Unpack your Ultimate 5th Wheel Connection kit and compare it with the Parts List on the Page 2. If it appears
that there are missing or damaged items caused by shipping and handling, contact the freight carrier who
delivered the unit for their damaged freight procedures. If any component appears to be missing or damaged -
but NOT due to shipping and handling, please contact us immediately.

SECTION 1: PREPARATION

SECTION 2: INSTALLING THE KINGPIN COUPLER BLOCK

2-3.
tightening the 4 set screws.
IMPORTANT:
tow vehicle, be very aware of the front corners and nose of your
trailer so they do not hit the windows or cab of your tow vehicle.
Each trailer is unique so be sure to watch its position in a sharp turn.
2-1.
kingpin as illustrated in the pictures to the left.
Make sure the ball socket is face-down. For
most 5th wheel installations, place the
greaseless opening towards the front of the
kingpin.
Pay close attention to the length of the
pin box. If there's a possibility that it
might hit the tailgate or side boards of
your tow vehicle, then place the
greaseless opening of the coupler block
behind the kingpin.
Do not attach the remote latch cable yet.
2-2.
their holes to hold the coupler block on the
kingpin and place the nuts on the two bolts
as illustrated on the left. Push the bolts all the
way flush to the block, but DO NOT fully tighten
the nuts yet.
Make sure the coupler block is centered to the pin box before
When turning sharply or reversing at an angle in your
Place the kingpin coupler block on the
Need Extra Clearance?
Insert the two 5" x 5/8" kingpin bolts into
