Summary of Contents for grado RM210
- Page 1 Ear INFrarED thErmomEtEr INStrUCtIoN maNUaL...
- Page 2 ImPortaNt SaFEtY INStrUCtIoNS...
- Page 3 rEaD thIS BEForE USING the following basic safety precautions should always be taken. Close supervision is necessary when the thermometer is used by, on, or near children, handicapped persons or invalids. Use the thermometer only for the intended use described in this manual. Do not use the thermometer if it is not working properly, or if it has suffered any damage.
-
Page 4: Table Of Contents
taBLE oF CoNtENt Cautions and Warnings Restrictions of Use introduction Package Contents Thermometer Parts lCD screen Replacing the Battery About normal Body Temperature & Fever Using the Device Replacing lens Filter Taking ear Thermometer hints on Taking ear Temperature Recalling the Memory Viewing Results on a Personal Computer... - Page 5 Care & Cleaning Fever indicator Troubleshooting specifications symbol information Warranty...
-
Page 6: Cautions And Warnings
Class ii Medical Device according to Directive eeC 93/42 and subsequent amendments CaUtIoNS aND WarNING As with any thermometer, proper technique is crucial to getting accurate temperature readings. Please read this manual thoroughly and carefully before using. Always store the thermometer in a cool and dry place: temperatures between -20C°... -
Page 7: Restrictions Of Use
rEStrICtIoN oF USE This thermometer is clinically proven to produce accurate temperature measurements. However, please be advised if you have the following situations: The accuracy cannot be ensured for a person who has deformity in the ear such that the thermometer probe can not be properly inserted into the ear canal. - Page 8 INtroDUCtIoN Thank you for choosing RM210 infrared ear thermometer GRADO by Moretti Spa. This innovative medical device relies on on advanced infrared (IR) technology to measure temperature instantly RM210 ear thermometer is an elegantly designed infrared thermometer meant for your family.
- Page 9 LCD. NotE The thermometer does not emit any infrared signal. rEGULatIoN The ear infrared thermometer GRADO by Moretti Spa is in accordance with the following regulation: EN 980 EN 1041 EN 12470 - 5...
-
Page 10: Package Contents
PaCKaGE CoNtENtS RM210 Two 1.5V AAA Ear Thermometer Batteries Lens Filter User’s Manual Storage Case... -
Page 11: Thermometer Parts
thErmomEtEr PartS Lens filter Lens filter ejection button On/Memory button Sticker Battery cover Data port Probe lens Probe Lens filter detector Scan button... -
Page 12: Lcd Screen
LCD SCrEEN... - Page 13 Ear temperature indicator Non-lens filter warning Temperature scanning in progress Temperature display Memory mode Record numbers Low battery indicator Temperature unit Temperature indicator for memory mode Communication symbol...
-
Page 14: Replacing The Battery
rEPLaCING thE BattErY The thermometer comes with two 1.5V AAA alkaline batteries. Replace it when “ ” appears. Please follow the steps to replace new batteries. StEP 1 Remove the battery cover. StEP 2 Place the new battery in the battery compartment and press it in until the battery is firmly secured. - Page 15 StEP 3 Reattach the battery cover. NotE Although the thermometer works when “ ” appears, we still recommend that you change the battery to obtain an accurate result. Remove the battery if stored for a long period of time. The battery should be kept out of reach of children. if they are swallowed, promptly see a doctor for help.
-
Page 16: About Normal Body Temperature & Fever
aBoUt NormaL BoDY tEmPEratUrE & FEVEr Body temperature can vary from one individual/person to next. It also varies by location on the body and different time of the day. Below shows the statistical normal ranges from different sites. Please keep in mind that temperatures measured from different sites, even at the same time, should not be directly compared. -
Page 17: Using The Device
USING thE DEVICE replacing Lens Filter StEP 1 Check the lens filter is clean and new. StEP 2 Attach new lens filter into the probe. now, you can start to test your ear temperature. NotE if a lens filter is not attached on the probe, lCD will show “... - Page 18 StEP 1 Make sure lens filter is firmly attached to the probe. StEP 2 Press and release the On / Memory button to turn on the thermometer. When ready, the thermometer displays the last measurement. StEP 3 Gently fit the probe into the ear canal.
- Page 19 StEP 4 Press and release the Scan button. Do not remove the thermometer until it beeps. StEP 5 Read the result. “ ” is shown together with a temperature value. StEP 6 Discard used lens filter into trash by pressing lens filter ejection button. NotE Turn off the thermometer by pressing On / Memory button twice.
-
Page 20: Hints On Taking Ear Temperature
hINtS oN taKING Ear tEmPEratUrE 1. As with other of thermometer, you may observe slight variations in consecutive measurements. it is recommended that you take 3 temperature readings and use the highest one for the following situations: Infants younger than 3 months old. Children younger than 3 years old and who have a compromised immune system and the presence / absence of fever is critical. -
Page 21: Recalling The Memory
rECaLLING thE mEmorY Your thermometer stores 10 recent readings in the memory. StEP 1 Be sure the thermometer is OFF before recalling this memory. StEP 2 Press the On / Memory button to turn on the thermometer. StEP 3 Press the On / Memory button for 3 seconds to enter memory mode. - Page 22 StEP 4 Exit the memory. Press the Scan button and LCD will show latest results with flashing “ ” . Then press On/Memory button again and LCD will show “ OFF ” to exit memory.
-
Page 23: Viewing Results On A Personal Computer
VIEWING rESULtS oN a PErSoNaL ComPUtEr Results in memory can be transmitted to the personal computer by either cable or wireless connection for RM210 (OPTIONAL). traSmIttING Data VIa CaBLE (oPtIoNaL) Step 1 Install Software Install Software on your computer. Step 2 Connect to Personal Computer Connect the interface cable to a serial port on the back of your computer. - Page 24 StEP 3 traSmIt Data Follow the instructions provided in the software to transmit data. Results transmitted will include date and time. Remove the cable and the thermometer will automatically turn off.
-
Page 25: Care & Cleaning
CarE & CLEaNING If you would like to clean the probe lens, wipe it gently with an 70% alcohol swab or soft cloth moistened with 70% alcohol. Do not attach a new lens filter within 30 minutes. The probe is not waterproof. Please wipe with a clean cloth which is dry or damped with 70% alcohol. -
Page 26: Troubleshooting
troUBLEShootING The table below shows problems you may encounter. All error messages below would be shown together with orange backlight. Please follow “what to do” to resolve problems. If the problem still exists, please call your local dealer for help. message What it means What to do... -
Page 27: Specifications
SPECIFICatIoN model no. RM210 Dimensions 160.5mm(W) x 45.9mm(H) x 32.5mm(D) 98.33g (include 2 x1.5V AAA Weight batteries) Battery 2 x 1.5V AAA alkaline batteries Displayed temperature range 32C° to 43C° (89.6C° to 109.4C°) Display resolution 0.1 C° ± 0.2C°(±0.4F°) for the range of 36.0C°... - Page 28 Symbol referent Consult Instruction for use Keep away from sunlight Keep dry Temperature limitation Date of manufacture Manufacturer Serial number Caution, consult accompanying documents Authorized representative in the European community CE mark Type BF equipment Do not use if package is damaged...
- Page 29 trEatmENt oF BattErIES - (Directive 2002/96/EC) At the end of its life, the product must not be disposed of along with other domestic waste. The users must dispose of this equipment by bringing it to a specific recycling point for electric and electronic equipment or at retailers that provide this service.
-
Page 30: Warranty
WarraNtY The product has 2-YEAR warranty from purchase date which is certified by the receipt or invoice. The distributor reserves the right either to repair or replace necessary parts to correct defects in the materials or workmanship without any charge. The warranty does not apply to damage resulting from failure to follow the operating instructions, accidents, abuse, alteration or disassembly by unauthorized individuals.
