- Page 1 User Manual BYOD Multiformat Presentation Switcher All Rights Reserved Version: BYOD_2018V1.2...
- Page 2 Stoltzen Multiformat Presentation Switcher Preface Read this user manual carefully before using the product. Pictures are shown in this manual for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 Stoltzen Multiformat Presentation Switcher SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ⚫...
-
Page 4: Table Of Contents
Stoltzen Multiformat Presentation Switcher Table of Contents 1. Introduction ....................... 1 1.1. Introduction to BYOD ................... 1 1.2. Features ....................... 1 1.3. Package List ......................1 2. Specification ......................2 3. Panel Description ..................... 3 3.1. Front Panel ......................3 3.2. -
Page 5: Introduction
The Stoltzen BYOD is a Multiformat Presentation Switcher converting AV signal from Lightning, USB-C, MINI DP, DP, HDMI type-A and HDMI type-D to HDMI. The BYOD is a green low energy consumption product which has a various application in different places, such as classroom, small meeting room, lecture hall, and etc. -
Page 6: Specification
Stoltzen Multiformat Presentation Switcher 2. Specification Input (1) Lighting; (1) USB Type-C; (1) Mini DP; (1) DP; Connector Type (1) HDMI Type-A; (1) HDMI Type-D Lighting Video Resolution Up to 1080P@60Hz USB-C Video Resolution Up to 4Kx2K@30Hz DP Video Resolution... -
Page 7: Panel Description
Stoltzen Multiformat Presentation Switcher 3. Panel Description 3.1. Front Panel USB - C DP full sized HDMI A HDMI type-D ① Lightning port for connecting iOS device, such as iPhone or iPad with charging capability. ② USB-C port for connecting MacBook, Chromebook or other devices with SlimPort output. -
Page 8: Rear Panel
Stoltzen Multiformat Presentation Switcher 3.2. Rear Panel 1080P SERVICE RES. DC 24V ① Security lock slot for installing Kensington lock. ② Micro USB port for firmware updating. ③ Dip switch for setting the HDMI output resolution as 4K or 1080P base on the EDID of connected display and source. -
Page 9: System Connection
4.2. Bracket Installation If the BYOD will be permanently mounted to a surface, the included bracket can be can be mounted to lock the unit according the below procedures. ① Taking out the bracket and self-tapping screws from the package. - Page 10 Stoltzen Multiformat Presentation Switcher ③ According the below installing direction arrow to insert the BYOD to bracket. Rear Panel Front Panel...
-
Page 11: System Diagram
Stoltzen Multiformat Presentation Switcher 4.3. System Diagram 1080P SERVICE RES. DC 24V 1080P SERVICE RES. DC 24V USB - C DP full sized HDMI A HDMI type-D Preview USB-C PC Graphics card Laptop Cellphone/PAD iPad MacBook Mac Mini... -
Page 12: System Operation
Stoltzen Multiformat Presentation Switcher 4.4. System Operation ① Connect TV to the HDMI output on the rear panel. ② Power on TV and the switcher, and then the TV will show “Please connect your device”. If the switcher doesn’t detect any source within 10 minutes, it will automatically turn off TMDS. -
Page 13: Panel Drawing
Stoltzen Multiformat Presentation Switcher 5. Panel Drawing 1080P SERVICE RES. DC 24V 135.00 mm USB - C DP full sized HDMI A HDMI type-D... -
Page 14: Troubleshooting & Maintenance
Stoltzen Multiformat Presentation Switcher 6. Troubleshooting & Maintenance Problems Potential Causes Solutions Color loss or no video signal output in HDMI display. The connecting Check whether the cables No HDMI signal output in the cables may not be are broken or connected... -
Page 15: Customer Service
Stoltzen Multiformat Presentation Switcher 7. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. 1) Warranty The limited warranty period of the product is fixed three years.
