Andersen 3200 Installation Manual

5th wheel connection rail mount gooseneck , 20,000 lbs gtwr - 4,500 lbs tongue
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Table of Contents

Ultimate 5th Wheel Connection
Part #3200 Gooseneck Mount, 20,000 lbs GTWR - 4,500 lbs Tongue
INSTALLATION MANUAL

Table of Contents

!
!
!
!
!
Important Safety Information ...............................................
Parts Illustration ...................................................................
Section 1: Preparation .........................................................
Section 4: Installing the Base Unit .......................................
Section 5: Removing the Base Unit .....................................
Rail Mount
Table of Contents
Page 2
Page 3
Page 4
Page 4
Page 5
Page 6
Page 6
THERE IS NEVER A NEED TO
GREASE BALL OR COUPLER
NOTE:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Andersen 3200

  • Page 1: Table Of Contents

    Ultimate 5th Wheel Connection Rail Mount Part #3200 Gooseneck Mount, 20,000 lbs GTWR - 4,500 lbs Tongue INSTALLATION MANUAL Table of Contents Table of Contents Important Safety Information ..........Page 2 Parts Illustration ..............Page 3 Section 1: Preparation ............

  • Page 2: Important Safety Information

    If you happen to lose or damage any of your Ultimate 5th Wheel Connection parts, please visit your local Authorized Andersen Dealer for replacements. Note: The Rails that you will attach the Ultimate 5th Wheel Connection to are NOT INCLUDED in this package.

  • Page 3: Parts Illustration

    PARTS ILLUSTRATION #3200 ULTIMATE 5TH WHEEL CONNECTION –RAIL MOUNT The complete 3200 assembly includes all items listed on this page Kingpin Coupler Assembly #3231 1. Kingpin coupler block (greaseless) #3233 2. Kingpin coupler set screws (4) (40 ft-lb torque) 3. Kingpin coupler bolts with nuts, 5/8" x 5" (2) 4.

  • Page 4: Section 1: Preparation

    SECTION 1: PREPARATION Unpack your Ultimate 5th Wheel Connection kit and compare it with the Parts List on the Page 2. If it appears that there are missing or damaged items caused by shipping and handling, contact the freight carrier who delivered the unit for their damaged freight procedures.

  • Page 5: Section 3: Attaching The Remote Latch Cable

    2-4. Using a 1/4" allen wrench, tighten the 4 set screws to 40 ft-lbs of torque. NOTE: Because kingpins vary in height, some blocks will have space between the coupler block and the kingpin plate (see picture on right) while others will be flush. This is normal and does not impact the performance of your Ultimate Connection in any way.

  • Page 6: Section 4: Installing The Base Unit

    SECTION 4: INSTALLING THE BASE UNIT 4-1. Place the Ultimate Connection base into the rails already installed in the bed of your truck. Standard & Long Bed Trucks For standard and long bed trucks, the base should be installed with the ball closer to the cab of the truck.
