GSN PATROL-701 Installation And User Manual

PATROL – 701
PASSIVE INFRARED
OPTOELECTRONIC
INTRUSION DETECTOR
FOR INDOOR USE
INSTALLATION
AND USER MANUAL
www.gsncompany.com
G.S.N. Electronic Company Ltd.

Selecting mounting location.

Choose a location where
the detector will have a best view
angle of the most possible intrusion
sight. For gain maximum protection
zone it is recommended to place a
detector on 2.1 meter height.
Attention!
Avoid the following locations:
Areas with rapid temperature
changes.
Areas with strong air flows
On unstable or vibrating
surfaces.
Detector performance improves,
if it's located in thermo stable and
dynamically constant environment.
8. For vertical mount place
the PCB in the "A" position.
9. For mounting on a bracket
place the PCB in the "B" position.
10. Close the detector's cover
and fasten the screw.

Pulse count.

"PATROL-701" - Automatically
chooses and counts the levels
of the entering impulses,
according to the strength of the
signals acting on the detector.

Special features.

Hi – tech design
Automatic pulse count
Detector's sensitivity switch
regulator
Optoelectronic switch relay
Hi-light immunity –
no less then 10000 Lux
Hermetically insulated
pyrosensor
Low temperature mode
of working
Automatic temperature
compensation
High RFI & EMI immunity.

Mounting the detector.

1. To remove the front cover,
push the lower part of the case,
with a flat screwdriver.
2. Loosen the screw that holds
the PCB and move it, down to
the keyhole. Remove the PCB
from the plastic case.
3. Detector can be placed vertically
or at a small angle (up to 10°).
- For vertical mount use the holes
on the front side of the back cover.
- Use a bracket for mounting the
detector at an angle.

Sensitivity switch regulator.

For premises with stable
temperature environment, without
warmth's & another's influences on
the detector, use the "HIGH' mode.
For premises with strong air flows,
temperature changes, vibrations
and est., use the "LOW" mode.
S2
HIGH
LOW
SENSITIVITY

Description.

«PATROL-701» – passive infrared
detector with dual element
pyrosensor, was designed for
use in electronic alarm and
security systems
.
The device detects intrusion by
determining changes of energy
spectrum in infrared areas.
It emits no radiation and is harmless
for humans & animals.
The usage of "Fresnel Technologies"
original, optical, lightproof lens, has
allowed creating the detector, which
is protected from false alarms,
caused by a sunlight.
4. For wires connection use
the specially signed holes on
the plastic case of the detector.
5. Mount the back cover of
the detector to the wall.
6. Place the PCB back in the cover
and fix the correct position with a
screw.
7. Connect the wires according to
the scheme.
-
+ 12V TAMPER

Led indicator.

LED LED
ON ON
OFF OFF
JP 2 JP 2
Jumper's "ON" position – LED is
activated and will light on in case
of intrusion.
Jumper's "OFF" position – LED is
turned off.
RELAY
