symbio CS301 Operating Instructions

Battery Saver Feature

The simulator powers-off automatically about 30 minutes after a key was last
pressed, or after defib or pacer energy was last detected. This is normal operation.
To allow simulator to remain powered-on after 30 minutes, follow these instructions:
1. Power-off simulator.
2. Press and hold down convert key, then press and release ON OFF key.
The simulator powers-on.
3. Observe NSR indicator. When indicator blinks on and off, release convert key.
NSR indicator continues to blink for about one second.
The battery saver feature is now disabled. When you power-off the simulator,
it will return to normal battery saver operation.
The simulator is powered by one 9 volt alkaline battery. To replace the battery, turn
over simulator, then slide open battery compartment door.

Service

The CS301 Code Simulator is warranted to be free of defects in material or
workmanship for three years from date of purchase.
If the simulator needs service, or if you have questions about its operation, please
contact Symbio customer service, or your authorized dealer.
Symbio Corporation
1600 NW Compton Drive
Suite 120
Beaverton, Oregon
U.S.A. 97006
voice: 503.748.2030
fax: 503.748.2031
www.symbiocorp.com
9801-900
4

Getting Started

1. Connect monitor's ECG cable to simulator's ECG snaps. See Figure 1.
2. Connect defibrillation cable to simulator's defib cable receptacle. See Figure 2.
3. Press ON OFF key to power-on simulator. Observe that NSR indicator is
illuminated.
4. Power-on monitor/defibrillator. Observe that NSR at 72 bpm is displayed.
Figure 1
Figure 2
5
Press ECG cable connectors onto
simulator snaps.
Left to right: RL, RA, LA, LL.
ECG signal is obtained with either
3- or 4-lead ECG cable.
Connect defibrillation cable to
simulator. (The connector on
your simulator may be different
from the one shown here.)
WARNING: SHOCK HAZARD!
Be sure defibrillation cable is
securely attached to simulator.
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS
Controls And Indicators . . . . . . . . . . . . . . 1
Rhythms For Defibrillator Training . . . . . . . . 2
Rhythms For External Pacer Training . . . . . . 2
Defibrillator Exercise. . . . . . . . . . . . . . . . 3
External Pacer Exercise. . . . . . . . . . . . . . 3
Battery Saver Feature. . . . . . . . . . . . . . . 4
Service . . . . . . . . . . . . . . . . . . . . . . . . 4
Getting Started . . . . . . . . . . . . . . . . . . . 5
