  • Page 1 200M Home for Windows ’ UIDE DY N A P U L S E 2 0 0 M...
  • Page 2 For your reference, this User's guide describes the hardware and software functions and features of DP-200M/Home with RS232 communication. USB DP-200M users shall follow the Quick Guide instructions to install USB drivers and software, and use USB connection instead. USB DP-200M is powered via USB, NO Battery is required.
  • Page 3 Screen shot(s) © 1985-1997 Microsoft Corporation. Reprinted with permission from Microsoft Corporation. Macintosh is a registered trademark of Apple Computer, Inc. Pulse Metric is a registered trademark and DynaPulse is a trademark of Pulse Metric Incorporated. Microsoft is a registered trademark and Windows is a trademark of Microsoft Corporation.

  • Page 4: Table Of Contents

    Table of Contents Introduction Blood Pressure Defined How is Blood Pressure Measured? What is Mean Arterial Blood Pressure? Facts About Hypertension The DynaPulse Blood Pressure System Tips for an Accurate Measurement System Requirements and Setup System Requirements Equipment Layout Installing the Batteries...
  • Page 5 The Record Table The Personal Information Record Retrieving the Measurement Display Display Options Printing The Tool Window Appendix Warranty and Service Information Software Licensing Agreement COM Port Configuration Selecting the Correct Cuff Error Messages DynaPulse Accuracy and Tips for Use Specifications...

  • Page 6: Introduction

    Introduction Thank you for purchasing the DynaPulse. To use this system correctly and safely, read this manual carefully before operating the DynaPulse. Retain this manual together with the DynaPulse for future reference. NO MEDICATION CHANGES SHOULD BE MADE BASED ON INFORMATION PROVIDED BY THE DYNAPULSE SYS- TEM WITHOUT FIRST CONSULTING A PHYSICIAN.
  • Page 7 Used to call your attention to an important feature of the system, or system software. This manual is a guide to installing and using the DynaPulse blood pressure recording system. Pulse Metric recommends that all users read this manual before they begin using the...

  • Page 8: Blood Pressure Defined

    Blood Pressure Defined Blood pressure is defined as the force generated by the blood as it flows through the arteries. The heart pumps the blood through the arteries, which act as "pipes" to carry the blood away from the heart. This pumping action causes the blood pressure to rise and Introduct fall.
  • Page 9 The estimations are based on large amounts of data, and are usually accurate, but they are still estimations. Pulse Dynamics, the patented DynaPulse technology, also mea- sures the pressures generated by the cuff and the arterial pulsation. However, it is the only oscillometric method to measure blood pressure based on physical phenomena, much like the auscultatory method.

  • Page 10: What Is Mean Arterial Blood Pressure

    What Is Mean Arterial Blood Pressure? Mean arterial pressure is the average pressure in the artery over time. High pressures cause the artery to bulge, like a balloon when it is inflated. At very low pressures, the artery actually bends inward slightly.

  • Page 11: Facts About Hypertension

    Facts About Hypertension Hypertension is described as a persistently elevated blood pressure that exceeds predetermined thresholds. The Sixth Report of the Joint National Committee on Detection, Evaluation, and Treatment of Hypertension estimates that 50 million Americans have blood pressures that consistently equal or exceed 140/90 mmHg, and are therefore at increased risk for developing cardiovascular diseases such as coronary heart disease and peripheral vascular disease.
  • Page 12 Hypertension as a risk factor for cardiovascular disease Hypertension increases the risk for developing many cardiovascular diseases, including atherosclerosis and left ventricular hypertrophy. Other risk factors for cardiovascular disease include: smoking, Introduc diabetes mellitus, lack of exercise, and excessive alcohol intake. Hypertension management Mild cases of hypertension can be treated effectively by non-drug therapies.

  • Page 13: The Dynapulse Blood Pressure System

    The DynaPulse is linked to the computer and its software by the communications cable. All of the data is stored, displayed, and analyzed on your computer.
  • Page 14 • Repeated deep breaths, coughing, sneezing, and talking may affect the reading. The patient should relax and remain motionless during each blood pressure measurement. • A rolled-up sleeve may constrict blood flow through the arm. Putting all or part of the cuff on top of a sleeve may affect the reading’s accuracy as well.

  • Page 15: System Requirements

    System Requirements To operate the DynaPulse, you will need the following equipment: • 80386 or higher IBM, or IBM compatible computer with 2 Mb of RAM, a hard disk drive, and a CD-ROM/floppy What You Nee disk drive. •Windows 3.x running in standard or enhanced mode, or Windows 95/98, NT, 2000 or XP.

  • Page 16: Equipment Layout

    Equipment Layout DynaPulse measurement unit Serial Communications Cable Pressure Bulb with Valve Pressure Cuff, Hose and Connector...

  • Page 17: Installing The Batteries

    Connecting the DynaPulse to the Computer Connect the RS-232 cable from your computer's serial communica- tions port (hereafter referred to as the COM port) to the DynaPulse unit. If your COM port uses a 25 pin connector, use a 9 to 25 standard pin adaptor.

  • Page 18: Installing The Software

    OK. If the drive letter is different than the one shown in this example, enter the correct drive letter. If you have a previous version of DynaPulse installed on your hard disk and want to maintain the same measurement files created with...

  • Page 19: Main Menu

    The Main Menu File Edit User Measure Trend Record Options Window Help Store measurement and personal information to disk. Print the currently selected display. Print the screen. Exit the program. Cancel the previous edit operation. Cut selected text from the Record Table or Personal Info display. Place selected item onto the Windows Clipboard.
  • Page 20 Retrieve the measurement Waveform Display Display or edit personal medical information. Display blood pressure measurements in tabular form. Select the communications port to be used by the DynaPulse. Find the communications port used by the DynaPulse. Reset the unit due to environmental changes.

  • Page 21: Adding A New User

    Adding a New User From the User menu, select Add... The "Enter ID" dialog box will open. Enter a unique, easy to remember ID for the user. The ID cannot contain spaces or punctuation, and cannot exceed 9 characters. Click OK. The user "Name"...

  • Page 22: Selecting A User

    Selecting a User When you open the program the "User List" screen will appear. Double click on the name that you wish to use. If you have taken measurements then . . . The selected user's "Trend" screen will appear, and you are given the opportunity to recall measurements, and print the "Trend Display"...

  • Page 23: The User List

    The User List The User List displays the name, data directory, date and time in the Status Bar. Users are listed by name, ID and data directory of each user. The default user is "Guest". Measurement informa- tion cannot be saved for the GUEST user. A user from the User List must be selected before taking a measurement to allow full use of program functions.

  • Page 24: Deleting A User

    DELETE from the User options. Getting Started Sorting The DynaPulse is an FDA-registered device and generates clinical data. While the program will delete a user from the User List, the program will not delete the measurement data produced by the user.

  • Page 25: Sorting The User List

    Sorting the User List The User List can be sorted by either user name or user ID. To sort the User List by ID, select USER from the Main Menu. Select SORT and choose the BY ID NUMBER option. The User List will be sorted with the lowest number first.

  • Page 26: Performing A Zero Reset

    Zero Reset will compensate for these variations. Select ZERO RESET from the OPTIONS menu. Follow the on-screen prompts to complete the calibration. NOTE: Do not reset the DynaPulse before each measurement. Reset the DynaPulse only if a large change in temperature or humidity is noticed.

  • Page 27: Putting On And Using The Cuff

    Putting On And Using The Cuff Loop the cuff with the Velcro interlock on the inside. If the cuff does not fit, switch to a different cuff size. See Selecting the Correct Cuff. Locate the brachial artery on the left arm. It is located on the inner side of the upper part of the arm.
  • Page 28 Fold the end of the cuff so that it fastens onto the Velcro panel. Don't put the cuff on too tightly. Plug the tube connector into the DynaPulse unit. Close the release valve on the pressure bulb. (Turn the knob clockwise completely.)
  • Page 29 The arm should rest on a table surface. Do not let the cuff rest on any other surface. When the program asks you to start pumping, squeeze the pressure bulb to pump up the cuff. When the program has completed its measure- ment, release the remaining air pressure in the cuff by slowly turning the valve counterclock- wise.

  • Page 30: Taking A Blood Pressure Measurement

    Taking A Blood Pressure Measurement Select the START option from the MEA- SURE menu. Put the cuff on the arm and press ENTER, or click OK. For further information regarding correct cuff placement, see Using The Cuff. Adjust the Air Release Index (the knob on the unit) to the appropriate value.
  • Page 31 Begin pumping. Don't pump You will see the indicator too fast. Click Quit or press rise as the pressure increases. ESC to abort. The measurement will start Stop pumping only when at the selected upper limit the program tells you to. setting.

  • Page 32: The Measurement Display

    The Measurement Display Wavefo CURRENT TIME CURRENT USER ARTERIAL AT CURSOR AND DATE USER NAME DIRECTORY PULSE POSITION DATE AND TIME OF MEASUREMENT TIME MEASUREMENT SCALE (IN SECONDS) SYSTOLIC, MEAN DIASTOLIC CUFF CUFF PRESSURE PRESSURE AT CURRENT INDICATORS (LEFT TO RIGHT) OF SCALE CURSOR POSITION POSITIONS IN PRESSURE WAVE...
  • Page 33 At these points the cuff pressure was equal to (from left to right) systolic, mean arterial, and diastolic blood pressures. The Pulse Dynamic algorithm used by the DynaPulse products uses pattern recognition to determine blood pressures.
  • Page 34 For convenience, the blood pressures are displayed on the top right hand corner of the screen, along with heart rate. When first looking at the waveform, one may immediately notice two striking features: the pressure oscillations (the peaks and valleys) , and the increasing then decreasing height of the oscilla- tions with time.
  • Page 35 Estimated Measurements The DynaPulse has the capability to estimate one measurement parameter (such as systolic), provided that it has measured the other two. An estimated measurement can be distinguished from other measurements by the presence of a highlighted background. Estimated measurements occur when either the High or Low Range is not set correctly.

  • Page 36: Adjusting The Measurement Settings

    Adjusting Measurement Settings When taking the first set of measurements for a new user, you should adjust the cuff size and Air Release index for the user. This may require a few test measurements. Once these parameters have been set, however, they will be saved along with the user's data and will not need to be adjusted.
  • Page 37 Adjusting the Air Release The total measurement time should be 25-35 seconds. Measure- ment time is displayed above the arterial waveform (in seconds). If the total measurement time is outside this range, the Air Re- lease index needs to be adjusted. Adjust the Air Release index by choosing AIR RELEASE from the MEASURE menu.
  • Page 38 Adjusting the High and Low Range Settings The HIGH and LOW RANGE features enable the user to set HIGH and LOW blood pressure limits. The default settings are 160 (systolic) and 50 (diastolic) mmHg. The HIGH RANGE varies from 100 to 280 mmHg in 20 mmHg increments.

  • Page 39: Saving User Data

    Saving User Data Select FILE from the Main Menu, then select SAVE. The current measurement or personal information will be saved in the user's data directory. If you try to produce another blood pressure measurement without saving the current measurement or personal information, you will be asked if you want to save the current data.

  • Page 40: The Trend Display

    The Trend Display The Trend Display is another informative feature of the DynaPulse system. With it, you can track an unlimited amount of measurement data (the actual limit is determined by the size of your hard disk storage) for each user.
  • Page 41 The Trend Display MEASUREMENT TIME & DATE CURRENT DATA USER NAME RESULTS AT OF MEASURE- DIRECTORY TIME & DATE MENT CURSOR POSITION GUIDELINES OF BLOOD PRESSURE THRESHOLD (140/90) BLOOD PRESSURE COMMENT HEART RATE CURSOR SCALE ( IN mmHg ) LINE SCALE ( IN BPM) SCROLL BAR...

  • Page 42: The Record Table

    The Record Table The Record Table lets you view measurement data in tabular form. When measurement data is saved, the systolic, mean Personal arterial and dias- tolic pressures along with heart rate are automati- cally entered into the Record Table. Additionally, any comments will be displayed with the...

  • Page 43: The Personal Information Record

    The Personal Information Record Choose PERSONAL INFO from the RECORD menu. The Personal Information Record may be used to store relevant medical, doctor, hospital and insurance information. Enter the information as needed. Save the information by selecting SAVE from the FILE menu.

  • Page 44: Retrieving The Measurement Display

    Retrieving the Measurement Display Recalling measurement data from the Trend screen is accomplished quickly by either double-clicking on measurement, or choosing the measurement and pressing the ENTER key. A Measurement Display may also be retrieved by selecting the measurement and choosing RETRIEVE from the TREND menu.

  • Page 45: Display Options

    Display Options: Cascade, Tile, and Close All One feature of the DynaPulse for Windows is the ability to display multiple measurements on the screen. This feature is useful if you wish to compare data from different mea- surements. Features like the CASCADE...
  • Page 46 Display Options: Arrange Icons You may also "clean up" the display screen and still have several measurements available for your review by using the ARRANGE ICONS option from the WINDOW menu. Any Measurement, Trend, Record Table, or User List may be minimized and arranged Printing by selecting this feature.

  • Page 47: Printing

    This is also true for selections arranged using the CASCADE or TILE feature. NOTE: Print quality is directly related to the printer used and the printer driver selected. The DynaPulse program will print the active window only.

  • Page 48: The Tool Window

    The Tool Window The SHOW TOOL WINDOW located under the OPTIONS menu is a convenient way to operate the DynaPulse system. The Tool window contains controls that you use the most. Once selected, the Tool window can remain in the display area for easy access until you close it.

  • Page 49: Appendix

    Appendix Warranty Information Software Licensing Agreement COM Port Configuration Selecting the Correct Cuff Error Messages DynaPulse Accuracy Tips For Accurate Blood Pressure Measurements Specifications...

  • Page 50: Warranty And Service Information

    Warranty Information Pulse Metric, Inc. warrants that the DynaPulse system unit will be free from defects in workmanship and materials for a period of one year from the date of purchase. This one year warranty extends only to the original purchaser. All other accessories (pressure cuff, RS-232 cable, etc.) will be warranted for 90...

  • Page 51: Software Licensing Agreement

    PMI software product from your computer and disk archives and promptly return the disk package and the accompanying items (manuals, DynaPulse unit, and all accessories) to the place you obtained them for a full refund.

  • Page 52: Com Port Configuration

    Windows 95/98 is capable of detecting most standard COM ports, therefore we recommend that you use the standard serial ports (COM 1 or COM 2) for your DynaPulse. If the use of COM ports 3 or 4 is necessary, the configuration procedure is provided below.

  • Page 53: Selecting The Correct Cuff

    Selecting the Correct Cuff The American Heart Association makes the following recommenda- tions with regard to determining the correct cuff size: ♦For adults, the bladder inside the cuff should encircle 80% of the arm. ♦For children less than 13 years of age, the bladder should encircle 100% of the arm.

  • Page 54: Error Messages

    If you are using the DynaPulse for the first time, verify that the I/O PORT option is set to the port that the DynaPulse is connected to.
  • Page 55 Air Release Too Fast If you receive this message, check for cuff leaks or hose and connector leaks. If no leaks are found, check the mea- surement time (the time scale is located Messages Messages above the arterial waveform). The total measurement time should be 25-35 seconds.
  • Page 56 ♦The DynaPulse program requires that you pump over the selected "HIGH" range so the DynaPulse system can obtain useful data at the start of the selected High range. For instance, if the High range is set at 160 mmHg., the program will require the user to pump over 160 before told to stop pumping.
  • Page 57 High Pressure Range is Set Too Low. The DynaPulse did not pump to a sufficiently high pressure to measure the systolic pressure. Messages If the you are asked to increase the HIGH RANGE, choose HIGH RANGE from the MEASURE menu and increase the range by one step (for example 160 to 180).
  • Page 58 Low Pressure Range is Set Too High. The DynaPulse did not measure to a sufficiently low pressure to measure the diastolic pressure. If the you are asked to decrease the LOW RANGE, choose LOW RANGE from the MEASURE menu and decrease the range by one step (for example 50 to 40).

  • Page 59: Dynapulse Accuracy And Tips For Use

    DynaPulse Accuracy All DynaPulse systems are clinical-grade. The DynaPulse is FDA- registered, and meets or exceeds Association for the Advancement of Medical Instrumentation (AAMI) standards for non-invasive blood pressure monitors. However, like any other device, proper use of the DynaPulse is essential for accurate measurements.
  • Page 60 General Tips The following suggestions will increase the accuracy of blood pressure measurements in general. They do not apply exclusively to the DynaPulse. •Allow 1-3 minute intervals between measurements • The user should relax and remain motionless during each blood pressure measurement.

  • Page 61: Specifications

    Specifications DYNAPULSE 200M MANUAL PUMP SYSTEM Measurement accuracy: ± 2 mmHg. or ± 2% whichever is greater. Measurement Range: Blood pressure- 20 to 300 mmHg. Pulse- 30 to 200 bpm. Deflation method: Air release valve Inflation method: Manual pump, using rubber bulb Power Consumption: 60mW when measuring Operating temperature: 0°C to 45°C (32°F to 113°F)
  • Page 62 2100 Hawley Drive Vista, California 92084 telephone 760 .842 .8278 . fax 760.758 .9425 www.dynapulse.com...
