DYNAPULSE DP-200M/Education Quick Manual

Non-invasive blood pressure monitoring and recording system
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

DP-200M/Education
Congratulations, and thank you for choosing the USB-Version PC
based DynaPulse 200M/Education non-invasive blood pressure
Note: This USB Version DynaPulse (DP-200M/Education/USB) blood pressure monitor applies
standard PC-USB connection to provide Serial DATA communication and DC power to DynaPulse
monitor. USB drivers and DynaPulse software must be installed to your PC for proper operation of
I. Install software and getting ready:
Before you start installing DP-200M/Education/USB hardware and software, please check and make
sure you have following items ready:
 DP-200M/Education/USB monitor
 USB communication cable
 Blood Pressure cuff assembly (Use appropriate size cuff)
 DP-200M/Education/USB software for Windows CD (Include USB drivers)
 A PC with Windows operation system (Windows 2000, XP, Vista or Win-7), and an available
USB communication port.
Getting ready with DP-200M/Education/USB monitor and connect it to a PC:
 Install USB drivers: Following instructions on provided Software CD to install correct USB
drivers to your PC.
 Connect USB cable, one end to DP-200M and the other end to PC's USB- port.
 Connect Cuff assembly to DP-200M (Use appropriate size cuff for each patient.)
Quick Guide for
monitoring and recording system.
DynaPulse monitor.
www.DynaPulse.com
1
(USB)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP-200M/Education and is the answer not in the manual?

Questions and answers

Related Manuals for DYNAPULSE DP-200M/Education

Summary of Contents for DYNAPULSE DP-200M/Education

  • Page 1 Note: This USB Version DynaPulse (DP-200M/Education/USB) blood pressure monitor applies standard PC-USB connection to provide Serial DATA communication and DC power to DynaPulse monitor. USB drivers and DynaPulse software must be installed to your PC for proper operation of DynaPulse monitor.
  • Page 2  Note: First-time installation of DP-200M software, an automatic COM check window will appear, click “Continue” to find and select an available COM port.  Read included hardcopy Manual/User’s Guide of DP-200M/Education system for detail instructions of using/operating and the features of DP-200M/Education software. USB users may ignore the parts on battery and RS232 sections.
  • Page 3  A successful measurement will display the measured Systolic, Diastolic, Heart Rate and Pulse waveform, etc.. To keep this measurement, go to “File” and select “Save”. You may enter comments for this measurement. www.DynaPulse.com...
  • Page 4 (patient or it’s owner’s) information.  Go to “Record” in Main Menu and select “Record Table”, a tabulated display of previously recorded blood pressure measurement data will be displayed.  For other advanced features, please read DP-200M/Clinical manual (User’s guide) page 51-69. www.DynaPulse.com...
  • Page 5 (MAP). It records and displays arterial pulse waveform for visual identification of irregular heartbeats and/or measuring artifacts. Via optional DynaPulse Analysis Center (DAC) online analysis service, it can also provide cardiovascular hemodynamic profiles for advanced managements of Hypertension, CVD and CHF.
