Spotsee SpotBot Cellular Quick Start Manual

STEP 5
CONFIGURE SPOTBOT UNIT (CONTINUED)
D. Remove the rubber cover from the front of your
SpotBot Unit
E. Connect your computer to the SpotBot using the
Micro-USB Cable provided
F. Push the "Start/Stop" button the front of the SpotBot Unit
Unit ID will appear within the Profile Pop Up Window (shown below)
G. Select the desired "Alarm Threshold"
Note: Impacts at a G-level above the "Alarm Threshold" will send
alarms visible in the SpotSee Cloud
H. Select desired "Summary Time"
Note: Summary time dictates the interval that the SpotBot will
send impact, location, and temperature summaries to the SpotSee
cloud. Less frequent intervals will improve battery life.
I. Click "Save"
Status message will appear noting "Save Successful"
J. Close the configuration window and unplug the
Micro-USB Cable.
This document is written and published by ShockWatch, Inc. All rights reserved.
STEP 6
SPOTBOT IN USE
A. Begin Monitoring – Press "Start/Stop"
Button in the Access Port. The "On" and
"Sending" lights will both flash green.
B. In Use (No Alarm) – When SpotBot is in use and not in process
of sending an alarm to the SpotSee Cloud the "On" light will flash
green every minute if no alarm has occurred. This light will flash
yellow if the unit has low battery life remaining.
C. In Use (Alarm) – If an alarm has occurred, the red "Alarm" light
and the green "On" light will flash every minute.
D. Alarm Triggered – When SpotBot experiences an impact above
the "Alarm Threshold" the "Alarm" (red) as well as the "On" and
"Sending" (green) lights will flash at different intervals. The lights
continue to flash as the SpotBot Unit sends the alarm data to the
SpotSee Cloud.
E. Unit Status Check – To check the status of the SpotBot Unit,
press the "On/Off" button for 1 second. If the "On" light flashes
green and the "Alarm" light flashes red, an alarm has occurred. If
the "Alarm" light does not flash, then no alarm has occurred.
F. Stop Monitoring – Press and hold the
"On/Off" button (for approximately 5 seconds)
until all (3) lights stop flashing and remain on.
For additional operations, please refer to the product manual.
FOR QUESTIONS OR TROUBLE SHOOTING PLEASE
CONTACT TECHNICAL SUPPORT
Email: techsupport@shockwatch.com
ShockWatch Canada & Americas
US: +1 800-466-0101 Outside US: +1 214-736-4579
ShockWatch Europe, Middle East, Africa: +31.55.7370 148
ShockWatch Asia-Pacific: +86 138-1884-4157
QUICK START GUIDE
