Summary of Contents for In Win 915
- Page 1 Lighting Instruction Manual...
- Page 2 Lighting Modes The 915 will automatically display the lighting effects in the front panel for 10 seconds when computer turns on, then will lead users into two lighting modes. (The lighting modes depend on the features of the motherboard.) This allows users to switch between: 1.InWin LED (Default Mode)
-
Page 3: Installation Guide
2.Addressable RGB If your motherboard supports addressable RGB headers, please connect the 3-pin addressable cable directly to the motherboard (refer to the following step), it allows you to sync the addressable lighting effects with motherboard. Installation Guide Addressable RGB Light Bar Operation Instructions If your motherboard support the addressable RGB luminous effect, please follow the direction of sign and insert addressable RGB-strip into the 3-pin addressable RGB-strip header directly on the motherboard. - Page 4 Lighting Control 1.The lighting effects are controlled by pressing the Top Cover Ventilation & LED Lighting Control button. To switch between InWin LED mode and Addressable RGB, just simply hold the button for 2 seconds. (Note* The top cover ventilation control and system failure indicator will be temporarily unavailable.) 2.When switching from Addressable RGB to the InWin LED mode, it also can shift to different LED lighting effects by a quick press of the button, the button sequence is as follows:...
-
Page 5: Troubleshooting
Troubleshooting 1. When the system failure indicator LED is flashing on both sides, please check for any of the following occurrences: System Failure Color Occurrence Description Indicator A Malfunction of the The motor stops running, or the Motor or the Top top cover isn’t installed properly. Cover A Malfunction of the The limit switch or the internal Green Switch or the Wires wires are broken or damaged. - Page 6 Copyright © 2018 In Win Development Inc. All Rights Reserved.
