3.2 Electrical connection Basic knowledge 4.1 Function principle of Identification Systems 4.2 System topology 4.3 Read distance/offset 4.4 Product description 4.5 Data security 4.6 IO-Link basic knowledge Technical Data BIS L-409-045-001-07-S4 BIS L-409-045-002-07-S4 BIS L-409-045-003-07-S4 BIS L-409-045-004-07-S4 Appendix Ordering code Accessories www.balluff.com...
BIS L-409 IO-Link Device Processor Notes to the user 1.1 About this This manual describes processors in the series BIS L-09-... identification system as well as manual startup instructions for immediate operation. 1.2 Structure of the The manual is organized so that the sections build on one another. manual Section 2: Basic safety information.
BIS L-409 IO-Link Device Processor Notes to the user 1.5 Abbreviations Balluff Identification System Cyclic Redundancy Code Direct Parameter Page Electromagnetic Compatibility Least Significant Bit Most Significant Bit Personal Computer Standard IO SPDU Service Protocol Data Unit Programmable Logic Controller Transmission Control Protocol www.balluff.com...
BIS L-409 IO-Link Device Processor Safety 2.1 Intended use BIS L-09-... processors together with the other components of the BIS L system comprise the identification system. They may be used only for this purpose in an industrial environment corresponding to Class A of the EMC Law.
In addition to the processor with integrated read head, the following processors with remote read head are available. The processors with remote read head are also tightened using M screws to a max. tighten- ing torque of 15 Ncm: Fig. 2: Processor dimensions in mm BIS L-09-05-002-07-S, Clear zone www.balluff.com...
Page 8
BIS L-409 IO-Link Device Processor Getting Started Fig. : Processor BIS L -S, dimensions in mm -09-05-00-07 Clear zone Fig. : Processor BIS L -09-05-00-07 -S, dimensions in mm Clear zone...
Page 9
When installing two BIS L-09-... on metal there is normally no mutual interference. Unfavorable use of a metal frame can result in problems when reading a data carrier. In this case the read distance is reduced to 80% of the maximum value. In critical applications a pre-test is recommended. www.balluff.com...
Item Display Function LED 1 green Supply voltage present LED 2 yellow Tag Present Data line IO-Link port (M12, A-coded, female) Function +2 V ► Connect data line to IO-Link Master. (See Balluff IO-Link catalog for connection cable and accessories)
Page 11
The operating mode is set using jumpers in the processor (X): – IO-Link mode, jumper setting as shown in Fig. 7 (factory default setting) – Service mode - to be used only by Balluff service The baud rate is set using two DIP switches S101 and S102: S102 S101...
BIS L-409 IO-Link Device Processor Basic knowledge 4.1 Function The BIS L-09-... Identification System is a non-contact read-only system. The compact proces- principle of sor consists of processing circuitry with a fixed read head. Identification The system may be used to read information which has been permanently programmed into the Systems data carrier and to send current status messages to the controller.
BIS L-409 IO-Link Device Processor Basic knowledge 4.3 Read distance/ To ensure that data carriers are recognized without error and the data can be reliably read, do offset not exceed a maximum distance and maximum offset between the data carriers and read heads (see “Technical Data”...
BIS L-201-0 / BIS L-101-05 – – – BIS L-202-0 / BIS L-102-05 – – – BIS L-20-0 / BIS L-10-05 – – – Mechanical data Housing material Plastic (PBT) Wiring Connector, M12 -pin, A-coded Enclosure rating IP65 (with connectors) Weight 220 g www.balluff.com...
Page 16
BIS L-409 IO-Link Device Processor Technical data Electrical data Operating voltage VS 2 V DC +10/-20 % Ripple ≤ 10 % Current draw ≤ 150 mA Load current capacity in SIO mode max. 50 mA Output C/Q Short circuit protected Device interface IO-Link Operating...
– – BIS L-201-0 / BIS L-101-05 – BIS L-20-0 / BIS L-10-05 – – Mechanical data Housing material Plastic (PBT) Read head housing material CuZn nickel plated Wiring Connector, M12 -pin, A-coded Enclosure rating IP67 Weight 200 g www.balluff.com...
Page 18
BIS L-409 IO-Link Device Processor Technical data Electrical Data Operating voltage VS 2 V DC +10/-20 % Ripple ≤ 10 % Current draw ≤ 150 mA Load current capacity in SIO mode max. 50 mA Output C/Q Short circuit protected Device interface IO-Link Operating...
0 - 5 0 - 8 0 - 11 BIS L-20-0 / BIS L-10-05 – – Mechanical data Housing material Plastic (PBT) Read head housing material*) CuZn nickel plated Wiring Connector, M12 -pin, A-coded Enclosure rating IP67 Weight 170 g www.balluff.com...
Page 20
BIS L-409 IO-Link Device Processor Technical data Electrical Data Operating voltage VS 2 V DC +10/-20 % Ripple ≤ 10 % Current draw ≤ 150 mA Load current capacity in SIO mode max. 50 mA Output C/Q Short circuit protected Device interface IO-Link Operating...
– – BIS L-201-0 / BIS L-101-05 – BIS L-20-0 / BIS L-10-05 – – Mechanical data Housing material Plastic (PBT) Read head housing material CuZn nickel plated Wiring Connector, M12 -pin, A-coded Enclosure rating IP67 Weight 170 g www.balluff.com...
Page 22
BIS L-409 IO-Link Device Processor Technical data Electrical Data Operating voltage VS 2 V DC +10/-20 % Ripple ≤ 10 % Current draw ≤ 150 mA Load current capacity in SIO mode max. 50 mA Output C/Q Short circuit protected Device interface IO-Link Operating...
00 = Remote read head C-05 housing (0.5 m cable) Interface 07 = IO-Link Mod- S = M12 -pin male Accessories Accessories for the BIS L-09-... can be found in the Balluff IO-Link catalog. (optional, not included) The catalog can be downloaded on the Internet at “www.balluff.de”. www.balluff.com...
