Brinno ATH2000 User Manual

Construction Power
Housing
ATH2000
User Manual
www.brinno.com
www.brinno.com/support/registration
For manuals in other languages, visit
www.brinno.com/support
The product features, specifications sheets and instructions
may differ from actual products. Please refer to Brinno official
site for the latest version of user manual.
EN_A2 301-0126-01

In the Box

1
Camera Mounting Adapter
Construction Power Housing
Extension Lens Cover
(for Brinno BCS lens)
Battery Slot
Micro USB Type C Adapter
Screwdriver
Strap (x2)
Desiccant

Install Camera

3
1. Remove camera
mounting screw.
2. Depends on different cameras, install a screw to their
respective positions.
2
1
4
1. TLC130
2. For future model use
6
3. TLC120
3
7
4. TLC2000 (with kit lens)
5. TLC200/TLC200Pro (with kit lens)
6. TLC2000 (with BCS lens)
7. TLC200 Pro (with BCS lens)
5
1
3
4 6
2
5 7

Parts of Device

2
Kit Lens
Cover
Tripod Socket
(1/4 inch)
Tripod Socket
(1/4 inch)
Cord Hole (for optional
power input accessories)
3. Tighten screw until secure.
Make sure the camera is facing to front.
Latch
Padlock Eyelets
External Power Cable
(Micro USB connecter)
Battery Level
Check Button
Battery Level Indicator

Install Batteries

4
1. Loosen the screw and remove battery slot from power housing.
2. Install batteries.
Camera
Mounting Screw
Thumb Screw
