Summary of Contents for Sonos S14
- Page 1 Play:1 Play:3 Product Guide...
- Page 2 Sonos, Inc. Sonos and all other Sonos product names and slogans are trademarks or registered trademarks of Sonos, Inc. Sonos Reg. U.S. Pat. & Tm. Off.
-
Page 3: What's In The Box
The S14 is compatible with any TV that has an HDMI ARC or optical digital audio output connector. Home network To use the Sonos app, your device must be on the same network as Sonos. If you need help, please go to http://faq.sonos.com/notfound. -
Page 4: Download The Sonos App
Download the Sonos App An easy way for you to listen to all your music - in bold Sonos sound. Just get the app from the app store on your mobile device and follow the setup instructions. Play music right away, start adding your music and voice services, or add a music library. - Page 5 Sonos uses minimal electricity when not in use. Turn off the sound using the app or the buttons. • Stop sound in just one room—touch Play/Pause on the S14. • Stop music everywhere—Use the app to pause the music. Play/Pause Touch to play and pause sound.
-
Page 6: Before You Start
Join Ethernet port Ethernet Port Use an Ethernet cable to connect the S14 to your Wi-Fi. Only use this port to plug in either the S14 or a Sonos BRIDGE or BOOST. HDMI connector Connect the HDMI cable from the S14 to your TV’s HDMI ARC connector. -
Page 7: Select A Location
Disconnect any existing home theater or surround sound equipment from your TV. Select a location Place the S14 on a tabletop or mount it on a wall above or below a wall-mounted TV. See Mount the S14 on a wall. -
Page 8: Connect Using A Optical Adapter
Product Guide • Do not place the S14 in a cabinet or on a walled shelf. Make sure both ends of the S14 are at least 1 ft. (30cm) from a wall or other obstruction. Set it up S14 is compatible with Sonos software versions 7.2 and later. If you are adding the S14 to an existing Sonos system, check for software updates first. - Page 9 Insert the power cord fully into the S14’s power connector and plug it into power. The speaker status light flashes. (OPTIONAL) If you are setting up your S14 with a SUB and/or surround speakers, put them where you want them and plug them in. ...
- Page 10 For a 5.0 home theater experience, set up two speakers, such as two PLAY:5s, as surround speakers with your S14. For a 5.1 home theater experience, pair a SUB and two speakers, such as two PLAY:5s, with your S14. Open the Sonos app (see 2).
-
Page 11: If You Need Help
If you’re adding to an existing Sonos system: a. Check to see if there’s a Sonos software update available. If you see one, please update your Sonos system before adding the S14. (S14 is compatible with Sonos software versions 7.2 and later). -
Page 12: Sub Settings
Tap Remove SUB. Choose one of the following settings: • If you want to associate the SUB with a different Sonos speaker, select Choose Room for SUB and then select another room. • If you are not going to use the SUB right now, select Don’t use SUB. It will appear in Rooms as SUB (unused) until you select it and associate it with another Sonos speaker. -
Page 13: Surround Speakers
Sonos S14 • If you want to associate the SUB with a different Sonos speaker, select Choose Room for SUB and then select another room. • If you are not going to use the SUB right now, select Don’t use SUB. It will appear in Rooms as SUB (unused) until you select it and associate it with another Sonos speaker. -
Page 14: Change The Surround Settings
If you’re using a mobile device Go to More > Settings > Room Settings. Select the room the S14 and surround speakers are located in. It appears as Room (+LS+RS) in Room Settings. Tap Advanced Audio > Surround Settings. -
Page 15: Play Music
Play music The S14 streams all your favorite music even when the TV is off. If TV Autoplay is On, the S14 stops playing music and switches to TV audio whenever the TV is turned on. Go to TV autoplay for more information. -
Page 16: Tune Your Room With Trueplay
Select the TV Setup tab. Click Remote Control Setup. Pick up the remote control you wish to begin using with the S14, and then click Next. Point the remote at the S14 and press the Volume Up button on the remote control. - Page 17 Select Manage > Settings (PC) or Sonos > Preferences (Mac). Select Room Settings if it is not already highlighted on the left. Choose the room the S14 is located in from the Room Settings for list, and then select the EQ tab. Choose one of the following options: •...
-
Page 18: Recalibrate The Audio
Tap Advanced Audio > Recalibrate Audio. Follow the prompts to optimize your audio performance. • If you have a SUB associated with your S14, you will be asked to choose between 2 test sounds: • Press Play to compare the volume of two test sounds, A and B, and then select No Difference, A is louder or B is louder. -
Page 19: Additional Tv Sound Options
TV is turned on, the music immediately stops and the S14 switches to TV audio. Additionally, if the S14 is in a room group when the TV is turned on, it automatically drops from the group. This setting is On by default. -
Page 20: Ungroup On Autoplay
A white light displays on top of the S14 to indicate that the unit is functioning in normal operation. If desired, you can turn this indicator light off so that when the S14 is in normal operation the white light does not display. -
Page 21: Mount The S14 On A Wall
Mount the S14 on a wall Use the S14 Wall Mount Kit (sold separately) to mount the S14 on a wall above or below a wall-mounted TV. Make sure the connector panel faces away from the TV when mounted—the Sonos logo should be farther from your TV. -
Page 22: Troubleshooting
• Did you allow Sonos to check for updates? The Sonos S14 requires software version 7.2 or later. • Is the power cord properly seated? Be sure to push the power cord firmly into the S14 until it is flush with the surface. - Page 23 After you disable your TV speakers, your TV might display an annoying or confusing message when you adjust the volume on the S14. This could be a message reminding you that your TV speakers are off, or a volume indicator unrelated to the sound from your S14. If you have a programmable remote control, you can try the steps below.
- Page 24 After you disable your TV speakers, your TV might display an annoying or confusing message whenever you adjust the volume on the S14. This could be a message reminding you that your TV speakers are off, or a volume indicator unrelated to the sound from your S14. Try the steps below to configure your universal remote so this message no longer appears when you increase or decrease the S14’s volume.
-
Page 25: I Have A New Router
If you purchase a new router or change your ISP (Internet service provider), you will need to restart all your Sonos products after the router is installed. Note: If the ISP technician connects a Sonos product to the new router, you only need to restart your wireless Sonos products. -
Page 26: I Want To Change My Wireless Network Password
Note: Don't see Advanced Settings? Your Sonos system may need to be updated. Tap Update Now if it appears. Are you part of our Sonos Beta program and using an iOS device? If you are, you’ll need to open the app on a device that’s not running iOS. -
Page 27: Important Safety Information
• Do not use chemical solvents (e.g. alcohol, benzene, paint thinner) or other flammable cleaning liquids. • Refer all servicing to Sonos qualified service personnel. Servicing is required when the unit or the power cord has been damaged in any way, if liquid or other foreign matter has fallen into the ventilation openings, or the unit has been exposed to rain or moisture. - Page 28 Sonos app. Music Music Services Sonos works seamlessly with most music services, including Apple Music™, Google Play Music, Pandora, Spotify and Radio by TuneIn, as well as downloads from any service offering DRM-free tracks. Service availability varies by region. See http://www.sonos.com/streaming-music.
- Page 29 Description Wireless Connectivity Connects to your home Wi-Fi with any 802.11 b/g/n router. 802.11n only network configurations are not supported—you can either change the router settings to 802.11 b/g/n or connect a Sonos product to your router. ™ SonosNet Extender...
-
Page 30: Product Guide Feedback
We’d love to hear from you! We’ll read your feedback carefully and use it to help us improve our product guides. Write to us at: docfeedback@sonos.com If you’re having a problem with your Sonos system, please contact Customer Care so they can help. Email them at http://www.sonos.com/emailsupport.
