The proper installation and maintenance of all our products is the responsibility of the user unless you have asked 4B to perform these tasks. B. All installation and wiring must be in accordance with Local and National Electrical Codes and other standards applicable to your industry.
Page 5
3. SELECT A QUALIFIED AND COMPETENT INSTALLER Correct installation of the product is important for safety and performance. If you have not asked 4B to perform the installation of the unit on your behalf, it is critical for the safety of your operation and those who may perform work on your operation that you select a qualified and competent electrical installer to undertake the installation.
WARNING • Rotating machinery can cause serious injury or death • Always lockout and tagout the machine prior to installation PRODUCT OVERVIEW The P300 is an inductive sensor designed to detect shaft speed, shaft position, gate position, or object presence. No contact is made between the sensor and the object being monitored. Maximum range of ferrous targets is 8 mm (5/16”) and for non-ferrous targets is 5 mm (6/16”), assuming a 20 mm (3/4”) diameter target.
APPROVALS Baseefa12ATEX0226X 1G Ex ma IIC T4 Ga ATEX 1D Ex ma IIIC T 110°C Da Tamb -15°C to 50°C, IP66 IECEx BAS 12.0118X Ex ma IIC T4 Ga IECEx Ex ma IIIC T 110°C Da Tamb -15°C to +50°C IP66 PAGE 7...
DIMENSIONS Locknuts 3m Long Cable 20 AWG Cores 6.2 mm Overall Cable Diameter 1-3/16” 30 mm 2-3/4” 69 mm 1-7/16” 3-5/8” 36 mm 92 mm Red LED - Output INSTALLATION The P300 should be wired as shown in the connections diagram on page 10. The P300 Proximity Switch must be wired through a load/resistor (see standard wiring diagram) and not directly to supply voltage.
Page 9
Fasten the P300 to a suitable mounting bracket, such as 4B’s Whirligig® universal shaft sensor mount, with the nose of the switch within the sensing range of the target, as shown below - P300 Shown on Optional Whirligig®...
STANDARD WIRING DIAGRAM All wiring must be In accordance with local and national electrical codes and should be undertaken by an experienced and qualified electrician. Where necessary, use dust/liquid tight flexible metal conduit with approved fittings to protect the sensor cables.
Page 11
P3003V34AI (+V to Blue) P3003V34AI (+V to Brown) Note: NPN, Energised (top left) is the standard wiring to use this sensor with all the 4B controllers. PAGE 11...
4. If monitoring for speed see A, for proximity monitoring see B - A. If the P300 is being used to monitor speed, 4B’s SpeedMaster™ calibration and testing device can be used to insure the P300 shuts down the machine at the correct percentage of slip. Shut down will depend on your specific monitoring setup.
TROUBLESHOOTING GUIDE FAULT REMEDY • Check that the sensing face of the sensor is not bolted directly to metalwork • Check that there is a space between the sensor face and any surrounding metalwork (30mm minimum) LED Stays “ON” • Check that the machinery is rotating and that the target is actually leaving the sensor before reappearing •...
4B France herein after referred to as 4B to the original purchaser against defects in workmanship or materials under normal use for one (1) year after date of purchase from 4B. Any product determined by 4B at its sole discretion to be defective in material or workmanship and returned to a 4B branch or authorized service location, as 4B designates, shipping costs prepaid, will be, as the exclusive remedy, repaired or replaced at 4B’s option.
Page 15
THIS PAGE IS INTENTIAONALLY LEFT BLANK PAGE 15...
