- Page 1 Meaco Wall Mounted Dehumidifiers MeacoWall 53B/W MeacoWall 72B/W MeacoWall 103B/W Please read the manual before installation. INSTRUCTION MANUAL [EN] MeacoWall Series...
-
Page 2: Safety Information
If in doubt do not use the dehumidifier and consult a qualified electrician or a Meaco approved engineer. The operator must: Make the operating instruction available for the user and make sure that the user does understand the manual. -
Page 3: Electrical Installation
Electrical Installation 103L Rated Voltage 220 - 240V / 50Hz Power Consumption (kW) 0.93 1.13 1.97 Running current (amps) Start-up current (amps) 5.85 The unit must be installed to a grounded supply in ALL applications If the unit is to be installed in to a wet area (i.e. a swimming pool) please ensure that the mains connections meet the criteria set out in section 602 of BS7671 other equivalent local regulation (non-UK) This unit is supplied without a plug and is expected to be connected to s fused spur by a qualified electrician following local regulations and laws. - Page 4 1. FIRST THING TO DO Before putting your dehumidifier into operation for the first time, the instruction manual should be studied carefully. After receiving the unit, you should check your dehumidifier for any transport damage. In case of damage, you should inform the sender immediately.
-
Page 5: What Is In The Box
3. WHAT IS IN THE BOX 4. INSTALLATION AND TRANSPORTATION For installation and transportation, the following instructions must be considered: The air inlet and the air outlet must not be covered whilst the dehumidifier is in operation. Before moving the dehumidifier it must be switched off by its ON-OFF switch. The dehumidifier must be disconnected at its fused spur and excess water should be drained. -
Page 6: Continuous Drainage
Using the enclosed drills five holes for the wall mounting bracket and secure using the expansion bolts. The wall must be true and the bracket level or water will leak from the dehumidifier. 5. CONTINUOUS DRAINAGE This dehumidifier is designed to be connected to a permanent drain via a 16mm hose. Make sure that the drain connection is running downhill and does not have any kinks or blockages. - Page 7 If you wish to move the drain to the other side then you can do so by removing the side covers. This should only be done by a qualified electrician and only when the unit’s power supply has been turned off and isolated. Remove the one screw as per above to access the side panels.
- Page 8 Connect the condensate hose (16mm diameter) and ensure that the water is flowing downhill with no kinks or blockages. You have the choice of fitting the drain on the right or left side. The hose on the right is pre-fitted, if you wish to change to left then remove the bung from the left and swap it with the hose on the right.
- Page 9 Please keep the dehumidifier upright at all times prior to installation. If the dehumidifier is inclined greater than 60 degrees then the dehumidifier should only be turned on 24 hours after it has been installed. 60° 9 [EN]...
- Page 10 6. CONTROL PANEL AND USING THE DEHUMIDIFIER When you turn the dehumidifier on the display will show 88 and then the program version number for ten seconds. This is to allow the relative humidity sensor to sample the air and to take a reading. The display will dim after 90 seconds of no keys being pressed.
- Page 11 Child Lock Press the On/Off button for 5 seconds to lock the control panel. Repeat to deactivate. Checking the relative humidity set point Press either the up or down arrow once to check what target relative humidity has been set to. Setting the relative humidity set point Use the up or down to set your preferred target relative humidity.
- Page 12 Off Timer When the unit is turned on use this button to determine when the dehumidifier will turn off. On Timer When the unit is turned off use this button to determine when the dehumidifier will turn on. 12 [EN]...
- Page 13 How to change the fan speed. The internal setup parameter 11 is designed to control the fan speed. The default value is 2. Within parameter 11 are the following options: 1 - low speed, 2 - middle speed, 3 - high speed. Press the UP Press the UP Button for 10s to enter the...
- Page 14 Set the fan to run continuously or set the fan to run only when the compressor is on. The parameter 18 is used to control when the fan runs. The default value is 1. 0 -The fan motor will stop running when the dehumidifier reaches the target humidity. 1 -The fan motor will keep running when the dehumidifier reaches the target humidity.
- Page 15 What happens when the machine is running? When it is dehumidifying and when it is not If the dehumidifier is dehumidifying you will see this symbol on the control panel The dehumidifier will continue to dehumidify until the relative humidity is 5%rh below the target and stays there for at least 3 minutes.
-
Page 16: Maintenance
7. MAINTENANCE **Disconnect the power supply before carrying out these tasks** Cleaning the filter To ensure that your dehumidifier has a long operational life please clean the filter at least once every two weeks as a blocked filter will put pressure on the fan and cause damage to the fan motor. The filter can be removed without the need to remove the dehumidifier from the wall and without having to tilt the dehumidifier, the image below only shows the dehumidifier on its side for clarity. -
Page 17: Automatic Defrosting System
Clean the outside with a soft, damp cloth. Do not use anything that will scratch the surface or any detergents. 8. AUTOMATIC DEFROSTING SYSTEM This dehumidifier is equipped with an automatic hot-gas defrosting system. When operating in low temperatures the surface of the evaporator will accumulate frost and this will affect the efficiency of the dehumidifier. When this happens the machine will go into periodic defrosting automatically and the defrost symbol will appear on the display. -
Page 18: Specifications
11. SPECIFICATIONS 103L Temperature Range +10°C to +36°C Relative Humidity Range 30% - 99%rh Rated Voltage 220 - 240V / 50Hz Air flow (m³/h) 450m³/h 600m³/h 750m³/h Noise level at 1 metre dB(A) Power Consumption (kW) 0.93 1.13 1.97 Running current (amps) Start-up current (amps) 5.85 Refrigerant... -
Page 19: Performance Curves
Performance Curves 19 [EN]... -
Page 20: Troubleshooting
The room temperature is lower than +10ºC The fan is not running with temperatures above +10°C. If not the above. Contact a Meaco approved workshop. Conditions are below +10°C Move the dehumidifier to a warmer space. Unit does not defrost Defective bypass relay valve Contact a Meaco approved workshop. - Page 21 13. CHEMICALS 1. This dehumidifier is designed to be used in clean air atmosphere free from corrosive chemicals. The use of chlorine is common in swimming pools and at safe levels will not harm the dehumidifier but excess levels will damage the dehumidifier and invalidate the warranty.
-
Page 22: Warranty And Customer Service
To prevent unnecessary expenses, we recommend that you always carefully read the user’s manual first. If this does not provide a solution, call Meaco and we will be happy to help. This appliance is not intended for use by person (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 23 Meaco are specialists in dehumidifiers and would welcome your comments and questions on this dehumidifier. If you do develop a fault within the first year then please do call us and if we cannot fix the problem over the phone we will be happy to collect the dehumidifier from you at our expense and repair or replace as appropriate.
