O P E R A T I N G I N S T R U C T I O N S
The Monarch® 9462™ Single-Station Battery Charger charges one
7.4V lithium-ion battery (p/n 12009502) at a time.
Note: You must charge a battery before using it.
Information in this document supercedes information in previous
versions. Check our Web site
(www.printers.averydennison.com/en/home.html) for the latest
documentation and release information.
♦ Use only a Monarch-qualified battery. The battery could be damaged or explode if
placed on a different charger.
♦ Do not charge non-rechargeable batteries in this charger.
♦ Do not throw the battery in the trash. Dispose according to your local regulations.
♦ Do not disassemble, short-circuit, heat above 80°C, or incinerate the battery. It may
explode.
♦ Follow the operating and storage limit specifications listed at the end of these
instructions. Otherwise, the battery may permanently lose its charge capacity.
♦ The unit is for use only with Listed ITE.
S e t t i n g U p t h e E q u i p m e n t
To set up the equipment:
1. Plug one end of the power supply into a
wall electrical outlet.
2. Plug the other end of the power supply
into the back of the charger. The Power
LED is on when the charger is set up and
plugged in.
C h a r g i n g t h e B a t t e r y
To charge the battery, insert the battery into
the charger as shown. Charging time can take
up to three hours. It takes approximately 2 hours
to reach the 80% level (where it is now usable).
To reach 100%, it takes approximately 1 hour
more.
TC9462OI Rev. AR 11/17
WARNINGS:
©2009 Avery Dennison Corp. All rights reserved.
