivalent Anti-seize.
  • Page 51 PRO-700-V2 PRODRAIN TO DUMP AND CONTROL BOX SET-UP 13. Connect 1/4” air lines from Control Box to the valve assembly on the Tripod Stand and from the Tripod Stand to the Dump. (Figure 11) 14. Connect 1/2” black and red air supply hoses from the fittings on the Control Box to the fittings on the ABX-PRO Tractor. Mate each hose to its respective color bands.

  • Page 52: Navigator Rotary Hose Device With Control Box

    OPTIONAL ACCESSORY OVERVIEW- NAV-170-PKG NAVIGATOR NAV-170-PKG NAVIGATOR ROTARY HOSE DEVICE WITH CONTROL BOX The is the only automated rotary hose device in the industry specifically engineered to clean small diameter process pipe with bends. It cleans past multiple bends and elbows using hose rotation and is used in conjunction with the AutoBox ABX-PRO hose tractor. It can hold up to 100 feet (30 m) of hose for job site safety, hose protection and transport.

  • Page 53: Optional Accessory Part Diagrams

    OPTIONAL ACCESSORY PART DIAGRAM LIGHTWEIGHT POSITIONER ASSEMBLY (LWP-500-V2) PART NUMBER BR 002-XX-001 2.5 BOX RAIL EXTRUSION BU 002-XX-001 2.5 BOX RAIL EXTRUSION, SLOTTED LWP-500.1 LIGHTWEIGHT POSITIONER PARTS 866-795-1586 • WWW.STONEAGETOOLS.COM...
  • Page 54 OPTIONAL ACCESSORY PART DIAGRAM *OPTIONAL (BOP 035-XX) GUIDE TUBE COLLET BLOCK ASSEMBLY PART NUMBER QTY. BOP 032 COLLET BLOCK CAP BOP 033 QUICK PIN BOP 036 GUIDE TUBE COLLET BLOCK BODY BOP 037 GUIDE TUBE COLLET BLOCK CAP BOP 038-XX BOX RAIL, PRO LWP MOUNT GB 325-025 BOLT, HEX .25-20 X .63 SS GS 331-06 SHCS .31-18 X 1.50 SS GS 331-10 SHCS .31-18 X 2.50 SS FULL THD...
  • Page 55 OPTIONAL ACCESSORY PART DIAGRAM *OPTIONAL PRO-700-V2 PRODRAIN ASSEMBLY V2 PART NUMBER QTY. UNITS PRO 707 FOOT SPRING BOP 030 COLLET BLOCK ASSEMBLY PRO 708 FOOT VALVE BOP 081-6 SNOUT TUBE 1.75 X 6 SS PRO 709 FITTING, .06 BARB X 10-32, 90DEG GMS 319-025-32 HHMS .19-32X.63 SS PRO 710 SEALED WASHER GN 319-L-32 NYLOK NUT SS...
  • Page 56 OPTIONAL ACCESSORY PART DIAGRAM BOP 090 *OPTIONAL 1 1/4” SNOUT WITH CAMLOCKS, 6FT NOTE: The BOP 084, BOP O85, and BOP 086 are used in combination to connect the ABX-PRO Tractor to the BOP 090 SNOUT ASSEMBLY *OPTIONAL HS 121-XX-XX *OPTIONAL BOP 084 HOSE STOP CLAMP 1.75 X 1.25 MNPT...
  • Page 57 OPTIONAL ACCESSORY PART DIAGRAM CB-ABX-PRO *OPTIONAL CONTROL BOX The CB-ABX-PRO allows the Operator to use the ABX-PRO Tractor on a Lightweight Positioner. NOTES: ASSEMBLY REFERENCE DIMENSION SHOWN (MM) / INCHES. PART NUMBER QTY. CB 301 STAND ASSEMBLY CB 310 FRL ASSEMBLY CB 745-25 ABX HOSE BUNDLE ASSEMBLY CB 800 CONTROL BOX ASSEMBLY 866-795-1586 •...

  • Page 58: Terms And Conditions

    Conditions of Sale (“Terms and Conditions”) shall operate as the acceptance of these Terms and Conditions at any time, shall not in any way affect, limit or by StoneAge, Inc. (“Seller”) of the order submitted by the purchaser (“Buyer”). waive Seller’s right thereafter to enforce and compel strict compliance with Such acceptance is made expressly conditional on assent by Buyer to these every term and condition hereof.
  • Page 59 Product EXTENT SUCH DAMAGES WOULD CONSTITUTE DIRECT DAMAGES), WITH at any time without notice to End-User, and StoneAge is not obligated to make RESPECT TO THE COVERED STONEAGE PRODUCT, OR OTHERWISE...
  • Page 60 1-866-795-1586 • www.STONEAGETOOLS.com © 2015 StoneAge, Inc. All Rights Reserved...
