NOTICE
When handling supplemental restraint system components (removal,
installation or inspection, etc.), always follow the direction given in the repair
manuals listed above to prevent accidents and supplemental restraint
system malfunction.
FOREWORD
This wiring diagram manual has been prepared to provide
information on the electrical system of the 2000 MR2.
Applicable models: ZZW30 Series
For service specifications and repair procedures of the above
models other than those listed in this manual, refer to the
following manuals;
Manual Name
D 2000 MR2 Repair Manual
D 2000 MR2 New Car Features
All information in this manual is based on the latest product
information at the time of publication. However, specifications
and procedures are subject to change without notice.
Pub. No.
RM760U
NCF179U
1
