Omneon MediaGrid CSS-2122 ContentServer
Front Panel Components
Rear Panel Components
1 Dual Redundant Power Supplies
2 Power Supply Indicator
3 ID LED
4 PS/2 Mouse Connector
Omneon Technical Support: 888 686-7781 (Americas), +65 6548 0500 (Asia Pacific), + 44 1256 347 401 (EMEA), +1 408 585-5200 (Other)
Quick Reference Guide
1 Power and Reset Buttons
2 Power Indicator/Wink
Hard Drive Numbering
1 Disk Drives (12)
5 PS/2 Keyboard Connector
6 System Status LED
7 Serial Connector
8 Video Connector
3 Air Vents
4 Status LEDs
2 Latch
3 Disk Drive Status LEDs
9 NIC 1 Ethernet Port
10 NIC 2 Ethernet Port
11 USB Ports
12 PCI Slots
28-0244 Rev. A
