EVODESK STUDIO L
The Studio L upgrade replaces two components on the standard Evodesk to accommodate
the larger desktop. An extended side bracket and extended foot are included in the Studio L
box. There will be an extra standard foot and standard side bracket, should you decide to
change desktops.
TOOLS REQUIRED
Phillips Head Screwdriver
and/or Power Drill
Additional Components Included
Extended foot
16
No.
17
16
For technical support visit evodesk.com/support
Extended
Side Bracket
x1
No.
10
Leveling Studs
x1
17
13
Phillips Screws
10-24 x ½"
x1
10
No.
Studio L Assembly - 1
x9
13b
No.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for evodesk Studio L
Summary of Contents for evodesk Studio L
- Page 1 The Studio L upgrade replaces two components on the standard Evodesk to accommodate the larger desktop. An extended side bracket and extended foot are included in the Studio L box. There will be an extra standard foot and standard side bracket, should you decide to change desktops.
- Page 2 In Step 4 of the desk manual, replace one of the default side brackets with the extended side bracket from this kit. In Step 9 of the desk manual, use 7 10-24 x ½” (#13-b) Phillips Screws to connect the frame to the desktop. v.3.10.17 Studio L Assembly - 2...
