SYSTRONIK S4600-ST Operating Instructions Manual

Pressure measuring instrument, ble
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operating instructions
Pressure measuring instrument
®
S4600-ST
Read instructions before using device!
Observe all safety information!
Keep instructions for future use!
12.2015
854.001.0690
(BLE)
SYSTRONIK
Elektronik u. Systemtechnik GmbH
Gewerbestrasse 57
D-88636 Illmensee
Tel.: +49 (0) 7558 / 9206-0
Fax: +49 (0) 7558 / 9206-20
E-Mail:
info@systronik.de
Internet: www.systronik.com
SYSTRONIK part no.: 523538

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S4600-ST and is the answer not in the manual?

Questions and answers

Related Manuals for SYSTRONIK S4600-ST

Summary of Contents for SYSTRONIK S4600-ST

  • Page 1 Tel.: +49 (0) 7558 / 9206-0 Fax: +49 (0) 7558 / 9206-20 E-Mail: info@systronik.de Internet: www.systronik.com Operating instructions Pressure measuring instrument ® S4600-ST (BLE) Read instructions before using device! Observe all safety information! Keep instructions for future use! 12.2015 854.001.0690 SYSTRONIK part no.: 523538...
  • Page 2 S4600-ST®...

  • Page 3: Table Of Contents

    "Pitot Measurement" program (option) ............28 6.12 "Leakage measurement" program (option) ..........30 6.13 "Leakage rate measurement" program (option) ......... 32 Memory mode and memory structure ..............38 How to save ....................38 Database Memory (option) ................. 41 Entering the user address ................48 S4600-ST®...
  • Page 4 Maintenance ......................51 10 Troubleshooting ..................... 51 11 Disposal ......................... 52 12 Warranty ........................ 52 13 Copyright ....................... 52 14 Customer satisfaction .................... 52 15 Addresses ......................52 16 Appendix ........................ 53 16.1 DIN EN 50379 certificate ................53 S4600-ST®...

  • Page 5: This Instruction Manual

    1.2 Explanation of symbols and typeface Symbol Meaning  Prerequisite for an activity  Activity consisting of a single step Activity consisting of a several steps  Result of an activity  Bulleted list Text Indication on display Highlighting Highlighting S4600-ST®...

  • Page 6: Safety

    Safety 2 Safety 2.1 Intended use © The pressure measuring instrument S4600-ST may only be used to measure pressure of gaseous media in non-hazardous areas. The ® measuring instrument S4600-ST must not be used for pressure measurement at gas lines.

  • Page 7: Calibration / Adjustment

    Safety 2.5 Calibration / adjustment ® S4600-ST must be calibrated on an annual basis. Calibration and adjustment may only be performed by the manufacturer or by third parties authorised by the manufacturer. 2.6 Modifications to the product Changes or modifications made to the product by unauthorised persons may lead to malfunctions and are prohibited for safety reasons.

  • Page 8: Product Description

    Product description 3 Product description 3.1 Scope of delivery Scope of delivery:  ® Measuring instrument S4600-ST  USB mains adaptor 3.2 Properties and functions Cancel ("Clear" key) / direct access Up key On/off key Protective sleeve Down key Menu / Enter key...

  • Page 9: Technical Specifications

    750 hPa to +1100 hPa Humidity range Ambient 20 % rH to 80 % rH Supply voltage Battery operation Lithium-ion battery 3.6 V / 1800 mAh Mains operation Mains adaptor (USB) Electrical safety Degree of protection IP 40 EN 60529 S4600-ST®...
  • Page 10 ( 8 mm) ( 8 mm) ( 8 mm) ( 3 mm) Table 3: Additional device specifications Parameters Value Barometric pressure measurement 500 – 1150 hPa Measuring range Max. deviation ± 1.5 hPa Resolution ± 10 hPa Sensor Semiconductor sensor S4600-ST®...

  • Page 11: Approvals, Tests And Conformities

    Transport and storage 3.4 Approvals, tests and conformities ® The S4600-ST pressure measuring instrument is approved as per the German Federal Immission Act (1. BImSchV) and EN 50379-2 and is TÜV-tested. It complies with the EMC Directive (2004/108/EC). 4 Transport and storage CAUTION Damage to the device due to improper transport.

  • Page 12: Using The Bluetooth Smart Printer

    Commissioning Using the Bluetooth Smart printer Measuring Data could be also transferred via Bluetooth Smart to the “EUROprinter-BLE”. Activate the Bluetooth Smart in the S4600-ST ® Settings and on the printer. To activate the Bluetooth Smart on the printer press the keys “OFF” and “ON” at once. A blue flashing LED means activated Bluetooth Smart otherwise the IR modus is activated.
  • Page 13 Select the detected printer to activate the printer. The IR modus could be set by deactivating the „Bluetooth Printer“ in the settings menu. Set the printer to IR modus as well. Press the keys „OFF“ and „ON“ at once and the blue flashing LED goes out. S4600-ST®...

  • Page 14: Operation

    Program selection The program selection section displays the available programs as symbols. Programs can be selected and started. Fig. 2: Program selection in the start menu ® (example: S4600-ST Pressure Measurement) Main display 1 Status line 2 Measured values 3 Information line...
  • Page 15 The information line provides information on the current measuring program, time, date, etc. Main menu  Display the main menu with the "Menu/Enter" key. The main menu provides access to the main functions of the device. All other functions and settings are accessed via submenus. S4600-ST®...
  • Page 16 The change must be confirmed with the "Menu/Enter" key. The Edit mode is activated for the next number. Once you have changed and confirmed all numbers, the Edit mode is disabled and the blue background disappears. S4600-ST®...
  • Page 17 Switching off the device, automatic Off function Switching off the device: Briefly press the "On/Off" key ® confirm with the "Menu/Enter" key. The S4600-ST measuring instrument also features a time-dependent automatic Off function; this function can be enabled or disabled.

  • Page 18: Changing The Units

    Operation 6.2 Changing the units  Displaying the main menu. Various units are available for pressure measurements. S4600-ST®...

  • Page 19: Setting Time And Date

    6.4 Setting the display © The intelligent power management of S4600-ST allows for optimisation of the battery life. Three display settings are available: "Normal", "Automatic" and "Eco Mode".

  • Page 20: Setting The Key Tone And The Alarm Tone

    Operation 6.5 Setting the key tone and the alarm tone  Setting the key tone and the alarm tone. There are four sound levels for the key tone and the alarm tone:    Medium  Loud S4600-ST®...

  • Page 21: Displaying Device Information

     Displaying diagnostics data Press the "Clear" key in the program selection area to display the diagnostics data. The Diagnostics menu displays, among other things, the firmware version, the release date and the serial number. S4600-ST®...

  • Page 22: Generating Qr-Code

    The "Datalogger" function can be operated via the main menu. The MicroSD card must have been inserted and sufficient memory must be available. The following screenshots use the "Pressure Measurement" program as an example; the Datalogger function is also available in the "Pitot Measurement" program (option). S4600-ST®...
  • Page 23  Changing the data logger interval. The sampling rate can be changed in Edit mode. The Edit mode is described in chapter 6.1, page 16. The sampling rate (interval time) can be set between 1 and 999 seconds. S4600-ST®...
  • Page 24 Stopping the Data Logger function The Data Logger function can be stopped via the main menu at any time. The data stored on the MicroSD card in XML format can be read and further processed via an Internet browser or other XML tools. S4600-ST®...

  • Page 25: Pressure Measurement" Program

    MicroSD card. The Data Logger function is described in chapter 6.7, page 22. Function Quitting the program "Pressure Measurement" / displaying the Direct Access menu. Changing selection in the menu. Displaying the main menu. Switch off the device. S4600-ST®...

  • Page 26: Pressure Loss Measurement" Program

     ® Connecting the system to S4600-ST ® The system to be measured must be connected to S4600-ST . The pump is then used to apply the test pressure to the system as per instruction. "START" starts the pressure loss measurement. A counter in the main display shows the duration of the running pressure loss measurement in seconds and minutes.
  • Page 27 Function Quitting the program "Pressure Loss Measurement" / displaying the Direct Access menu. Changing selection in the menu. Displaying the main menu. Switch off the device. S4600-ST®...

  • Page 28: Pitot Measurement" Program (Option)

    Logger function is described in chapter 6.7, page 22. Function Quitting the program "Pitot Measurement". Changing selection in the menu. Displaying submenu. Switch off the device.  Entering measurement data (units, K factor of the Pitot tube, chimney shape, chimney size) S4600-ST®...
  • Page 29 "Rectangular, you can set the height and width in mm. The Edit mode is described in chapter 6.1, page 16. If you select the menu item "Deactivated" in the submenu "Shape", volume measurement is hidden in the main display. S4600-ST®...

  • Page 30: Leakage Measurement" Program (Option)

    The colour of the pressure value then changes from grey to black. The black colour indicates that the device is ready for measurements. Zero balancing can also be performed manually via the main menu. First set the settling time with the arrow keys. S4600-ST®...
  • Page 31 The start and the end of the pressure measurent is signalled acoustically. The measured values are held in the main display; you can save or print the measurement log. S4600-ST®...

  • Page 32: Leakage Rate Measurement" Program (Option)

    It is possible to enter the system (tube) volume manually. If the system volume is unknown the device can calculate the volume automatically. Manually: If the system volume is known select “Enter vol. manually” and use the editor to set the volume. S4600-ST®...
  • Page 33 First connect the shut-off valve (1) with the measurement device. Then connect the plug (2) with the candidate system. Open the shut-off valve (1) and with the pumpball (1) give a pressure (working pressure) to the candidate system. In this example 4.80 hPa. S4600-ST®...
  • Page 34 With “START meas.” start the measurement. Then open the shut-off valve (1) and add (or minus) the syringe (3) volume. The volume of the SYSTRONIK syringe (3) is 108 ml. Close the shut-off valve (1) and confirm the volume change with “CONFIRM change”. The calculation will start and stop at the entered measuring time automatically.
  • Page 35 Operation The device shows the calculated volume in the last line. Confirm the volume and exit the calculation menu with the “Back” key. Set the settling time with the arrow keys, and confirm with “Next”. S4600-ST®...
  • Page 36 Available media are air and methane. It is possible either to set the barometric pressure manually or measure by the device. Disselect the item “Manual amb. press.” To activate the automatic measurement by the device. S4600-ST®...
  • Page 37 A counter in the main display shows the duration of the running measurement in seconds and minutes. The start and the end of the pressure measurent is signalled acoustically. The measured values are held in the main display; you can print save, or show the measurement log as QR code. S4600-ST®...

  • Page 38: Memory Mode And Memory Structure

    1 GB. CAUTION Damage to the memory card slot due to improper plugging in  Always insert the MicroSD straight and with the contacts pointing up as shown above.  Displaying the "Memory" menu. S4600-ST®...
  • Page 39 However, private user data (such as pictures, documents, etc.) are not deleted by this function.  ® The memory structure of S4600-ST consists of 100 memory blocks; one measurement log can be written to each of these blocks.
  • Page 40 Memory mode and memory structure A saved file may there be displayed, printed or overwritten by a new measurement. The saved file can also be displayed via a browser (such as Mozilla Firefox). S4600-ST®...

  • Page 41: Database Memory (Option)

    The customer information will be print out with every measurement print and shown in the protocol. It is possible to create or modify the customer database either on the ® S4600-ST or on a PC.  For first use of the MicroSD card the database should be generated For new database open menu „Memory“...
  • Page 42 Memory mode and memory structure  ® Create / modify customer database on the S4600-ST Select „Scan“ in the menu „Memory“ and type the customer name: Select with the arrow keys the row with the desired character. Open the row with the „enter key“ and select the desired character using the arrow keys.
  • Page 43 „OK“ save the customer name. Already existing name will be shown. If the name doesn’t exist it is possible to save the customer name with „New entry“. Now additional information could be saved. (Street, City, Email, and Phone No.): S4600-ST®...
  • Page 44 Now type customer information in the table of the “DATABASE.CSV“ file. Column A is the customer name and column B – H are for additional customer information. Don’t use special characters only „@“, „_“ and „.“. Maximum 20 characters per field. S4600-ST®...
  • Page 45 CAUTION  Incorrect editing of the „DATABASE.CSV“ could generate errors ® in the S4600-ST Finally save the „DATABASE.CSV“ and restart the S4600-ST ® before import the MicroSD card. In this way the database will be newly read.  Use of the memory...
  • Page 46 , print or override it with a new measurement. The file name and the storage location is shown in the lower bar. In this example: Storage folder: MEMORY/0000 and file name 0000_00.txt: The customer information will be shown in the header of the measurement report. S4600-ST®...
  • Page 47 Memory mode and memory structure The saved file can be opened with a web browser (e.g.: Chrome, Firefox, Explorer, Opera, etc.) S4600-ST®...

  • Page 48: Entering The User Address

    "Address.txt" on the MicroSD card. This is a plain text file with the extension .txt. The text file can be created on the PC using any text editor (such as Notepad). The maximum length is 8 lines with 22 characters each. Note: A new user address overwrites an existing user address. S4600-ST®...

  • Page 49: Battery Management

    Use only the power supply unit delivered with the device for charging the batteries.  Connect the device-specific power supply unit to mains and ® then to the S4600-ST  The charging process of the batteries starts automatically: Green Current battery capacity...
  • Page 50 © The graphical charge level indicator of S4600-ST consists of three elements of a battery symbol and helps the user to correctly estimate the capacity of the battery. Five different battery states are detected.

  • Page 51: Maintenance

    No indication of Sensor defective. Send the device to pressure. the manufacturer.  – Display frozen / Hold down device does not "On/Off" key for six respond to key seconds, presses.  – Other malfunctions Send the device to the manufacturer. S4600-ST®...

  • Page 52: Disposal

    Customer satisfaction is our prime objective. Please get in touch with us if you have any questions, suggestions or problems concerning your product. 15 Addresses The addresses of our worldwide representations and offices can be found on the Internet at www.afriso.de. S4600-ST®...

  • Page 53: Appendix

    Appendix 16 Appendix 16.1 DIN EN 50379 certificate S4600-ST®...
  • Page 54 Appendix S4600-ST®...
