Omneon MediaGrid ContentStore 3160
Front Panel Components
MediaGrid
1
Rear Panel Components
1 Power Supply
Module
2 Serial Attached SCSI
(SAS) Ports (2)
Left port: Input
Right port: Output
Omneon Technical Support: +1 888 673 4896 (Americas), +65 6542 0050 (Asia Pacific), + 44 1252 555 450 (EMEA),
+7 495 506-5981 (Russia, CIS), +81 3 5565 6737 (Japan), +86 10 8391 3313 (China, mainland)
Quick Reference Guide
1
2
2
1
Controller A
2
1 Power Indicator
2 Air Vents
ContentStore 3160
4
3
1 Left Control Panel
(for Controller B)
2 Disk Drives
3 Power Button
4 Right Control Panel
(for Controller A)
Controller B
28-0335 Rev. B
