USING THE TRIFIELD EMF METER

1. Hold the meter as shown.
Note: Please do not cover the sensors at the top of the meter with your hand or other objects.
2. The knob is used to switch between measurement modes and to turn the meter off when not in use.
3. For measuring the effect of EMF on the human body (or any conductive body), use the dark blue
Weighted modes. For direct measurement of field strength, use the light blue Standard modes. The
red RF mode can be used for any radio or microwave measuring purpose.
4. The display shows the Field Measurement number and the units at the bottom of the screen. The
Peak Measurement number is shown at the top left next to the peak icon
5. To turn on the Audio Indicator, first remove the battery cover by sliding it downward. Press the audio
button . Press the audio button again to turn the audio off.
6. To turn on the backlight, first remove the battery cover by sliding it downward. Press the backlight
button
until the desired brightness is reached.
7. When the battery life indicator
the battery. Remove the battery cover by sliding it downward and tap the battery compartment on
the palm of your hand so the battery falls out. Replace with a 9V alkaline battery as shown.
at the top right shows only 1 bar remaining, it's time to replace
2
.
